Summary of Contents for smart-MAIC D101
- Page 1 Measure, Analyze, Improve and Control, ..be smart! USER GUIDE smart-MAIC D101 Version 5.0...
-
Page 2: Table Of Contents
CONTENT Introduction ........3 Purpose of the device and its functions . -
Page 3: Introduction
INTRODUCTION Thank you for purchasing the smart-MAIC 101 Energy Monitor. This device allows you to measure and record changes in electricity consumption and parameters of a single-phase power grid. Purpose of the device and its functions The device is designed for continuous measurement of electrical network parameters and electricity consumption. -
Page 4: Location Of Device Components
Location of device components The device is made in a housing for installation on a DIN rail with an IP20 protection level. When installing at the monitoring object, it is necessary to use a mounting box made of plastic with a level of dust and moisture protection IP54 for indoor installation or IP65 for outdoor installation. For outdoor installations, avoid direct sunlight. -
Page 5: Getting Started
II. GETTING STARTED Installation and connection The device can be installed in an electrical panel on a DIN rail. Follow the steps below to install the device: 1. Mount the device on a DIN rail. 2. Secure the device by sliding the latch up. The connection of the device to the mains must be carried out by trained personnel with a permit of at least group III for electrical safety when working on installations up to 1000 V. -
Page 6: Connection Diagram
On your computer or phone, go to the list of wireless networks and select the smart-MAIC0123456789 network connection. If the “smart-MAIC” + network (your device number) is absent, briefly press the Reset button on your device. There is no default password for connection. - Page 7 In the "WiFi and Network" section, select your network name from the list of wireless networks, click the "Connect" button and enter your network password. If the name (SSID) of your network is missing in the list of wireless networks, refresh the list by clicking the "Refresh" button. Wait a minute and reconnect to the device's access point again.
- Page 8 In the "Server Config" section, check the connection of the device to the "cloud" server. In the "About" section, look at and copy the device ID for yourself. You will need the device ID to connect the device to the "cloud server".
- Page 9 To synchronize the accumulative meter [Wh] Energy and [rWh] Rev.Energy with the readings of your electric meter, set the initial values for the accumulated data in the device settings in the “Current Data” section, note that the device measures electricity in watts, therefore, the kilowatts of your meter need multiply by 1000 to get watts.
-
Page 10: Mqtt Service
Replacing the battery is carried out in the following sequence: 1. Disconnect the device from the power supply. 2. Unscrew the 4 screws connecting the device body and remove the upper case. 3. Remove the old battery from the holder. 4. - Page 11 The service supports two control phrases for enabling and disabling the output. Control phrases up to 15 characters long can be changed on the device's WEB interface in the "MQTT Server" section. By default, the phrase to turn on the output "1" is the phrase to turn off the output "0".
- Page 12 To activate the condition, you must select the data type, select the comparison sign ">" or "<", enter the value for comparison, select the required action. Example: If it is necessary to turn off the relay when the voltage exceeds 260V and turn on the relay when the voltage returns to 250V, then two conditions must be enabled: 1) V > 260 Relay OFF 2) V <...
-
Page 13: Specifications
X. CONTENTS OF DELIVERY The scope of delivery must comply with the following table № Name Energy monitor smart-MAIC 101 2 Current transformers XI. SPECIFICATIONS Main characteristics of the device and ranges of measured values Measurement error, active energy 0,5% Measurement uncertainty, voltage and current <1%... - Page 14 www.smart-maic.com...
