Summary of Contents for GCS HLF 5700
- Page 1 QUICK START INSTRUCTIONS HLF 5700 Touch Screen QUICK START INSTRUCTIONS ENGLISH Part Code: 9BQE57G06 Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 2 These Operating Instructions must be read and applied by anyone performing work with or on the equipment described. In particular, it is imperative that all such persons familiarise themselves with the safety instructions. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
-
Page 3: Installation
Receiving the unit 1.1.1 NOTE Before to open the box of the HLF 5700 coffee maker, check out the packaging to be sure there is no damage. If damage is noticed, place a claim with the freight forwarder immediately. Check for: •... - Page 4 Extract the coffee hopper/s from the box and install it in the neck on the top lid of the HLF 5700 coffee machine, turn it clockwise until the micro fits into the hole (see image below).
- Page 5 Unscrew all the feet (A) supporting the coffee machine; screw the foot (B) (accessory) to foot (A); fix the support under the machine and repeat for the other 3 supports. (See image below) Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 6 WARNING Don’t try to operate the HLF 5700 coffee maker in case of presence of internal damages. Even if the damages are minimal, it’s strongly recommended to leave the unit disconnected from the power supply and call the technical service.
- Page 7 Refer to the national laws of your country for the connection to the water line. To connect the water line to the HLF 5700, is necessary to use a tube with a female screw of ¾ of inch at each end of it, as showed on the following picture.
- Page 8 QUICK START INSTRUCTIONS HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 9 Then, attach the end of the tube to the solenoid valve and the other end to the connector of the machine (see image below) The power for the valve should be connected with the appropriate wiring. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 10 1.2.2.2 How to connect the drainage tube Connect the drain pipe to the drip tray which is placed under the machine (see image below). HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 11 It is possible to download the coffee grounds directly into a larger drawer, external to the machine. • Insert the grounds discharge channel into the compartment located underneath the coffee group (see image below). Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 12 QUICK START INSTRUCTIONS WARNING Refer to planning diagram for the hole positioning. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 13 Insert the power cord on the back of the machine near to the main power switch. WARNING INSERT THE POWER CORD INSIDE A CORRECT WALL PLUG, WITHOUT USING ANY OTHER ELECTRIC ADAPTER. THE USE OF EXTENSION CORDS, ADAPTERS AND/OR MULTIPLE PLUGS IS STRONGLY FORBIDDEN! Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 14 1.3.1.1 Coffee beans Fill up the coffee beans hopper/s with fresh coffee beans. Remember to open the beans stopper located at the bottom of the coffee beans hopper. (see image A below). HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 15 It’s recommended to use a mix of coffee beans for automatic coffee makers, in order to avoid a rapid consumption of the grinder’s blades and also to get the best performance for the HLF 5700 For information refer to a coffee beans dealer. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 16 It’s recommended to do always this operation taking the powder canisters out of the machine, in order to keep the interior of the machine clean from dust. Place back each container in its original position. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 17 1.3.1.3 Milk WARNING Refer to paragraph 2.2.1.3 for the proper use of the milk with HLF 5700 machine. Open the door of the machine and take out the clear pipe from the inside. Open the fridge door and pass the pipe through the milk tube hole on the side of the...
- Page 18 QUICK START INSTRUCTIONS Then close the door of the machine and of the fridge. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 19 QUICK START INSTRUCTIONS CAUTION When pouring milk into the container, pay attention to hygiene to ensure that no contaminated milk enters the system. The milk container must be clean and dry. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 20 Take off the top lid and open the front door. Before to lift the tank, disconnect the grey tube from it (as the image below). HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 21 QUICK START INSTRUCTIONS From now it is possible to take out the tank and refill it. REMOVE THE TANK FROM ITS COMPARTMENT TO REFILL IT Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 22 When the detergent tank needs to be refilled, you will see this alarm in the main screen: If the alarm is still showing, press on the Reset button to show the detergent tank refill request. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 23 ATTENTION! The larger tank (blue label one) must be filled with two bottles maximum, the smaller tank (red label one) with only one bottle. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 24 Turning ON the unit 1.3.2 Turn on the unit by the main switch situated on the back of the HLF 5700 coffee maker. The following screen shot will appear on the touch screen. It means that an Hydraulic Loading has to be run in order to load water into all the hydraulic circuits.
- Page 25 QUICK START INSTRUCTIONS Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 26 QUICK START INSTRUCTIONS If the below screen shot will appear, push on the error icon (top right corner). The following screen shot will appear. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 27 This happened because at the first initial water fill in of the machine, the water doesn’t arrive directly to the boiler. After the press of the RESET button the machine will load the boiler, and the Hydraulic Loading screen will be shown again. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 28 QUICK START INSTRUCTIONS Initial heating 1.3.3 Once the cleaning cycle is finished, the Heating message will appear on the notification icon (top right corner). HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 29 When the notification icon disappears, the machine is ready to work. At this point it is possible to: • start delivering drinks • access the software and consult the instruction manual. To consult the Instruction Manual, push the top left corner: Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 30 QUICK START INSTRUCTIONS Then push Main Menu key. Enter the password (123456 by default) and push OK. HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 31 Scroll down to the bottom and push Manual. The application will check the version of the instruction manual installed (internet connection is required). If a more recent version is found, you will be asked to start the download. Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
- Page 32 The possible operations to do are the following: : to scroll to the previous page : to scroll to the next page : to access the manual bookmarks and select a section : to scroll forwards/backwards HLF Italian Design Q.S.I. HLF 5700 Eng V06-2021...
- Page 33 QUICK START INSTRUCTIONS User Manual 1.3.4 Scan the below QR Code or click on the following link to access the instructions manual of the machine: https://kutt.it/IM-5700-Eng Q.S.I. HLF 5700 Eng V06-2021 HLF Italian Design...
