Summary of Contents for GWC AP1103
- Page 1 USB Serial Converter User's Manual...
- Page 3 Copyright Statement No part of this publication may be reproduced in any form by any means without the prior written permission. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any commercial damage, including but not limited to special,...
-
Page 4: Table Of Contents
Table of Contents 1. Introduction ....................... 1 Features ..........................1 Package Contents ......................1 System Requirements ......................1 2. Installation ......................2 ® Windows OS ........................2 ® Verify the Driver Installation on Windows OS ............... 3 ® Mac OS ........................... -
Page 5: Introduction
USB Serial Converter User’s Manual 1. Introduction How to find a lightest way to contact your PDA to the USB port on your PC? USB Serial Converter operates as a bridge between one USB port and standard RS-232 Serial port. You just easily hook the cable into PC or Hub’s port, and it can connect any RS-232 devices, such as PDA, scanner, printer…etc. -
Page 6: Installation
USB Serial Converter User’s Manual 2. Installation ® ® ® ® Windows Note: DO NOT connect the USB Serial Converter to your computer before completing the driver installation. * The strings of the driver and screenshots may vary slightly on each operating system. -
Page 7: Verify The Driver Installation On Windows Os
USB Serial Converter User’s Manual ® Verify the Driver Installation on Windows Once you finish the installation, you can open Windows Device Manager to verify if your Ethernet adapter is properly installed. To access the Device Manager: Windows 10: Settings\Devices\Connected devices ®... -
Page 8: Mac Os
USB Serial Converter User’s Manual ® ® ® ® Mac OS ® The provided Mac OS X driver supports: ® Mac OS 10.1 and later for PowerPC based Mac ® ® Mac OS 10.4 and later for Intel based Mac * The strings of the driver and screenshots may vary slightly on each operating system. - Page 9 USB Serial Converter User’s Manual 4. Select a destination disk to install the driver and click Continue. 5. Click Install. 6. When the Authenticate screen appears, enter your password in the provided field and click OK.
- Page 10 USB Serial Converter User’s Manual 7. Click Continue Installation. 8. Click Restart to finish installing the driver and reboot your Mac. 9. Connect the converter to a free USB port on your Mac. 10. To verify the installation: Go to Apple System Profiler > Extensions and you should find IOGraphicsFamily and IONDRVSupport among the list.
-
Page 11: Connecting Serial Device
USB Serial Converter User’s Manual Connecting Serial Device Now you can connect your RS-232 device to the converter. If prompted to install the driver for your serial device, follow the manual that comes with your serial device to complete the installation. -
Page 12: Specifications
USB Serial Converter User’s Manual 3. Specifications Data Transfer Rate 500 kbps Function USB1.1 Serial Converter operates as a bridge between one USB port and standard RS-232 serial port Ports USB 1.1, USB Type A male Power Bus-powered ® ® ®... -
Page 13: Regulatory Compliance
USB Serial Converter User’s Manual 4. Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received.
