Volanti Displays 32-4KT Quick Start

Installation:

• Review this quick-start guide and familiarize
yourself with the monitor.
• When unpacking, handle the monitor with
care making use of the carry handles. Remove
protective wrapping including from the display.
• Attach mounting brackets as appropriate and
mount before connecting cables.
• Connect video signal & USB touch cables to PC
or other appropriate input source.
• The monitor will auto-seek to any connected
video input. If multiple input sources are
connected they can be selected using the
buttons for the menu, or use the remote or any
connected room controller.
• Connect power supply to the monitor then plug
into AC mains as final step.
Note: The monitor default is to power on when
power is attached, it will then stay on if an active
video source is connected. If video is disconnected
it will auto power Off. This can be changed through
the OSD menu.

Monitor Information

• Volanti Display 32" PCAP multi-touch 4K
resolution monitor. See Input note below.
• Windows 10-point multi-touch, HID compatible
so just plug & play, no additional drivers or
software required if using Windows 8 or 10.
• Input: Use Ultra-HD (3840x2160) @60Hz for
optimal image quality. Lower resolution input will
be scaled to fill the display. The aspect ratio of
the display is 16:9, other aspect ratios may result
in black bars on the sides, for example a 4:3
image source will result in black bars left & right.
All manuals and user guides at all-guides.com
Quick Start - Front
32" PCAP 10-Point Touch - P/N: 32-4KT
www.volantidisplays.com
29"
31.5" viewing

In the Box

The Volanti 32" PCAP touch monitor comes with:
• Volanti 32" PCAP touch monitor.
• Remote control (with batteries).
• Power supply and power cord.
• HDMI cable
• USB cable
17"
