- Page 1 WP10 Installation manual Copyright © 2021 TKH Security B.V.. Version 2.0. TKH Security | Siqura EX-PD24 | Installation manual...
- Page 2 Any brand names mentioned in this manual are registered trademarks of their respective owners. Liability TKH Security accepts no liability for claims from third parties arising from improper use other than that stated in this manual. Although considerable care has been taken to ensure a correct and suitably comprehensive description of all relevant product components, this manual may nonetheless contain errors and inaccuracies.
-
Page 3: Table Of Contents
Connecting the HSG04 ....................... 9 Connecting the SA camera series ..................10 Connecting a WP10 to a SA-PTZ ................10 Connecting a WP10 to a SA-FIX W ................10 Dimensions ........................11 TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 4: Description
The units can be controlled using a 24 Vac control signal or a dry contact / open collector signal. The WP10 is fitted with a float switch that prevents the pump from running dry and indicates an “empty tank” by an contact-closure output. TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 5: Before You Continue
Ensure that the unit case is properly earthed, connecting all the earth ground studs. TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 6: Install The Unit
M6: Water M3: Empty tank connection: 100 Vac power connection pump (pre- alarm. Can be set to to 240 Vac 24 Vac or 24 Vdc connected) NC or NO via J1 TKH Security | Siqura WP10 | Installation manual v2.0... - Page 7 Power Supply GREEN LED turns ON when a power supply is provided Water Level Alarm RED LED, turns ON when empty tank is detected Pump Motor Output YELLOW LED, turns ON when the Water Pump is enabled TKH Security | Siqura WP10 | Installation manual v2.0...
-
Page 8: Connecting The Upxx Series
Black Not used Brown ALARM OUT NO Normally open (Washer) ALARM OUT NC Orange Normally closed ALARM OUT COM Yellow Common (Washer) WP10 Washer tank WP10 UP33/UP36 24Vac Mains power power TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 9: Connecting The Hsg04
The washer is controlled by alarm output (DO2) from HSG04. The movement will be maintained by camera installed in HSG04. Detailed configuration please refer to HSG04 quick start guide. WP10: To M7 Pin 1 & 2 TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 10: Connecting The Sa Camera Series
Connecting the SA camera series Connecting a WP10 to a SA-PTZ WP10 Washer tank 24Vac Mains power power Connecting a WP10 to a SA-FIX W WP10 Washer tank 24Vac Mains power power TKH Security | Siqura WP10 | Installation manual v2.0... -
Page 11: Dimensions
Dimensions Dimensions in mm TKH Security | Siqura WP10 | Installation manual v2.0... - Page 12 TKH Security Proposal | RFP Name | RFP Number tkhsecurity.com Brands Our Brands © 2020, TKH Security. © 2021, TKH Security TKH Security | Siqura EX-PD24 | Installation manual...
