USER'S MANUAL
HDVR 6000
HDD VIDEO RECORDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dolby Laboratories 6000

  • Page 1 USER'S MANUAL HDVR 6000 HDD VIDEO RECORDER...

  • Page 2: Safety Instructions

    I. SAFETY INSTRUCTIONS Read all the safety instructions before first use of your HDD video recorder. POWER SOURCE You should only plug the appliance into a 100V to 240VAC, 50Hz supply. Safety considerations Position the power supply lead and other leads so that they are not likely to be walked on or pinched by things placed on or against them.

  • Page 3: Getting Started

    II. GETTING STARTED CHECK ACCESSORIES Remove your HDD video recorder carefully from the box, You may wish to store the packaging for future use. In the box Included in this package should be: Table 1 HDD video recorder Remote controller AAA batteries User’s manual Read these instructions before use.

  • Page 4: Table Of Contents

    I. SAFETY INSTRUCTIONS ...1 II. GETTING STARTED ...2 CHECK ACCESSORIES...2 USE REMOTE CONTROLLER ...2 III. FEATURES...4 IV. PLAYABLE DISCS...5 V. BEFORE OPERATION ...6 VI. PRECAUTIONS FOR DISCS ...6 VII. PREPARATIONS BEFORE OPERATION...7 REFERENCE DRAWING FOR BACK SIDE ...7 REFERENCE DRAWING FOR FRONT PANEL...8 REFERENCE DRAWING FOR DISPLAY WINDOW ...8 REMOTE CONTROLLER BUTTON LAYOUT...9 REFERENCE DRAWING FOR CONNECTIONS ...10...

  • Page 5: Features

    III. FEATURES 1. MULTIPLE FUNCTIONS Combines the functionalities of DVD player and HDD Recorder. 2. HDD RECORDER a. TIME-SHIFTING Time-shifting recording using the HDD (Play and record at the same time); b. PLAY/RECORD AT SAME TIME Play external DVD and record on the HDD at the same time;...

  • Page 6: Playable Discs

    IV. PLAYABLE DISCS Table 2 TYPE MARK Super-VCD CD-R CD-RW Kodak Picture Cd Notices: MARK INDICATION DVD- functions of DVD SVCD- functions of Super-VCD VCD- functions of VCD CD- functions of CD THIS UNIT IS SET TO PLAY REGION 2 DISCS FOR THE UK AND EUROPEAN MARKETS.

  • Page 7: Before Operation

    V. BEFORE OPERATION SECURITY Before operation, check if the voltage of the unit is in line with the local voltage. Hold the plug to disconnect it from the mains outlet. Do not pull the power cord. When the plug of the unit is connected to the mains outlet, the unit will be still connected to AC even of the power is turned off.

  • Page 8: Preparations Before Operation

    VII. PREPARATIONS BEFORE OPERATION REFERENCE DRAWING FOR BACK SIDE Apparatus Claims of U.S. Patent Nos. 4， 631， 603; 4， 577， 216; 4， 819， 098， and 4， 907， 093 licensed for limited viewing uses only. 1. VIDEO OUTPUT 2. 5.1-CH SURROUND AUDIO LEFT TRACK OUTPUT JACK 3.

  • Page 9: Reference Drawing For Front Panel

    REFERENCE DRAWING FOR FRONT PANEL 1. POWER BUTTON 2. EARPHONE JACK 3. VIDEO IN PUT 4. AUDIO LEFT TRACK INPUT JACK 5. AUDIO RIGHT TRACK INPUT JACK 6. DISPLAY WINDOW 7. STANDBY INDICATOR 8. OPEN/CLOSE DISC TRAY BUTTON 9. DVD/HDVR CONVERT BUTTON REFERENCE DRAWING FOR DISPLAY WINDOW 1.

  • Page 10: Remote Controller Button Layout

    REMOTE CONTROLLER BUTTON LAYOUT 1. OPEN/CLOSE BUTTON 2. POWER BUTTON 3. REPEAT PLAYING BUTTON 4. DIGEST BUTTON 5. TITLE BUTTON 6. PROGRAM PLAYING BUTTON 7. A-B REPEAT BUTTON 8. ANGLE BUTTON 9. SUBTITLE BUTTON 10. VIDEO MODE 11. GOTO BUTTON 12.

  • Page 11: Reference Drawing For Connections

    REFERENCE DRAWING FOR CONNECTIONS Turn off all equipment before operation. The unit has many kinds of output modes like VIDEO output, S-VIDEO output and digital signal output (OPTICAL, COAXIAL) and SCART output. You may select, as you need. This platform can also be integrated into high-end TV products such as Digital TV, HDTV, Back-Panel or Plasma-TV. CONNECTING TO POWER SUPPLY CONNECTING TO TV SET A.
  • Page 12 B. VIA VIDEO CABLE AND DIGITAL CABLE Connect CVBS or S-Video to TV set, connect Coaxial or Optical to Amplifier. C. VIA AV RCA CABLE Figure 12 Figure 13 -11-...
  • Page 13 CONNECTING AV INPUT DEVICE A. VIA SCART CABLE B. VIA AV RCA CABLE (AV1) C. VIA AV RCA CABLE (AV2) -12- Figure 14 Figure 15 Figure 16...
  • Page 14 CONNECTING CABLE TV Notes: During HDVR's shut-down, cable TV signal is by-passed to TV set via TV tuner outport. CONNECTING HEADPHONE Figure 17 Figure 18 Figure 19 -13-...

