Dometic GROUP SeaLand VacuFlush HTS-VG Owner's Manual

Holding tank system

Advertisement

Quick Links

SeaLand
®
HOLDING TANK SYSTEM
OWNER'S MANuAL
VacuFlush
HTS-VG Models (with vacuum generators)
®
Standard HTS-T Models (with discharge pump only)
Basic HTS Models (with fittings only)
WARNING
!
This manual must be read and under-
stood before installation, adjustment,
service, or maintenance is performed.
Modification of this product can
result in property damage.
Dometic Corporation, Sanitation Division
13128 State Rt 226, PO Box 38
Big Prairie, OH 44611
SeaLand Product Customer Service: 1-800-321-9886
www.Dometic.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SeaLand VacuFlush HTS-VG and is the answer not in the manual?

Questions and answers

Summary of Contents for Dometic GROUP SeaLand VacuFlush HTS-VG

  • Page 1 SeaLand ® HOLDING TANK SYSTEM OWNER’S MANuAL VacuFlush HTS-VG Models (with vacuum generators) ® Standard HTS-T Models (with discharge pump only) Basic HTS Models (with fittings only) WARNING This manual must be read and under- stood before installation, adjustment, service, or maintenance is performed. Modification of this product can result in property damage.
  • Page 2 TABLE OF CONTENTS SeaLand HTS Benefits ......2 HTS Components ......6 Installation .
  • Page 3 INSTALLATION CHOOSING A LOCATION FOR THE HTS As a general rule, the HTS should be positioned as low in the hull as possible with all interconnecting hoses or pipes sloped to permit gravity drainage and prevent potential hose odor permeation. The holding tank must not be exposed to temperatures above 120°F (45°C).
  • Page 4 INSTALLATION (cont’d) PLuMBING CONNECTIONS AND HOSE LAYOuTS When connecting flexible hose to plastic fittings, use liquid dish soap on end of fitting and inside hose end to make connection easier. Do not use any other lubricants, sealants or adhesives when connecting sanitation hoses and fittings. Do not restrict the ability to pull the hose or pipe.
  • Page 5 INSTALLATION (cont’d) VENT LINE AND FILTER INSTALLATION • Holding tank vent lines must be free of low points which can trap liquid and prevent the free flow of gases from or air into the holding tanks. • Do not use non-reinforced hose for vent lines. Over time, it will tend to kink and effectively block the vent.
  • Page 6 HTS COMPONENTS TankWatch 4 Level Monitor and Micro-Float ® Switches* I n c l u d e s f o u r t a n k levels – Empty, Low, Mid and Full. Micro-float switches are installed in holding tank. No electri- cal components contact waste or water.
  • Page 7 PLuMBING FITTINGS, HOSE AND PIPE SeaLand valves and fittings are designed for use with 1-1/2" (38mm) ID OdorSafe Plus sanitation hose and ® ® 1-1/2" (38mm) ID PVC pipe. HOSE BALL VALVE Part No. DescriPtioN 307346087 307346087 Ball Valve Non-corrosive PVC with Teflon seals.
  • Page 8 Dometic Corporation, Sanitation Division Dometic Group supplies a wide range of workshop equipment for 13128 State Rt 226, PO Box 38 service and maintenance of built-in air conditioners. Dometic Group...

This manual is also suitable for:

Sealand standard hts-tSealand basic hts
