Summary of Contents for Eltax Millennium Mini
-
Page 1: Instruction Manual
Instruction Manual M-100 Mini Component System... -
Page 2: Service Information
We have done our outmost to make sure that the product live up to your expectations. Should you still need help with installation etc. we suggest that you visit our home page . www.eltax.com On our home page under support you'll find >FAQ< Frequently Asked Question, where you'll find answers to most questions. -
Page 3: Table Of Contents
Service information Content Important safety notices Front- and rear-panel Remote control System connection Basic operation Radio operation Trouble shooting Technical specifications Own notes Content... -
Page 4: Important Safety Notices
WARNING: IT IS IMPORTANT THAT YOU STUDY AND OBSERVE BOTH THE INSTRUCTIONS IN THIS MANUAL AND THE INSTRUCTIONS ON THE DEVICE. KEEP THIS MANUAL FOR FUTURE USE. This device was developed and made with a view to providing maximum safety for the user. Incorrect use of the device may cause electric shock or fire. - Page 5 Lightning Unplug the device for additional protection during thunder or when the device is not used for prolonged periods. This will prevent damage to the device from lightning and surges. Penetration of objects and liquid Never push any objects through the openings into the device, as they may touch dangerous voltage points or short circuit parts and cause fire or electric shock.
-
Page 6: Front- And Rear-Panel
Remote control sensor 12 13 14 15 ANTENNA MINI COMPONENT SYSTEM MODEL: M-100 POWER SOURCE: 220-240V~50/60Hz POWER CONSUMPTION: 50W MAX ITEM NO.: SERIAL NO.: © Eltax A/S Denmark Developed and Designed in Denmark www.eltax.com AUDIO1 AUDIO2 EJECT VOLUME PLAY/PAUSE INPUT... -
Page 7: Remote Control
Mute 0-9 digits Save Search FM / AM Pause Stop CH- / Previous 10 Tune- / Fast reverse 11 Eject 12 +10 13 Mono 14 Frequency 15 Audio 1 16 Audio 2 17 Volume increase / decrease 18 Play 19 Shuffle 20 CH+ / Next 21 Tune+ / Fast forward Remote control... -
Page 8: System Connection
SPEAKERS (4-16 ) Ω ANTENNA MINI COMPONENT SYSTEM MODEL: M-100 POWER SOURCE: 220-240V~50/60Hz POWER CONSUMPTION: 50W MAX ITEM NO.: SERIAL NO.: © Eltax A/S Denmark RIGHT LEFT Developed and Designed in Denmark www.eltax.com AUDIO1 AUDIO2 SPEAKERS (4-16 ) Ω ANTENNA... -
Page 9: Basic Operation
Preparation Before turning the M-100 mini component system on, check that all connections are correct and reliable. Plug the AC powercord into a corresponding AC outlet. Press POWER on the front panel. Volume adjustment Press the VOLUME buttons on the remote or turn the volume button on the front panel to turn the volume up and down. - Page 10 Basic operation Fast forward and fast reverse During playback press the TUNE- / << (fast reverse)- or the TUNE+ / >> (fast forward)-button for fast forward or reverse playback. Each time the “TUNE- / <<” or “TUNE+ / >>” button is pressed, the speed increase. The will continue happening until the “TUNE- / <<”...
-
Page 11: Radio Operation
FM/AM radio operation 1. Enter the Tuner function by pressing the FM/AM-button on the remote or on the front panel. The tuner will start in the last known state. Press the FM/AM-button again to change between the FM and AM band. 2. -
Page 12: Troubleshooting
Please check the schematic below before requesting service. On our home page www.eltax.com answers to most questions. Common sympton No function No playback Sound in one or more channel(s) is missing The remote doesn’t work Troubleshooting under support you'll find >FAQ< Frequently Asked Question, where you'll find... -
Page 13: Technical Specifications
Technical specifications CD player Compatible Discs Connections Connections Amplifier Audio signal noise ratio: Frequncy response: Audio output power: FM Tuner Tuning Range S/N Ratio Monophonic Stereo Selectance Monophonic Stereo Frequency Response Stereo Resolution AM Tuner Tuning Range S/N Ratio Remote Control Transmitter Signal Range Power Source... -
Page 14: Own Notes
Own notes... - Page 15 Own notes...
- Page 16 For further information please visit our website: www.eltax.com Item no. 40131...
