Autex Acoustics Acoustic Timber Panel Install Instructions

These install instructions are of a general nature and are to be referred to when installing Acoustic Timber
Panel and Raft , as Acoustic Timber requires slightly different treatment. Please refer to the install instructions
™ ™
for the selected product as well as the below instructions.
These install instructions are designed to assist suitably experienced tradespeople in the installation of Acoustic
Timber products to a high standard in common wall and ceiling applications.
For installation support, contact your account manager before you start.
Autex Acoustics® recommends that all persons engaged in the installation of Autex Acoustics products have full
knowledge of the product and installation procedure as set out in the most recent edition of the manufacturer's
instructions, and related documents. Copies of these documents are available on request or from the Autex
Acoustics website.
Acoustic Timber Raft
™ ™
Manufacturer's
documents
Inspection
Transportation, storage
and handling
Acoustic Timber
For Acoustic Timber Raft Beam 100 and Beam 250 install instructions, please refer to pages 15 - 29 of our
Frontier™ Install Instructions.
Autex Acoustics recommends that all persons engaged in installing Acoustic Timber have full knowledge
of the product and installation procedure as set out in the most recent edition of the manufacturer's
instructions and related documents.
Manufacturer's documents relating to work in this section are:
• Acoustic Timber Panel Data Sheet
• Acoustic Timber Raft Data Sheet
• Acoustic Timber Panel Manufacturer's Guarantee
• Acoustic Timber Raft Manufacturer's Guarantee
• Acoustic Timber Install Instructions
• Cube™ Install Instructions
• Frontier Install Instructions
Copies of the above documents are available on request or from the Autex Acoustics website.
Before starting the installation of Acoustic Timber,
check that the materials have been supplied as
ordered and are free from damage or faults. Check
colors and product labels to ensure the product
has been supplied correctly. Where multiple sheets
of Acoustic Timber are required, it is important to
check that all product is supplied from one batch.
Due to batch to batch variation, we do not
recommend joining different batch lots as this
could result in color variation.
Acoustic Timber must be transported, stored,
and handled with care. Acoustic Timber should
be kept dry and stored indoors. Avoid delamination
or distortion, and protect edges from being
crushed. Do not accept damaged product.
If the product arrives damaged, note the condition
on the freight documents and contact Autex
Acoustics immediately.
Install Instructions
™
Any variations must be reported to Autex Acoustics
prior to commencing the installation.
Always ensure that the shop drawings have been
signed off before ordering and installing. If you
notice any inconsistencies, please contact your
account manager. No claims will be accepted
where the job continues with obvious faults
and no consultation with Autex Acoustics has taken
place.
Goods signed as received in 'good condition' will
not be the responsibility of Autex Acoustics. Always
transport and store Acoustic Timber on a flat,
clean, and dry surface.
™
