Magswitch 81101371 Operating Manual

Drill Press Fence Operation and Instruction Manual

Features and Benefits

Powerful magnets allow quick positioning and fine adjustment of the fence and make it easy to remove and store
•
when a fence is not needed.
Magnets can be positioned at different points on the fence for optimal placement on drill press tables.
•
The sturdy large vertical plate that will not interfere with the drill chuck, even when drilling holes close to the
•
fence, and can be used as a bandsaw resaw fence.
Stop block that can be quickly be positioned flush with the drill press table or sacrificial material under the
•
workpiece and can be stored out of the way when it is not needed.
The Fence Plate Spec:
•
Drill Press Fence Pro (81101371): the fence plate is 21 inches long by 4 5/16 inches high.
•
Drill Press Fence (81101375): the fence plate is 13 inches long by 2 1/2 inches high.
•
Read all instructions! Failure to follow all instructions listed below may result in an unsafe or dangerous condition.

General Precautions

• All magnets must be kept a safe distance from all magnetic storage devices, electronics, credit cards, etc.
• Ensure that Magswitch tools are stored in the OFF position when not in contact with ferromagnetic
materials. Magswitch tools can be left ON or OFF indefinitely without harm.
• When Magswitch tools are turned ON and brought near ferromagnetic materials there will be a sudden and
powerful attraction which can result in pinching and impact hazards.
• Never use a Magswitch tool to lift or transport materials unless specifically prescribed in the user manual.
All Magswitch tools can be used to clean up small debris such as nuts and bolts, metal shavings, etc.
• DO NOT attempt to disassemble or alter Magswitch tools; there are no user-serviceable parts inside.
• All Magswitch products are designed for normal work/jobsite conditions. DO NOT use underwater or in
hazardous environments without first consulting Magswitch engineering.
• DO NOT use a Magswitch tool if it is damaged or not working properly. Severe injury can occur if the device
is not used properly and safely.
• DO NOT expose standard Magswitch tools to temperatures above 176 degrees Fahrenheit (80 degrees
Celsius). Higher temperatures will permanently degrade the magnet's effectiveness and may result in product
failure or unsafe conditions.
• Painted or coated surfaces will reduce holding force and the finish may be damaged by the magnet.
• Always keep the bottom of the magnet clean and free of debris and rust. If needed, wipe with WD-40 or light
oil.
• This product contains PTFE lubricant. For MSDS information contact Magswitch.
