Advantec ASMB-587 Startup Manual

ASMB-587 LGA 1200 Intel
MicroATX Server Board with 4 x DDR4, 3 x PCIe,
6 x USB 3.2, 5 x SATA3, Quad/Dual LANs, and IPMI
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 Startup manual
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 COM cable (for connection to real panel)
• 1 I/O port bracket
• 1 Warranty card
• 1 JFP1 cable
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for ASMB-587 at:
https://advt.ch/asmb587
Register your products on our website and get 2 months
extra warranty for FREE at:
http://www.register.advantech.com
This manual is for the ASMB-587 series Rev. A1.
Part No. 2041058700
Printed in China
Xeon
®
Specifications
Standard Functions
• CPU: LGA 1200 Intel
i7/i5/i3 processor
• BIOS: AMI 256 Mb SPI BIOS
• Chipset: Intel W480E
• System memory: Dual Channel DDR4 ECC/Non-ECC
2933/2666/2400 MHz unbuffered DIMM, Max. 128 GB
Note:
• SATA3 interface: 5 x SATA3 6Gb/s ports to support Intel
Rapid Storage Technology with software RAID 0, 1, 10 &
5 (for Windows only)
• Serial ports: Two serial ports onboard, only support RS-
232 (one can be in rear IO via COM cable connection)
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse via KMBS1 pin header
• Watchdog timer: 255 level timer intervals (sec/min)
• USB 3.2: Supports up to six USB 3.2 ports, four Gen2
ports in rear I/O and two Gen1 ports from on-board pin
header
• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)
Display Interface
• Chipset: CPU integrated Intel HD graphics controller
• Display memory: 1 GB maximum shared memory with
2 GB and above system memory installed (BIOS default
is 256 MB)
• Resolution:
- Supports VGA up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports DVI up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1: Intel
(LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU only)
Mechanical and Environmental
• Dimensions (L x W): 244 x 244 mm (9.6" x 9.6")
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power consumption: Max. load: +3.3 V @ 0.75 A, +5 V @
1.43 A, +12 V @ 0.66 A, +12 V (8P) @ 7.08 A, +5 Vsb @
0.13 A
• Operating temperature: 0 ~ 60° C (depends on CPU speed
and cooler solution)
1st Edition
October 2020
• Weight: 0.5 kg (weight of board)
W & 10th Gen. Core™
®
Xeon W and 10th Gen. Core™ i9/
® ®
Due to the inherent limitations of PC architecture,
the system may not fully detect 128 GB RAM
when 128 GB RAM is installed.
I219LM; LAN2 ~ LAN4: Intel
®
ASMB-587 Startup Manual 1
I210AT
®
