ESS ES98 2Q PRO Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ES98x2Q PRO & ES98x0Q
Evaluation Board Manual
Overview of ES9842/22Q PRO and ES9840/20Q evaluation board. Including quick start guide, power
supply configuration, input/output paths, register configuration, board schematic and layout.
2020-11-20 – TR – 2.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES98 2Q PRO Series and is the answer not in the manual?

Questions and answers

Related Manuals for ESS ES98 2Q PRO Series

Summary of Contents for ESS ES98 2Q PRO Series

  • Page 1 ES98x2Q PRO & ES98x0Q Evaluation Board Manual Overview of ES9842/22Q PRO and ES9840/20Q evaluation board. Including quick start guide, power supply configuration, input/output paths, register configuration, board schematic and layout. 2020-11-20 – TR – 2.1...

  • Page 2: Table Of Contents

    Power Jumper Configuration ........................ 4 Input/Output Paths ............................5 Inputs ................................ 5 Outputs ..............................5 Register Configuration ..........................6 ESS GUI ..............................6 First Boot ............................... 6 Automatic Register Loading ........................8 Clocks ................................10 Board Schematic ............................12 Board Layout ............................... 18...

  • Page 3: Quick Start Instructions

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Quick Start Instructions Follow these steps to quickly get started with your ES98x2Q PRO & ES98x0Q evaluation board (EVB) 1. Make sure that the headers are configured as shown. 2. Connect USB to AUX Bridge, balanced input cables and digital serial I2S cables to GPIO headers. 3.

  • Page 4: Board Overview

    Auxiliary USB Bridge (AUX Bridge) The Aux USB bridge is a ES9280AQ PRO which can provide the following functions: • ESS Suite GUI register control of DUT through I2C • Saving register configuration for automatic loading of DUT through firmware •...

  • Page 5: I2C/Spi Connections

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual I2C/SPI Connections ES98x2Q PRO & ES98x0Q support both I2C and SPI serial communications for register configuration. On the EVB, the ES98x2Q PRO & ES98x0Q registers are set to be configured through I2C by the ES9280AQ PRO.

  • Page 6: Bridge Connections

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Bridge Connections ADC output can be accessed through USB using the AUX Bridge by connecting the following jumpers: Note: USB output from the board requires firmware for the ES9280AQ PRO. Power Supplies Board Level Supplies •...

  • Page 7: Input/Output Paths

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Input/Output Paths Inputs There are 4 XLR and 4 RCA connectors on the board that can be used as inputs. The input stage is designed to reach 0dBFS output at 15.75Vrms for the ES9842/22Q PRO and 11Vrms for the ES9840/20Q The following jumpers must be installed for single ended input and removed for differential.

  • Page 8: Register Configuration

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Register Configuration ESS GUI First Boot 1. The following jumpers need to be installed to connect the AUX Bridge to the DUT (I2C address 0x40): 2. Connect to USB and wait for the GUI to detect the bridge device: 3.
  • Page 9 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 4. Select ES9842 PRO from the I2C Device dropdown 5. Click on the “Controls for I2C Device” button 6. The ES98x2Q PRO & ES98x0Q is now ready to be configured either via single register changes or S2M script: 7.

  • Page 10: Automatic Register Loading

    Evaluation Board Manual Automatic Register Loading The ESS Suite GUI can store an S2M script in the on-board EEPROM that will be loaded at boot-up. 1. Confirm that the AUX Bridge FW_EN jumper is installed: 2. Go to the “Tools” screen and confirm the firmware version is 0.1.8045...
  • Page 11 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 3. Go to the “Controls for I2C Device” screen and press the “Store Register Settings” button 4. Select an S2M script. This script will be loaded automatically when the AUX Bridge is powered Note: The script will be loaded every time the USB is plugged in.

  • Page 12: Clocks

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Clocks 2020-11-20...

  • Page 13: Board Schematic

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Board Schematic 2020-11-20...
  • Page 14 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 2020-11-20...
  • Page 15 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 2020-11-20...
  • Page 16 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 2020-11-20...
  • Page 17 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 2020-11-20...
  • Page 18 ES98x2Q PRO & ES98x0Q Evaluation Board Manual 2020-11-20...

  • Page 19: Board Layout

    ES98x2Q PRO & ES98x0Q Evaluation Board Manual Board Layout Top Layer 2020-11-20...
  • Page 20 ES98x2Q PRO & ES98x0Q Evaluation Board Manual Inner Top Layer 2020-11-20...
  • Page 21 ES98x2Q PRO & ES98x0Q Evaluation Board Manual Inner Bottom Layer 2020-11-20...
  • Page 22 ES98x2Q PRO & ES98x0Q Evaluation Board Manual Bottom Layer 2020-11-20...

  • Page 23: Revision History

    ESS Technology, Inc. ESS Technology, Inc. makes no representations or warranties regarding the content of this document. All specifications are subject to change without prior notice. ESS Technology, Inc. assumes no responsibility for any errors contained herein.

This manual is also suitable for:

Es98 0q seriesEs9842/22q proEs9840/20q
