Installation Guide
Item
Qty
H1
4
Locking
Caster
Hex Bolts
H2
4
M8x64mm
H3
12
Washer
Hex Bolts
H4
6
M8x40mm
1. Screw four locking casters (H1) into two bottom posts by hand.
1
2. Connect two vertical posts
to two bottom posts by Hex Bolts (H2)
Description
- 1 -
Item
Qty
H5
6
H6
2
H7
1
H8
1
2
Description
End Cap
Self-tapping
Screw
Wrench
Screwdriver
1
Advertisement
Summary of Contents for Dynamic 91148X72MMAG
- Page 1 Installation Guide Item Description Item Description Locking End Cap Caster Hex Bolts Self-tapping M8x64mm Screw Washer Wrench Hex Bolts Screwdriver M8x40mm 1. Screw four locking casters (H1) into two bottom posts by hand. 2. Connect two vertical posts to two bottom posts by Hex Bolts (H2) - 1 -...
- Page 2 Installation Guide Item Description Item Description Description Locking End Cap Caster Hex Bolts Self-tapping M8x64mm Screw Washer Wrench Hex Bolts Screwdriver M8x40mm 3. Connect top horizontal posts to two vertical posts by Hex Bolts. (H4) 4. Connect bottom horizontal post to two vertical posts by Hex Bolts.
- Page 3 5. Slide the board downward until the board rests on the vertical post's designated notch. 6. Then insert the end caps (H5) into the vertical and bottom posts TO FLIP BOARD: To flip board, rotate knob below the horizontal bar until it disconnects from board.
