Lumitec
Kraken Dock Lighting System Installation Instructions
Models: 101638
WARNING
WARNING:
RISK OF ELECTRIC SHOCK
•
Use only in bodies of water, ponds and small decorative fountains where persons will immerse
no more than their hands and lower arms while the product is energized.
•
DO NOT use in water intended for swimming, wading, immersion, or bathing.
•
All installer completed cable connections must be located outside of bodies of water, pond or
fountain.
•
Low voltage circuit must be supplied by a power unit marked as suitable for supplying
submersible luminaires.
•
Power unit must be supplied by a circuit protected by a ground fault circuit interrupter (GFCI).
•
Maximum depth: 8 feet
•
All installer completed cable connections must be located outside of bodies of water, pond or
fountain. Take careful consideration of tidal shift if connections are completed under docks, or
near waterline.
WARNING: For your safety read and understand instructions before starting installation. Before
permanently wiring to branch circuit, turn off electricity at the fuse or circuit breaker box. Before
attempting any installation check your applicable electric code. This code sets the wiring standards and
should be carefully studied before starting.
Note: All statements, technical information and recommendations contained herein are based on
information and tests we believe to be reliable. The accuracy or completeness thereof are not
guaranteed. In accordance with "Terms and Conditions of Sale", and since conditions of use are outside
our control, the purchaser should determine the suitability of the product for his intended use and
assumes all risk and liability whatsoever in connection therewith.
IMPORTANT:
Read carefully before installing fixture. Retain for future reference.
APPLICATION: Kraken Dock Lighting Systems are designed for outdoor wet locations, where moisture,
dirt, corrosion may be present. Mantis underwater dock lights are intended for full submersion in fresh
and salt water.
Listed models of Kraken Dock Lighting System can be operated at the following voltages:
UNIVERSAL 100VAC - 300VAC 50/60Hz
Revision C 04/2020
600788
1
