TR Bale Handler Range
Operators Manual
JM AGRI DESIGN. Derrymore East, Tralee, Co. Kerry, Ireland. M: +353 (0)87 2193062 E: jmoynihan@jmagridesign.com.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VW TR Series

  • Page 1 TR Bale Handler Range Operators Manual JM AGRI DESIGN. Derrymore East, Tralee, Co. Kerry, Ireland. M: +353 (0)87 2193062 E: jmoynihan@jmagridesign.com.
  • Page 2: Table Of Contents

    Table of Contents Warning decals ............................3 TR-3 Technical Specification ........................4 TR-4 Technical Specification ........................5 TR-8 Technical Specification ........................6 Safety Precautions ..........................7 Dangerous Areas ..........................7 Hydraulic Fluid ............................ 7 Machine Operation ..........................7 Safety Shutdown Procedure ....................... 7 Safety Principles ..........................
  • Page 3: Warning Decals

    Warning decals 1. Read the operators manual carefully 2. Danger from oil splashes 3. Do not stand on or under implement 4. Danger stay a safe distance whilst machine is operating JM AGRI DESIGN. Derrymore East, Tralee, Co. Kerry, Ireland. M: +353 (0)87 2193062 E: jmoynihan@jmagridesign.com.
  • Page 4: Technical Specification

    TR-3 Technical Specification TR-3 Technical specification Length (closed) 1.296m Length (opened) 1.784m Width 1.23m Height (closed) 1.587m Height (opened) 2.055m Weight 220kg Max bale length 1.3m Max bale height 1.55m Max bale weight 1200kgs Hydraulic connection Double acting connection Oil pressure min & max 210bar/180bar JM AGRI DESIGN.
  • Page 5: Technical Specification

    TR-4 Technical Specification Technical specification Length (closed) 1.34m Length (opened) 1.835m Width 1.25m Height (closed) 1.584m Height (opened) 2.052m Weight 250kg Max bale length 1.3m Max bale height 1.55m Max bale weight 1200kgs Hydraulic connection Double acting connection Oil pressure min & max 180bar/210bar JM AGRI DESIGN.
  • Page 6: Technical Specification

    TR-8 Technical Specification Technical specification Length (closed) 1.34m Length (opened) 1.835m Width 2.4m Height (closed) 1.584m Height (opened) 2.052m Weight 500kg Max bale length 1.3m Max bale height 1.55m Max bale weight (combined) 2400kgs Hydraulic connection Double acting connection Oil pressure min & max 180bar/210bar Electrical supply 12v - 3 pole plug (24v optional)
  • Page 7: Safety Precautions

    Safety Precautions JM Agri-Design does not take responsibility for damages that may occur to machine, persons or other equipment, because of the machine NOT being used as described in this manual, or because of the safety precautions NOT being followed. IMPORTANT! Always make sure nobody is in the hazard area of the Bale Handler when the machine is in-use.
  • Page 8: Safety Principles

    It is the responsibility of the operator to ensure that all steps of the JM Trunk Bale Handler operating procedures are followed. Failure to do so may result in the Bale Handler being inadvertently closed or opened due to incorrect installation/operation. Safety Principles In addition to the recommendations given in this manual, legislation on work safety and accident prevention must be respected.
  • Page 9: Hydraulic System

    Before operating the machine, ensure that all safety guards are firmly in place and in good condition. If worn or damaged, replace immediately. Before operating the machine, check the tightness of all nuts and bolts, particularly on fixing elements. WARNING: Danger of crushing and shearing can exist when components are operated by hydraulic or pneumatic controls Before leaving the tractor or before adjusting, maintaining or repairing the machine, turn off the engine, remove the ignition key and wait until all moving parts have come to a stop.
  • Page 10: Operating Instructions

    Operating Instructions 1. When picking up a bale, it is best to tilt the JM handler forward slightly so the top of the mainframe (C) touches the top of the bale. By having the bale touching at point A, B & C ensures a tight grip at seen in figure 1 Figure 1.
  • Page 11 4. When unloading from a trailer or a stack of bales, open the trunk fully and carefully place the rollers over the touching bales so that the trunk can be gently rocked back and forth to create a space for the rollers to fit down into, as seen in figure 3. Rock back &...
  • Page 12: Maintenance

    Maintenance  Before checking for any machine malfunction and before adjusting, maintaining or repairing the machine, turn off engine and remove ignition key.  Check tightness of nuts and bolts regularly. Retighten if necessary.  If the machine is raised, prop it up in a stable position before carrying out any maintenance work.
  • Page 13: Guarantee

    GUARANTEE Subject as hereunder provided, the Seller undertake to correct either by repair or at their election by replacement any defect of material or workmanship which occurs in any of its goods within six months after delivery of such goods to first user. The term goods when used in this document means the article or articles described in invoice as sold by the sellers, but does not include equipment or proprietary parts or accessories not manufactured by the sellers.
  • Page 14: Operator Acknowledgment

    Operator acknowledgment 1. The operator understands and assumes the risk in using this product. All risks for operating the product are assumed solely by the user of the product. 2. You confirm that you are physically capable to use the product. 3.

This manual is also suitable for:

Tr-3Tr-4Tr-8
