IP POWER 9258 USER MANUAL
IP POWER 9258

USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP POWER 068420 and is the answer not in the manual?

Questions and answers

Summary of Contents for deXlan IP POWER 068420

  • Page 1: User Manual

    IP POWER 9258 USER MANUAL IP POWER 9258 USER MANUAL...
  • Page 2 IP POWER 9258 USER MANUAL USER MANUAL IP POWER 9258 Version: V1.34 2006.03 - 1 - VER. X.X,...
  • Page 3 Warning: Any changes to this equipment without permission may cause damages to your equipment! This equipment has been proved by CE & FCC to can be prevented from the influence of harmful electronic jamming in normal business use condition. 1. We have no responsibility for the possible damage caused by improper usage or abnormal working environment.

  • Page 4: Table Of Contents

    Table of Content 1. INTRODUCTION...4 FEATURES 9258 FUNCTION DESCRIBE 2.SPECIFICATION...5 PACKAGE ONTENTS MINIMUM YSTEM EQUIREMENTS 3.INTERFACE DESCRIPTION ...6 4.HARDWARE & SOFTWARE INSTALLATION...7 HARDWARE INSTALLATION SOFTWARE INSTALLATION 5. INITIAL SETTING ...8 INITIAL SETTING THROUGH ETHERNET READ MESSAGE FROM RS SERIAL 6. CONTROL AND SETTING THROUTH THE INTERNET EXPLORE... 10 LOGIN CONTROL THE POWER SUPPLY OF OUTLETS ……………………………………………………………...

  • Page 5: Introduction

    1. Introduction IP POWER 9258 is a web controller which can be easily used in the industry field. With the remote network control technology, user can control or query the power supply of equipment. User can do this in any computer connected to the internet or local area network, there is no special program needed, also there is no need to open the external case of the computer.

  • Page 6: Package Contents

    WINDOWS operating system (IE5.0+SPI) & LINUX Minimum 64MB RAM VGA Card: supported direct draw Network card with RJ45 port & Ethernet HUB or Switcher Internet network (Ethernet, ADSL or other ways, depends on whether you need far end control ability or not) NOTICES: 1.

  • Page 7: Interface Description

    IP POWER 9258 USER MANUAL 3. Interface Description IP Power 9258 Front interface shown below: From left to the right 1. RESET: self-protect AC reset button. IP Power 9258 can cut off the power supply of outlets automatically if there is a shortcut or current overload. After user having solved the problem, push the reset button, the AC power supply will become normal.

  • Page 8: Hardware & Software Installation

    4. Hardware & Software installation Before you star to use IP Power 9258, please follow the steps below Check the package to make sure the contents is complete. Prepare one Ethernet HUB or Router Check the voltage of the power supply to make sure it is AC 110-240 volt Please confirm the specification of your power cable.

  • Page 9: Initial Setting

    5. Initial Settings Initial setting through the Ethernet 1. Open attached CD and save IPEDIT.exe in to your Hardisk , execute IPEdit.exe 2. All the IP 92XX series, like IP Power 9258 IP Kamera 9000 series/IP Video 9100 series in the same subnet of the Ethernet will be found and be display in the window by the software.
  • Page 10 2. IP Power 9258’s default setting is fixed IP address: 192.168.10.100. The IP address of your computer should in the same subnet with that of IP Power 9258’s, so that you can open the control web page. In the figure above, the IP address of IP Power 9258 is 192.168.100.168.

  • Page 11: Control And Setting Throuth The Internet Explore

    IP POWER 9258 USER MANUAL 6. Control and settings through the Internet Explore) Type the new IP address of IP Power 9258 in the address field and you can enter the login web page. Input the default password 12345678, or the password set by you, click OK, and you can then enter the Web Control page.

  • Page 12: Power Supply State Query

    IP POWER 9258 USER MANUAL Power Supply State Query Click the “ Set Power” button on the left, the page will be refreshed. The state of each electric outlet will be displayed in column control. System Settings of 9258 User can set the password, IP address, e-mail address, timer setting, online firmware update, and the time of 9258 through the system settings.
  • Page 13 * Http Command Verification : setup the control possibility from HTTP command or SDK (VB & VC) 1. Select “ Cookie +Base64 “ : enable Http command & SDK control 2. Select “ Cookie “ : enable Http command & SDK control 2-1 IP address Settings: Ethernet (LAN ) and Internet(WAN) 2-1-1 Local Area Network (LAN) : In LAN, you can set a fixed IP address or gain it from a DHCP server automatically.

