- Page 1 4 8 4 1 9 - 7 7 4 8 4 1 9 - 1 2 5 4 8 4 1 0 4 8 4 2 0 LANG Technik GmbH • Albstraße 1-6 • D-73271 Holzmaden • www.lang-technik.de • Version 2021/010...
- Page 2 This documentation is subject to errors and omissions. LANG Technik GmbH reserves all rights to this documentation. Product modifications: Modifications to the product by the customer void the warranty. No modifications may be made to the product without the manufacturer‘s consent.
-
Page 3: Table Of Contents
Contents Chapter 1 Product Description Page Unit Areas of Application Accessories Chapter 2 Technical Data General Data Material Scope of Supply Maintenance and Repair Chapter 3 Design and Function Assembly Disassembly Chapter 4 Servicing Malfunctions/Error Chapter 5 Warnings Intended Use Personnel Requirements Protective Equipment and Safety Chapter 6 Decommissioning... -
Page 4: Unit
Product Description Unit Our Makro•Grip Contour Jaws are used to clamp workpieces such as those with ® pre-machined contours (see example). Using the two magnets eliminates the need to screw down the contour jaws. Information on mounting and use can be found under 3.1. No special base jaws are required –... -
Page 5: Chapter 2 Technical Data
2.4 Maintenance and Repair Please contact LANG Technik GmbH directly if any item is damaged or malfunctioning. LANG Technik GmbH • Albstraße 1–6 • D-73271 Holzmaden, Germany • Phone: +49 7023 9585-0... -
Page 6: Chapter 3 Design And Function
Design and Function Assembly PREPARING THE MAKRO•GRIP CONTOUR JAWS: ® 1. The magnets (2x) are inserted by hand into „ the slots of the top jaw and pushed toward the outer surfaces. Magnet 2. The mounting tool is then positioned with „... -
Page 7: Use
Design and Function 3.3 Use SETTING UP THE MAKRO•GRIP CONTOUR JAWS ON THE MAKRO•GRIP 5-AXIS VISE: ® ® 1. Place the contour jaws precisely and accurately on the Makro•Grip Jaws. ® „ The pre-stamped contour must engage and lock into the serration of the clamping jaws. - Page 8 No precision block With precision block LANG TECHNIK SAFETY INFORMATION The minimum clamping depth (E) is limited to 3 mm. In this regard, applying force above the 3 mm clamping depth is not permitted.
-
Page 9: Chapter 4 Servicing
Servicing Malfunctions/Errors Caution! The component and clamping device can become magnetized. The inserted magnets, as well as the part, can become magnetized as a result of using the Makro•Grip 5-Axis Vise several times. Particles from milling can ® remain stuck on the device. Regular cleaning of the elements is necessary to ensure a perfect fit without interference. -
Page 10: Chapter 6 Decommissioning
Specified in EU Directive 2018/851 Comply with country-specific disposal regulations when disposing of equipment. LANG Technik products are not considered household waste. Failure to comply with disposal requirements is a regulatory offense. Accessories and packaging are recycled in an environmentally friendly manner. -
Page 11: Chapter 7 Explanation Of Symbols
Explanation of Symbols Symbols Please pay attention to the following warning symbols Read all the operating instructions carefully before commissioning for the first time and keep it in a safe place for future use Please read and follow the technical and safety instructions Direction indicator Direction indicator, correct rotation The use of protective gloves made of tough, resistant material is... - Page 12 LANG Technik GmbH Albstraße 1–6 D-73271 Holzmaden Phone: +49 7023 9585-0 Fax: +49 7023 9585-100 Internet: www.lang-technik.de General e-mail: info@lang-technik.de Sales e-mail: sales@lang-technik.de...
