GSI Electronics 890-00664 Installation Instructions

Installing the EDGE Main Controller PSU Kit

Before You Begin

Follow the guidelines below for the safe usage of the product:
• Installation must be performed by qualified service person.
WARNING
• Read all the instructions carefully.
• Comply with local and national safety codes.

Terms of Use

Read and follow all installation, operation, and maintenance information carefully before using the
product. Refer to the user documentation for complete product specifications. If the product is used
in a manner not specified, the protection provided by the product warranty will be void.

IMPORTANT:

Protective Earth Ground Terminal, primarily used for protective earth terminals. Terminal connected to
conductive parts of a device for the purpose of safety and is intended to be connected to an external
system for protective grounding.
Power Supply - L1: High voltage input of the panel mount power supply.
Power Supply - L2/N: High voltage input of the panel mount power supply.
DANGER

What You Should Know

1. Position the metal plate from the right part of the enclosure onto the ribs and stand-offs.
2. Screw the metal plate to the main controller using the four screws included.
INSTALLATION
EDGE MAIN CONTROLLER PSU KIT
#890-00664 REV 03
