Summary of Contents for Swift CRUZE SDB-CVTB0970
- Page 1 VERTICAL BLINDS FITTING INSTRUCTIONS...
- Page 2 YOU SHOULD HAVE STEP 1 STEP 2 THE INSTALLATION OF THIS TOP FIXING PRODUCT SHOULD BE Measure and mark the distance CONDUCTED BY SOMEONE (D), allowing for obstructions like COMPETENT IN DIY. handles that protrude into the recess area. Hold each bracket into place and mark the hole positions.
- Page 3 STEP 3 STEP 4 STEP 5 RETAINING DEVICE TOP FIXING SAFETY DEVICE Screw the retaining device using Tilt and hook headrail into bracket The safety device must be installed at suitable fixings ensuring the device at point (E). Rotate the headrail into the maximum distance possible from is fully closed.
- Page 4 LOUVRE BLIND TROUBLESHOOTING TRAVELLERS NOT ALIGNED STEP 3 STEP 1 STEP 2 At this point you will need to pull on Travellers should start to align. Pull on chain until the chain with force. You will hear a completely restricted. grinding noise - this is normal.
- Page 5 LOUVRE BLIND TROUBLESHOOTING WHEN I PULL THE CONTROL CHAIN THE LOUVRES WON’T TURN STEP 1 STEP 2 STEP 3 Louvres are jammed/not rotating. Pull the control chain. Do runners rotate normally? If yes, return the runners to the open position and add the louvres. Pegs should be turned perpendicular to the headrail.
- Page 6 PLEASE READ THE INSTRUCTIONS BEFORE OPERATING THIS PRODUCT WAND OPERATION-DRAW WAND OPERATION-TILT Use the wand to draw the slats to either end of the blind. Twist the wand to tilt the slats in either direction to the open/closed position. If any of the slats are out of alignment, twist the wand control until the slats are in the closed position, then continue to twist the wand until all the slats are fully aligned.