  • Page 14: Email Settings

    3. EMAIL SETTINGS: When you finished the e-mail settings, you can set to let IP Power 9258 send its IP address automatically. For example: * Mail Server: abc.com * Pop3Servcer : cdef.com * Password : XXXXXXXX * Sender: 123@abcd.com * Receiver 1: 456@abcd.com * Receiver 2: 789@efgh.com * Receiver 3: * Subject: 9258 IP address...

  • Page 15: Setup Up Own Outlet Default Status

    4. Control the IP Power 9258 through Time Schedule : User can control the time when 9258 starts or stop through preset time schedule. Click the power schedule on the left of the page; you can select enter the time schedule setting If user wishes to control the power in one outlet of IP Power 9258, you can fill in the time in the power control column and choose on or off.

  • Page 16: Wake On Lan

    (2) Your network card must support “WOL”, remember to connect your connect cable to Main board or the network card can not send “power on” message to your main board. After setup in main board and network card , you can use WOL function by following two step: Step 1: Log in 9258 web page and go to “Network Wakeup”...
  • Page 17 Note: 1. If the Network card is not onboard card, it needs to connect with your Main board by cable. Please refer your network card connection 2. You can get your MAC address in PC , please refer following pictures :...

  • Page 18: Gprs For Cell Phone : Support Wap

    IP POWER 9258 USER MANUAL 8. GPRS for Cell Phone : Support WAP. IP POWER 9258 support GPRS function, you can use cell phone (with online function), We support : Motorola V878 , Sony Ericsson T630 & K700i. . To setup the online device ( real IP address) as operate in browser .: 1) Address setting : key in your online IP address.
  • Page 19 IP POWER 9258 USER MANUAL 7. Check 9258 status though SNMP 9258 support SNMP V1 and V2 , user can use snmp program to get the status of each port in 9258. - 18 -...

  • Page 20: Control And Settings Through Http Order

    8. Control and Settings Through HTTP Order User can control the 9258’s action directly though the HTTP orders. The format of the HTTP order is : http://username:password@XXX.XXX.XXX.XXX/Set.cmd?CMD=***Power+para1=*+p ara2=*+para3=*…… Explanations of each part of the order: Username : 9258’s username, default username is admin Password : 9258’s password, default password is 12345678 XXX.XXX.XXX.XXX the IP Address of 9258 CMD=***Power : the function module of 9258...
  • Page 21 IP POWER 9258 USER MANUAL * Schedule Control : User can use Http command to arrange the 9258 operation in specific time ，http command format as follow: http://username:password@XXX.XXX.XXX.XXX/Set.cmd? CMD=SetSchedule+Power=**+YY=****+MM=**+DD=**+HH=**+MN=**+SS=**+PARAM =****+ONOFF=* Explanations of each part of the order: Username : 9258’s username, default username is admin Password : 9258’s password, default password is 12345678 XXX.XXX.XXX.XXX the IP Address of 9258 Power=** setting of each parameter...

  • Page 22: Faq

    9. FAQ Q1: I forgot the password and can not enter the administration page now, what can I do? A1: Use username " super user " when log in webpage and then click "OK " turn power off for few second and then turn on ON . 9258 will to set back to default password.
  • Page 23 IP POWER 9258 USER MANUAL Step 2 : Open amend webpage “ipcontrol “ html file : Step 3. Amend webpage by HTML langrage( get from right click as in amend webpage”): Step 4 :Save file format as “UNIX” : Like choose “DOS to UNIX - 22 -...
  • Page 24 IP POWER 9258 USER MANUAL Step 5. After amend the other 9258 webpage you plan to amend . Please open program “Make9258Html “ in 9258 web page SDK and just press” make html patch”. Step 6 . There will be a new file “ Update_2006-01-11.bin” which is the BIN file include the amend webpage.
  • Page 25 IP POWER 9258 USER MANUAL Note: program “Make9258Html.exe “ and amend webpage must in same file. * If update fail and can not get IP address by IP EDIT , please use RS232 jack ( DB 9 Cable) connect with the PC and 9258, and you can get IP address to log-in and update again.
  • Page 26 6. Use this IP address to update again. We supply original firmware V1.22 for update f 7. Log tin this address to update again. 8. If still can not finish update successful, please check if create BIN file too big . If need to ship BIN file, please use bin file V1.22.bin in SDK to update back to factory version.