  • Page 15: Dvd Player Operations

    VIII. DVD PLAYER OPERATIONS PLAY DISCS 1. Connect the player with TV set according the indication in Figure 11, Figure 12 or Figure 13. 2. Push POWER on the TV, switch to AV mode (TV). 3. Connect the player to the power supply according to Figure 10.
  • Page 16 REPEAT Repeat play function. Use cursor to the icon, use ENTER to select required repeat play function. a. Repeat a chapter. Push REPEAT or use , the screen shows: b. Repeat a title Push REPEAT again or use c. Repeat a disc Push REPEAT again or use d.
  • Page 17 audio channel, press ENTER to confirm the selection. Three play modes are available: Sequential, Programmed and Random. When PBC is “ON”, the system will display the menu of VCD, use digit key to select what you like. When PBC is “OFF”, system will be in sequential play mode.

  • Page 18: Volume Control

    REPEAT Repeat play function. Use cursor to the icon, use ENTER to select required repeat play function, and to confirm the selection. a. Repeat a chapter. Push REPEAT or use , the screen shows: b. Repeat a disc Push REPEAT again or use c.

  • Page 19: Fast Play

    1. Push to enter the next menu. ROOT 12.------- MENU 13.------- 14.------- 15.------- 2. Push digit buttons to select directly. Pressing 10+ one time means adding 10. If select tracks greater 19, please press 10+ twice, and then press 1 to 9 button.

  • Page 20: Repeat Playback

    of three indicator: Time, File name, Play mode indicator. 4. Press the RETURN on the remote control handset to return to top panel when the cursor locates in bottom panel. 5. Scroll up and down through files or folders using the UP/DOWN cursors on the remote control 6.

  • Page 21: Hdd Recorder Operation

    IX. HDD RECORDER OPERATION You can record TV program and other A/V program by connecting cable TV or other A/V device output to HDD recorder. RECORD TV PROGRAM If you want to record a chapter when you are watching Push RECORD to begin record. The screen show: RECORD 00:00:00 CH 26 Push STOP If you want to finish this record at once.

  • Page 22: Play/Edit Program List Hdd

    “AV INPUT 1”（ref Figure 15）. Push RECORD to begin record. The screen show: RECORD 00:00:00 Push STOP, if you want to finish this record. Now, the record is over. The same way to AV2 and SCART IN recording. Notes: 1. During recording, you can not change the television channel or navigate CD / MP3 / video discs.

  • Page 23: Function Setting

    X. FUNCTION SETTING According to the recorded information and external equipment, set the following functions for HDD video recorder to obtain the best playing status. Push SETUP to enter the main menu. SETUP The screen shows: MAIN PAGE SETTING EXIT ush SETUP or go to EXIT toexit from the main menu.

  • Page 24: Dvd Setup

    PVR SETTING PAGE DATE/TIME SETUP HDD MANAGER RECORD QUALITY TIME SHIFTING POWER ON MODE SETTING AUTO OVERLAY RETURN EXIT Select “system info”, the screen show the hard disk information. Select “scan disk”, check the hard disk, and reconstruct the hard disk if there is bad sector detected.

  • Page 25: Video System

    AUDIO SETUP PAGE ANALOG OUTPUT DIGITAL OUTPUT RETURN SETTING EXIT ANALOG OUTPUT AUDIO SETUP PAGE ANALOG OUTPUT DIGITAL OUTPUT RETURN SETTING EXIT 2 CHANNEL: Down Mix to left and the right track as output. 5.1 CHANNEL: Switch to 5.1channel output: left, Right, Rear Left, Rear Right, Center and Subwoofer.

  • Page 26: Main Setting

    MAIN SETTING to move the cursor and select “SETTING”. MAIN SETTING PAGE OSD LANGUAGE TV CHANNEL PICTURE SETUP DEFAULT RETURN SETTING EXIT OSD LANGUAGE SETUP to move the cursor and select “OSD LANGUAGE SETUP”, the screen show: MAIN SETTING PAGE OSD LANGUAGE TV CHANNEL PICTURE SETUP...

  • Page 27: Troubleshooting

    XI. TROUBLESHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. No sound Check if the unit is connected securely. Make sure you operate the TV or amplifier correctly. Make sure you have selected HDD video recorder position on the amplifier.

  • Page 28: Technical Specifications

    XII. TECHNICAL SPECIFICATIONS HDD DIGITAL RECORDER Table 3 FUNCTION RECORDING FORMAT OTHER RECORDING TIME LENGTH Play Fast Forward Fast Backward Switch between video record and DVD play modes Switch Video inputs (TV, A/V1, A/V2, SCART) PVR Status Display Stop Schedule recording Time shifting Timer Audio...

  • Page 29: Dvd Player

    Weight Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
