User Manual
Model: G200
A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 1
A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 1
1/12/21 10:09 AM
1/12/21 10:09 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G200 and is the answer not in the manual?

Questions and answers

Related Manuals for SoClean G200

Summary of Contents for SoClean G200

  • Page 1 User Manual Model: G200 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 1 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 1 1/12/21 10:09 AM 1/12/21 10:09 AM...
  • Page 2 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 2 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 2 1/12/21 10:09 AM 1/12/21 10:09 AM...
  • Page 3 SoClean Air Purifier Our mission is to bring pure air to those most susceptible to poor air quality. The SoClean Air Purifier is designed for individual rooms and personal spaces. With its portable, lightweight design, the SoClean Air Purifier, featuring Celios Advanced Air Purification Technology, removes allergens and mold and eliminates up to 99.99999% of viruses and bacteria.* Its ultra-fine purification system captures...
  • Page 4 READ AND SAVE THESE INSTRUCTIONS A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 4 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 4 1/12/21 10:09 AM 1/12/21 10:09 AM...

  • Page 5: Table Of Contents

    Table Of Contents PACKAGE CONTENTS • SOCLEAN AIR PURIFIER PRODUCT SPECIFICATIONS • IMPORTANT SAFETY INFORMATION WHERE TO PLACE YOUR SOCLEAN AIR PURIFIER SETTING UP YOUR SOCLEAN AIR PURIFIER • INSTALLING THE AIR FILTERS • INSTALLING THE LITHIUM ION SMART BATTERIES •...

  • Page 6: Package Contents

    SoClean Air Purifier Package Contents 1. Core 2. Main Stand 3. Mini Stand 4. Core Filter 5. Carbon Filters 6. Pre Filters 7. Lithium Ion Smart Batteries 8. Remote Control 9. Power Adapter 10. AAA Batteries 11. User Manual Not shown Featuring Celios Advanced Air Purification Technology A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 6...

  • Page 7: Soclean Air Purifier Product Specifications

    SoClean Air Purifier Product Specifications Power Requirements: DC input 15V, 4A ; Power brick 100-240V, 50-60Hz, 1.5A EPA Est. 96509-NH-1 AC Power Usage: Idle - 0.6W, Speed 1 - 2.5W, Speed 2 - 3.8W, Speed 3 - 6.5W, Speed 4 - 22W Dimensions 14.125”...

  • Page 8: Important Safety Information

    DO NOT use outdoors. may cause harmful interference to radio communications. DO NOT immerse the SoClean Air Purifier in liquid and do not However, there is no guarantee that interference will not handle the SoClean Air Purifier with wet hands.
  • Page 9 The batteries may explode in a fire. Dispose of Replacement Battery Guidelines: the air purifier in accordance with the following instructions: • Batteries must be installed in accordance with SoClean Instructions for Disposal of the Product: guidelines. Proper disposal of this product helps prevent waste and •...

  • Page 10: Where To Place Your Soclean Air Purifier

    Where to place your SoClean Air Purifier The SoClean Air Purifier is designed to purify air in small rooms or personal spaces, such as your bedroom, office, or car to create a zone of purified air around you. Use in larger rooms, may require longer run time to achieve desired purification .
  • Page 11 When you are not using a stand, just be sure to place the SoClean Air Purifier on its side, so the honeycomb grill on the bottom of the Core is not obstructed and is free to pull in air.

  • Page 12: Setting Up Your Soclean Air Purifier

    Setting up your SoClean Air Purifier STEP 1: INSTALLING THE AIR FILTERS The SoClean Air Purifier uses three different powerful air filters. All are colored blue for easy identification. You will need to order a replacement Filter Kit about every 8 months.
  • Page 13 Install the Core Filter The SoClean Air Purifier comes with one Core Filter. This filter captures ultrafine particules down to 10 nanometers in size. You will need to replace your Core Filter about every 8 months. 1. Slide the Core Filter into the Core with the grill facing up.
  • Page 14 Install the Pre Filter The SoClean Air Purifier comes with two Pre Filters. You will install one and save one for future use. The Pre Filter is made from material often found in HVAC systems, specifically designed to capture large airborne particles, such as dust, pollen, and pet dander.
  • Page 15 Install the Carbon Filter The SoClean Air Purifier comes with two activated granular Carbon Filters. You will install one now and save one for future use. The Carbon Filter removes gases, odors, and VOCs emitted from common household products. You will need to replace your Carbon Filter about every four months.
  • Page 16 2. Place the Carbon Filter into the tray as shown. 3. Slide the tray back into position in the Main Stand. Note: The Carbon Filter tray will click when fully installed. Featuring Celios Advanced Air Purification Technology A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 16 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 16 1/12/21 10:09 AM 1/12/21 10:09 AM...

