- Page 1 EK12 / EK12C EK1235/EK1235C Deluxe Electric Kit...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please read all instructions before using the Electric Powerhead. When using this electrical appliance, basic precautions should always be followed, including the following: WARNING Electric shock could occur if used outdoors or on wet surfaces. 1) Unplug and disconnect power before 9) Do not allow to be used as a toy. - Page 3 Tool with Brush 3. (W-550) Top Wand 4. (BW240) Lower Wand Storage Accessories 5. (W-419H) Chrome 10. (H-431) Plastic Hose Hanger 11. (CB-180) Mesh Tool Caddy Bag Telescopic Ratchet Wand **EK12-SFH630 Hose, Direct Plug-In; EK12C- SFH630C Hose, 6ft. Pigtail Cord...
- Page 4 EB-250B 14” ELECTRIC POWER BRUSH Use this powerbrush to vacuum wall to wall carpeting, handmade carpets, fine rugs, and other flooring. This powerbrush must be used with the top and lower wands. Features include: • Quietdrive V-Belt--Multi-grooved reinforced belt for continuous contact and efficient transfer of power to the brush.
- Page 5 ELECTRIC BRUSH ASSEMBLY AND USE Wand Insertion and Release To Insert: Insert wand into electric brush until the wand button snaps into place. To Remove: Lock wands in straight-up position. Then, step on the “Wand Quick Release” pedal with foot. Now, pull up on wand. WARNING DO NOT attach or remove handle or wands while cleaner is ON.
-
Page 6: Belt Changing And Agitator Cleaning
ELECTRIC BRUSH CARE WARNING Always follow all safety precautions when cleaning and Electric Shock or Personal Injury Hazard servicing the electric Disconnect electrical supply before servicing or cleaning the brush. unit. Failure to do so could result in electrical shock or per- sonal injury from cleaner suddenly starting. - Page 7 4. Lift rear latches up and tilt cover forward from back until front snaps free. 5. Depress tabs on rear of agitator cover and rotate forward to release from the electric brush base. 6. Lift agitator assembly out and re- move worn belt.
- Page 8 4. Line up front of cover and base. Rest cover on front edge of base as shown. 5. Tilt cover to back. Press cover firmly until side and rear tabs snap into place. Turn the electric brush upside down and replace the 2 cover screws. WARNING Electric Shock or Personal Injury Hazard Disconnect electrical supply before servicing or cleaning the unit.
- Page 9 EB250 ELECTRIC BRUSH...
- Page 11 Your kit comes with either a direct connect wall end or a pigtail cord... *EK12-Direct connect wall-end--Must be used with an electric inlet valve such as the Electravalve.
- Page 12 WANDS 1. (W-550) Top Wand • Connects to lower wand when operating the floor brush 2. (BW-240) Lower Wand • Swivel Wand Connector--allows wand to rotate 90° along with wrist movement to provide ease of vacuuming and to prevent strain 3. (W-419H) Chrome Telescopic Wand • Extension wand--can be adjusted to necessary height to lessen back strain and can be extended to reach high areas • Extends from 23-1/2” to 39” in 3/4” increments •...
- Page 13 CLEANING ATTACHMENTS & TOOLS* To Attach Tools for Use: Simply slide the tool onto end of the telescopic ratchet wand or directly onto stub tube of the hose. *Tools are to be used with telescopic ratchet wand or handle on hose. Do NOT use with top or lower electric brush wands.
- Page 14 UT-630BBLK Premium Upholstery Tool with Brush • Cleans upholstered furniture, drapes, mattresses,and even works well on vehicle upholstery and carpets. • Continuous airflow is critical to cleaning results. This tool is designed to prevent airflow from being cut off. • The brush strip gently engages upholstery to lift debris and groom surfaces being cleaned. CB-180 Mesh Tool Caddy Bag •...
- Page 15 OTHER PRODUCTS AVAILABLE FROM LINDSAY MANUFACTURING, INC. A variety of accessories and tools are available to complement your EK12kit.** Below are just a few of the options available. Visit www.vacumaid.com Wet Pick-Up* This unit allows the powerful built-in central vacuum sys- tem to pick up liquid and wet debris, but prevents it from entering the vacuum tubing and dirt canister.
- Page 16 Copyright © 2017 by Lindsay Manufacturing, Inc. All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means without written consent. Any unauthorized copies will be prosecuted for civil damages to the fullest extent of the law.
