Summary of Contents for Asetek Invicta Sim Racing Clutch
- Page 1 Invicta Sim Racing Clutch Manual...
- Page 2 Thank you for purchasing the Asetek SimSports™ Invicta™ Clutch. You have made an excellent choice! We are sure the Invicta Clutch will help you take your sim racing career to the next level. Whether you are a beginner or an experienced racer, you will now be able to reach ultimate immersion.
-
Page 3: Table Of Contents
Table of contents 4.3 Start Racing! ........................23 5. RaceHub Adjustments ..................... 23 Foreword ............................. 2 5.1 RaceHub Download ......................23 About this document......................2 5.1.1 RaceHub Installation ....................23 Other Relevant Documents ....................2 Symbols Used ..........................3 5.1.2 RaceHub Updating ...................... 24 Copyright ............................ -
Page 4: Foreword
The serial number can be found on the bottom of the base plate and written here for your convenience: This manual is written for the end-user of the Asetek SimSports Invicta Clutch and contains all information required to correctly... -
Page 5: Symbols Used
Asetek. This manual or any parts thereof may only be published, transmitted, displayed, or made available to a third party with express written permission from Asetek... -
Page 6: Box Contents
The box contains the following components and accessories: • Invicta Clutch pedal • Safety brief • Manual (This document) • Warranty statement • Asetek SimSports sticker sheet • M6x5 set screw (x2) • M6x20 bolt (x2) • M6 Slot nut (x2) • Washer (x2) •... -
Page 7: Videos
The Asetek SimSports https:/ /www.asetek.com/simsports/product/invicta-pedals-clutch/ Invicta Brake & Throttle pedals can be bought in our webshop or at an Asetek SimSports authorized dealer. Do not use the pedals 1.4 Support & Contact without mounting, for they may shift during use. -
Page 8: Compatibility
Unauthorized removal or modification of parts or safety devices of the product; Games Assetto Corsa • Use of spare parts or accessories that Asetek SimSports has not Assetto Corsa Competizione approved; DiRT Rally • Mounting and/or use of any parts in a vehicle;... -
Page 9: Product Overview
3. Product Overview Clutch pedal face plate Clutch pedal arm Rod clevis lock pin Rod clevis Clutch pivot pin & bushing Clutch spring Spring lock pins Clutch preload force adjustment Lock nut Clutch end-stop Clutch curve adjustment Pivot bracket Pivot bracket Clutch Pedal stop Locking thumb nut Heel rest... -
Page 10: Getting Started
• Allen key, 5 mm (not included) all adjustments to the positioning of the base must be handled • Key wrench (not included) by your rig. Note: Use the allen keys supplied with the Asetek SimSports Invicta Brake & Throttle... - Page 11 Ø6,4 diameter. It is also compatible with the included M6 slot nuts. The Asetek SimSports Invicta pedals are designed to withstand an extreme amount of force. Therefore, it is paramount that you install them on a very rigid base. Ideal conditions are aluminium profile cockpits or a thick metal baseplate (as a minimum, we recommend: 3 mm, steel).
- Page 12 Insert the connection pins in the connection holes of the Place the clutch next to your brake & throttle. clutch Use the guiding pins to align the clutch to the brake and throttle. Insert the guiding pins of the clutch into the holes on the side of the brake &...
- Page 13 Use the four (4) M6x5 set screws from above to secure the 10. Align the holes in the clutch to the two existing mounting guiding pins in place. holes in your sim racing cockpit, if available. Route the cable under the Invicta Brake & Throttle through the bezel and insert the cable to the Invicta Clutch 11.
- Page 14 If there are no holes available or they do not line up, you can use the mounting schematics available here: https:/ /www.asetek. com/simsports/product/invicta-pedals-clutch/ or continue to step 13. 13. Mark the drilling locations. 14. Remove the pedal and drill two (2) Ø6.4 mm holes.