  • Page 17: Installing The Lithium Ion Smart Batteries

    STEP 2: INSTALLING THE LITHIUM ION SMART BATTERIES The SoClean Air Purifier runs on either outlet power or Lithium Ion Smart Batteries, which are included with your purchase. These batteries are hot swappable, which means you can remove either of them without shutting down or interrupting air purification.
  • Page 18 Install Batteries into the Core Silver Wire 1. There are two slots for the Lithium Ion Smart Batteries above the Pre Filter you just installed. Pull the silver wire and rotate it upwards. 2. Take one Lithium Ion Smart Battery and align the battery slots to the slots within the unit.
  • Page 19 Dock the Core in the Main Stand 1. Plug the Power Adapter into the Main Stand and then to a powered electrical outlet. 2. Slide the Core into the Main Stand. The control panel on the Core will be facing the same side as the Remote.
  • Page 20 2. You can also charge the batteries outside of the Main Stand by plugging the Power Adapter directly into the Core. Note: The SoClean Air Purifier can operate: • On one or both of its batteries •...
  • Page 21 The Core can be docked in the Main Stand or plugged in directly. 2. Allow the batteries to charge until full You may run the SoClean Air Purifier on any setting while charging. 3. Turn the unit on to Speed 1 and remove the power adapter plug.

  • Page 22: Setting Up The Remote Control

    STEP 3: SETTING UP THE REMOTE CONTROL The SoClean Air Purifier uses a Bluetooth remote control device, which can work within a 75 ft range. When not in use, store the remote control in the slot on the front of the Main Stand.
  • Page 23 Pair the Remote Control with the Core 1. Install the provided two AAA batteries into the Remote Control. 2. With the SoClean Air Purifier powered on, press and hold the Core power button for 6 seconds. The Core will beep and its power button will begin to flash, indicating that it has entered Bluetooth pairing mode.
  • Page 24 Please try again. Troubleshooting: If you have problems with pairing your Remote Control, please visit SoClean.com/air-user-manual or call us at 866-501-3705 Featuring Celios Advanced Air Purification Technology A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 24 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 24...

  • Page 25: Remote Control Settings

    Remote Control Settings You can control the SoClean Air Purifier settings from: • The control panel on the Core • The Remote Control 1. POWER BUTTON Turns the SoClean Air Purifier on and off. 2. FAN SPEED BUTTON To select the fan speed you desire, lightly press the fan speed button on the control panel or Remote Control to cycle through the speed settings.
  • Page 26 While different fan speeds will either increase or decrease the rate of air flow, the purity of the air generated by the device remains the same at all speeds. Fan speeds 1 & 2 are recommended for use while you're in the room for pure air generated as quietly as possible, while speeds 3 &...
  • Page 27 3. INDICATOR With functioning AAA batteries, the indicator will illuminate with each press of a button on the Remote Control. The light also flashes during pairing. If the light does not illuminate, please check or change the AAA batteries. 4. NIGHT MODE BUTTON The night mode button controls the display panel illumination.

  • Page 28: Core Panel Descriptions

    Core Panel Description Power Button Fan Speed Button Battery Life Indicator Filter Life Button Pressure Light Warning Light Featuring Celios Advanced Air Purification Technology A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 28 A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 28 1/12/21 10:09 AM 1/12/21 10:09 AM...

  • Page 29: Cleaning Your Soclean Air Purifier

    CLEANING THE SOCLEAN AIR PURIFIER GRILLS If you notice that the SoClean Air Purifier’s airflow is weaker than expected, or if the grey grills on the top of the Main Stand look dirty, then it is time to clean the grills.

  • Page 30: Alarms & Notifications

    Alarms & Notifications • When you correctly dock the Core in • If the SoClean Air Purifier becomes the Main Stand with power, the unit blocked and there is no airflow, an will beep. alarm will sound. • When you install the first battery •...
  • Page 31 The SoClean Air Purifier LED panel will display an alert when the filters are approaching or due to be changed. Frequency Filter Notification Steps to Take 12 hr/day 24 hr/day Life operation operation Replace the Pre filter & Carbon filter (from the Filter Kit), then reset...

  • Page 32: Troubleshooting

    Troubleshooting Problem Possible Cause Solution • Install charged batteries or connect Unit does not power on • Battery(ies) or AC adapter not installed to AC adapter • Battery(ies) installed do not have • Replace batteries with charged ones charge or install AC adapter Battery should be charging •...
  • Page 33 Problem Possible Cause Solution • Remove batteries in Remote; Remote will not pair • Error in communications Pressure Light AND Warning Light are illuminated AND beeping is heard remove all power sources from the Core; reinstall power to the Core then batteries into the Remote;...

  • Page 34: Soclean Limited Warranty

    SoClean Air Purifier Warranty SoClean Inc. warrants this product under this This warranty does not cover product warranty for a two (2) year limited warranty for failures due to misuse, abuse, improper defects in manufacture or workmanship. maintenance, normal wear and tear, typical...
  • Page 35 LIMITATION DAMAGES: SOCLEAN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CON- SEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. NO LIABILITY ARISING FROM ITS USE, HOWEVER, CAN BE ACCEPTED BY THE COMPANY, WHO RESERVES THE RIGHT,...
  • Page 36 CUSTOMER SUPPORT If you have any questions about your SoClean Air Purifier, visit SoClean.com/air-user-manual or contact us by phone or email: 866-501-3705 info@soclean.com Manufactured for: SoClean Inc. 12 Vose Farm Road, Peterborough, NH 03458 For patent information visit SoClean.com/patents A000849-11 Rev C 011221 C000850 Rev C A000849-11_Rev C-SCAP IFU_7.5x5_NO 2400_011221.indd 36...
