Summary of Contents for Strack Eloflex Series
- Page 1 INSTRUCTION MANUAL FOR USE, DRIVING AND SAFETY Read this documentation before using your Eloflex to make sure that you use it in a manner that is safe, and which does not harm you, your environment or your power wheelchair. Eloflex...
-
Page 2: Table Of Contents
Thanks and good luck! Thank you for choosing an Eloflex as your power wheelchair. It means a lot to us because our vision is to make people’s everyday life a little easier and to give people with disabilities a greater freedom. We hope you experience both with the help of your Eloflex. We believe that you will enjoy much of your new power wheelchair. -
Page 3: Intended Use
Intended use Type classification and intended use Accessories Eloflex power wheelchairs have been developed for people Chargers and bag with simpler tools are available when who have difficulty walking or cannot walk at all, but who delivered in the storage bag under the seat. have vision ability, physical ability and mental ability to control Utility an power wheelchair. -
Page 4: Folding
Folding P D2 Fold up Step 1 Place the folded chair on the ground as shown on the right. Grasp the backrest and pull upwards to open the chair. Hold on with one hand on the seat cushion. Step 2 It is very Close the lock - this is very important! important... - Page 5 Folding Fold up Stand behind the chair and push the seat edges downwards. Fold Stand behind the chair and lift the seat edges upward. Fold the backrest You can fold the upper part of the backrest during transport by pressing the two locking buttons and folding the backrest backwards.
-
Page 6: Install The Joystick
Install the joystick P D2 Step 1 Mount the joystick in the tube under the armrest and tighten the screw in the desired position. Step 2 Assemble the cable connectors and gently rotate until the pins enter the holes and the grooves in the two IMPORTANT! connectors engage. -
Page 7: Change The Seat Width
Change the seat width P D2 You can increase the seat width by moving out the armrests using the widening kit. You can choose to increase the seat width by 5 or 10 cm. Step 1 Loosen the armrests on each side by unscrewing its two brackets. -
Page 8: Joystick
Joystick P D2 Battery status Power on and off Reduce speed Increase speed Joystick Horn USB connector TIP: Use the USB connector on the underside of the joystick to charge your mobile phone. Joystick: Controls the Increase speed: Press to Battery status: This chair’s speed and direction. -
Page 9: The Footrest
P D2 Footrest For easier entry and exit, the footrest can be folded up as shown down below. Adjust the footrest You can change the height of the footrest in two fixed positions. Remove the black plastic cover from the four nuts. -
Page 10: The Backrest
Backrest P D2 Adjust the height You can steplessly adjust the height of the backrest. 1. Loosen the knobs behind the backrest 2. Pull up the backrest to the desired height. 3. Tighten the lock knobs. 4. If necessary, adjust the backrest cover to the desired position. -
Page 11: The Armrest
Lift the armrests P D2 To lift the armrests up and down, first loosen the lock by turning the locking lever half a turn. Then lift the armrests. OPEN It is important that you lock the armrests when you fold them down again by turning the lock lever back half a turn. -
Page 12: Disassemble & Assemble - Model D2
Disassemble and assemble Dissemble Step 1 Fold the chair and put it upright. Make sure that the anti-tip devices are facing forward when you raise the chair so that the lower part can stand on its own. Step 2 Push down the handle of the locking mechanism while lifting the upper part off the lower part. -
Page 13: Fold Joystick
Fold down the joystick P D2 The smart joystick mount allows the user to quickly lower the joystick without removing it. This means that you get closer to the edge of the table, which gives a better sitting position. 1. Lift the lock lever to release the joystick. -
Page 14: Transport & Storage
Transport and storage • To lift the chair, it is recommended that the chair is first folded. • A folded chair can be put in the luggage of a car or set in a wardrobe. • If the chair is not to be used for a while, we recommend that the batteries be fully charged before the chair is set aside. -
Page 15: Accessories
Accessories You can make your Eloflex even smarter and adapt it to your own, individual needs with our accessories. We are constantly developing new accessories. ELOFLEX HEADREST ELOFLEX ATTENDANT CONTROL ELOFLEX PREMIUM CUSHIONS The headrest makes your Eloflex more With one of our attendant controls, With one of our premium cushions, personalized and useful, even for the person behind can easily drive... -
Page 16: Driving
DRIVING Safety instructions when driving There is a risk of injury by tipping the wheelchair. Risk of injury if you collide with other objects in • Only drive in inclines that do not exceed the narrow passages. maximum allowable slope •... - Page 17 Driving Read Run over obstacles The user must read these safety and driving instructions Run over obstacles: Drive slowly to the obstacle and make before using the Eloflex power wheelchair. sure the front wheels are in the direction of travel. Then move the joystick slowly forward while leaning backwards to drive Practice over the obstacles Eloflex is tested and approved for ob...
-
Page 18: Safety
SAFETY General safety instructions There is a risk of personal injury if the power There is a risk of personal injury if the maximum permissible load is exceeded. wheelchair is used for purposes other than those described in this document. •... - Page 19 Safety Crossing railway tracks Beware of heat Always cross the railway track straight from the front, never Never leave your Eloflex in direct sunlight or near a heat obliquely from the side. Never cross the railway tracks alone, source as the batteries may be damaged. Never be near always have someone with you who can help you.
-
Page 20: Technical Specifications
Technical specifications MODEL Weight 26 kg 28 kg 16+17 kg 28 kg 38 kg 26 kg Range 30 km 25 km 30 km 30 km 40 km 30 km Max load 120 kg 120 kg 160 kg 160 kg 200 kg 120 kg Speed 6,5 km/h...