-
Page 15: Adjusting The Pedals
Avoid eye contact with the lubrication grease and wash hands thoroughly after adjustment. track. The Asetek SimSports Invicta Clutch feature multiple mechanical adjustments, that can be made to increase the precision, The setup of the Invicta pedals (clutch and brake & throttle) is how performance, and experienced immersion. -
Page 16: Pedal Face Plate Adjustments
4.2.1 Pedal Face Plate Adjustments Do not use a power drill, as this may damage the screws. Invicta pedal face plates can be adjusted along the X and Y-axis. It will allow the pedals to accommodate a variety of different shoe sizes and increase performance and comfort for anyone using the pedals. -
Page 17: Clutch Pedal Angle Adjustment
4.2.2 Clutch Pedal Angle Adjustment To make sure your pedals are set up just the way you like them, the Invicta Clutch pedal offer the possibility of adjusting the angle of the pedal. The adjustment is a simple process. Simply follow the instructions below: You can adjust the pedal stops on the clutch pedal by loosening the locking thumbnut... -
Page 18: Clutch Preload Adjustment
4. Recalibrate your clutch in RaceHub (see section 5.3 Pedal Calibration) We suggest that you have the brake pedal arm tilted a bit more forward that the throttle and clutch, as in a real car. Imagine driving a race car and things go wrong and you are losing your car, you would rather press the brake than the throttle to avoid a potential crash. -
Page 19: Clutch Travel Distance Adjustment
4.2.4 Clutch Travel Distance Adjustment Turn the uppermost thumbnut counterclockwise to retighten it, locking the bottom thumbscrew in its position. The clutch can have its travel distance adjusted. This allows you to set a new pedal stop of your clutch pedal – essentially reducing the distance of activation and the feeling of resistance as you move through less of the available spring distance. -
Page 20: Change Clutch Pedal Curves
Use an allen key to adjust the height of the allen screw. The clutch often has a light force at end of the travel before the pedal kicks back. The Asetek SimSports Invicta Clutch allow the end-user to switch between different the force curve settings. - Page 21 Each individual curve tells mechanically when you hit the real bite-point feeling, which is reached at the peak of the increase, before the curve declines again. The Y-Axis describes the force required, and X-axis describe the travel.
- Page 22 These options give you the power of determining, which force Remove the clutch pivot pin and bushing to release the curve suits you the best, to get fastest out of the grid. clutch tension spring. To adjust the clutch curve: Loosen the spring tension locknut completely.
-
Page 23: Adjust Clutch Pivot Bracket
4.2.6 Adjust Clutch Pivot Bracket Re-insert the bushing and pivot pin through the pivot bracket and clutch tension spring. You can choose to have the clutch pivot in two positions. As Lock the clutch pivot pin in place with the spring locking default, the pivot bracket is mounted in the most forward pins. - Page 24 Lift the rod. Align the pivot bracket with the adjacent holes underneath the baseplate. Screw the four screws underneath the baseplate back into the pivot bracket. Unscrew the four screws underneath the clutch baseplate. Make sure to have the pedal angle in the most backwards position (see section 4.2.2.) Lower the rod and re-insert the rod clevis lock pin.
-
Page 25: Start Racing
5. RaceHub Adjustments Please be aware that edges on the rod clevis can be sharp. All Asetek SimSports products come with an extremely powerful yet easy-to-use piece of software that we have developed from the ground up. It is called RaceHub and will take care of your every need. -
Page 26: Racehub Updating
5.3 Pedal Calibration RaceHub will automatically notify you if there are available updates. If you want to double-check, please go to www.asetek. com/simsports/racehub and download the newest version. To ensure your pedals are as precise as they can be, you should run the pedal calibration wizard in RaceHub. -
Page 27: Deadzone Adjustments
Follow the on screen instructions of full activation. In the case of a clutch pedal, this would allow you to reach 100% clutch before your clutch pedal reaches full Done! Your calibration will carry over into all the supported activation and the mechanical pedal stop. This preference is games. -
Page 28: Custom Pedal Mapping
We suggest the following settings for deadzone when using the Asetek SimSports Invicta pedals, which is how it is calibrated from our factory. Clutch: Top: 2% Bottom: 2% 5.5 Custom Pedal Mapping One of the great features of RaceHub is the ability to map the curves of your pedals precisely to your liking. -
Page 29: Maintenance
Please note that RaceHub custom pedal maps work best when 6. Maintenance they are used exclusively and without the use of potential in- game settings. If your preferred simulator game offers a pedal mapping feature, we highly suggest you live it as linear and Owning a set of Invicta pedals means a minimum of instead use the functionality in RaceHub. -
Page 30: Spare Parts
7. Troubleshooting 6.2 Spare Parts We strongly advise you only you original Asetek SimSports spare parts. Failure to do so will void your warranty. Sometimes unforeseen issues occur. But do not worry, we are If you have questions, or do not know if you have an original here to help. -
Page 31: Safety
8. Safety The device must not be exposed to rain or humidity to avoid This product contains components that the user cannot • • the risk of fire and electric shock. repair. Opening parts of the product may compromise the safe use of the product and will void the warranty. -
Page 32: Commissioning & Sustainability
All packaging is made out of paper and cardboard. All our If you feel uncertain about how to recycle any Asetek SimSports cardboard and paper products are labeled with the FSC product, we suggest getting in touch with our dedicated mark, ensuring maximum reusability and that the forests are customer support team, who will happily help you. -
Page 33: Production
As such, any waste aluminum is re-used minimizing waste. We, Asetek, as manufacturer, declare that the Invicta products from the brand Asetek, produced in Denmark are tested according to all relevant CE standards/regulations and passed all tests.
