- Page 1 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product.
- Page 2 Introduction MX88 is an 8-by-8 HDMI matrix. It allows any of the eight Input Channels (HDMI) to be routed to any of the eight Output Channels (HDMI), no matter the source is HDCP or not. Users can choose several different ways to control the matrix: by using infrared, RS232, and LAN and supplied remote control.
- Page 3 HDMI Matrix (Routing Type) Product Overview ■ Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Features ■...
- Page 4 Notice We. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
- Page 5 Package Contents ■ 1x Main unit. P/N_ MX88. ① ② 1x Remote. 1x RS232 cable ③ 12V/DC Power Supply. P/N_VDC01205. ④ ⑤ 1x CD-ROM(Control software operating instructions). Mounting ears. ⑥ NOTE: PART NUMBER (Abbreviation as P/N). ■ Panel Descriptions ①...
-
Page 6: Control Via Ir Remote
Connect the HDMI input source ( such as HD-DVD/ PS3/STB etc.)Into MX88. Connect HDMI OUT of MX88 to display equipment. Connect the Broadband IR receive cable into MX88 IR RX ports. Power on the input source you want to show. ( Keep the unused input power off, otherwise it may interfere the normal display). -
Page 7: Control Via Rs232
NOTE: if the IR remote isn‟t work, please press the” system code switch key”, but please do not put the remote against theXZ0808-001 3. Control via RS232. 1) The Interface of MX88 comctl... - Page 8 2) The Message Window 2.1) Receive Window The “receive window” will show the message received from MX0808. When you click the Control Buttons ( see step 4) or send Control Command ( see 2.3) to MX0808, it will send out the message about “operation results”...
- Page 9 equipment. Select the Input Port in “Port Select” column, click “Write” button to set EDID of this Input Port the same as display equipment. Click “Save as” button to save EDID read from display equipment as “*.bin” file. Click “Open” button to open saved “*.bin” file, select the Input Port in “Port Select” column, click “Download”...
- Page 10 will be opened. 4) Control command format If user want to write his own control software, below are data format and baud rate setting. Com port setting: Baud Rate: 9600 bps Data bits: 8 bits Parity: None Stop bits: 1 bit Flow control: None 5) RS232 command...
- Page 11 from 0~7. “y” : indicate the input port, range from 1~8. cir_4x\r\n Output 5 select input 1~8 “x” : indicate the input port, range from 0~7. “y” : indicate the input port, range from 1~8. cir_5x\r\n Output 6 select input 1~8 “x”...
- Page 12 bc_\r\n Obtain the input status. “x” : indicate the input port, range from 1~8. Copy edid from “x” to “y”, sed_x_y\r\n sed_x_y “x””y” range from 0~7 rst_\r\n Reset factory settings. 6) Web password reset The command length is 4 bytes. rpw+ „↙’...
-
Page 13: Lan Control
4. LAN control Note: Use the direct UTP cable to connect with PC, or use cross cable to connect to the Ethernet switcher A. Double click Netfinder.exe. Click “Search” button to get the device IP address. B. Click “Web Browser” button. A web browser will be shown. The default password is "0000000000", input the password and login. - Page 14 The right area is for device controlling. Click these buttons to control the device. It is the same as using the remote controller. The left area shows which input ports are being chosen by the output ports. C. Telnet Control Telnet matrix‟s IP address Now you can control the matrix (Page 14: Control command format)
- Page 15 Specifications ■ Operating Temperature Range 0 to +35° C (32 to +95° F) Operating Humidity Range 5 to 90 % RH (no condensation) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) DTV/HDTV:3D/ 1080P/1080i/720P/ Video Format Supported 576P/480P/576i/480i Audio Format Supported DTS-HD、Dolby HD...
- Page 16 Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: ...
- Page 17 Labor(90) Days)which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be made by the warrantor. During the “Labor”...
