SportsPlay Equipment 541-656 Quick Start Manual

541-656 Adjustable Basketball Backstop
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
equipment must be installed in accordance with these instructions.
Check your shipment against Bill of Lading and Parts list.
or broken parts must be reported to your distributor within 10 days of
receipt of your order.
equipment will give many years of Safe, Trouble-Free use.
check for loose or broken parts.
broken parts must be replaced as they can possibly create dangerous
situations leading to unnecessary accidents.
1 CTN 1
1 533-217
1 545-902
1 CTN 1 543-002
1 PIPE 1 543-550
1 PIPE 1 543-551
2 CTN
SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
Aluminum Backboard
When properly installed and maintained,
PACKING LIST
Hardware Bag
Official Goal
Nylon Net
Aluminum Backboard
Adjustable Bracket
Pipe 3 ½" OD x 13' Long
2 PIPE 4 TOTAL PCS
IMPORTANT
Loose bolts must be tightened and
1 105-018
2 196-803
4 116-606
4 316-601
4 216-601
1 416-400
1 116-618
1 226-601
150 # Weight
Page 1 of 1
Rev. 01/10/03
All
Any missing
Periodically
HARDWARE BAG
3 ½" Pipe Plug
½" x ¾" Socket Set Screw
3/8" x 1 ½ Hex Head Bolt
3/8" Flat Washer
3/8" Hex Nut
¼" Socket Key
3/8" x 4 ½" Hex Head Bolt
3/8" Lock Nut
Class 70
