Summary of Contents for MOBILE SIGNAL BOOSTERS DoCall C15F-5B
- Page 1 C15F-5B Mobile Signal Booster User Manual PLEASE KEEP APPROPRIATELY AND CAREFULLY READ THIS USER MANUAL BEFORE INSTALLATION...
-
Page 3: Table Of Contents
The power supply voltage of the booster Ensure of grounding, waterproof and should meet the standards of security lightning protection when installing the requirements. booster. The user had better not dismantle the The booster should be installed and booster to maintain or replace the initiated by professionals. -
Page 4: Package Content
C15F-5B Five Band Signal Booster Package Content C15F-5B signal booster, 1pc 5V/2A power adapter, 1pc screws, 1bag U-shape holder, 1pc Outdoor antenna, 1pc Indoor antenna, 1pc 32 ft coax cable, 1pc 16 feet coax cable, 1pc Product Description C15F-5B booster is suitable for areas with multiple frequencies, supporting amplify 2G/3G/4G signal simultaneously. -
Page 5: Connector Description
Connector Description A ： Outdoor antenna port(N-female connector) B ： Indoor antenna port(N-female connector) C ： DC 5V power supply port D ： Grounding screw E ： PCS indicator F ： AWS indicator G ： CDMA indicator H ：... -
Page 6: Technical Specification
C15F-5B Five Band Signal Booster Technical Specification Items Uplink Downlink LTE12 698 ~ 716 MHz 728 ~ 746 MHz LTE13 776 ~ 787 MHz 746 ~ 757 MHz Frequency CDMA 824 ~ 849 MHz 869 ~ 894 MHz Range 1710 ~ 1755 MHz 2110 ~ 2155 MHz 1850 ~ 1910 MHz 1930 ~ 1990 MHz... -
Page 7: Installation Tools
Installation Tools Items Quantity Remarks Percussion drill Drill holes on wall, self-provided Wrench Reinforce the interface connection, self-provided Mobile phone for testing Test installation effectiveness, self-provided Multimeter Test voltage and wiring connection, self-provided Screwdriver Tighten or fasten the device, self-provided Prevent device from liquid leaking into the feeder Waterproof tape A lot... -
Page 8: Starting
C15F-5B Five Band Signal Booster 5) Put the expansion pipes(size: 8mm) into the 4 drilled holes. 6) As shown in the figure, align the fixing holes of the U-shaped back holder with corresponding holes on the wall. Then drive 4 M6*40 screws into the expand plugs with screwdriver. -
Page 9: Maintenance And Repairing
Maintenance and Repairing FAQ and Solutions Problems Reasonable Causes Solutions Check the power adapter and Indicator lights are off Disconnected to power source power outlet, and reconnect it The network of SIM card does not Replace SIM card or booster comply with that of signal booster Everything is okay after power-on, but no... -
Page 10: Fcc Statement
FCC Statement FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instruction for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
