Philips HR2730 User Manual

Register your product and get support at
www.philips.com/welcome
HR2730
HR2732
HR2734
EN User manual
UK
RU
Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
1/2
3140 035 29081
HR2730_2732_2734_CEE1_UM_V1.1
English
1 Important
Read these instructions for use carefully before using the appliance and save them for future
reference.
Danger
Do not immerse the motor unit in water nor rinse it under the tap.
Do not connect the appliance to a timer switch.
Warning
Before you connect the appliance to the power, make sure that the voltage indicated
on the bottom of the appliance corresponds to the local power voltage.
If the power cord, the plug, or other parts are damaged, do not use the appliance.
If the power cord is damaged, you must have it replace by Philips, a service center
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
For their safety, do not allow children to play with the appliance.
Be very careful when you handle the cutter, especially when you remove it from the
worm shaft and during cleaning. The cutting edges are very sharp!
Before you remove any accessory, switch the appliance off and unplug it.
hopper while the appliance is running. Only the pushers are to be used for this
purpose.
Caution
The appliance is intended for household use only.
Before you connect the appliance to the mains, make sure that the appliance is
assembled correctly.
Never use any accessories or parts from other manufacturers or that Philips does not
invalid.
Always switch the appliance off by turning the switch knob to .
Do not let the appliance run unattended.
Do not exceed the maximum operating time of 4 minutes under heavy load
applications.
Noise level: Lc = 87 dB [A]
Safety system (Fig. 6 and Fig. 7)
This appliance is equipped with overheat protection. If the appliance overheats, it switches
off automatically. Unplug the appliance and let it cool down until room temperature. Then,
put the mains plug back into the power outlet and switch on the appliance again. Please
contact your Philips dealer or an authorized Philips service center if the overheat protection
is activated too often.
HR2730 is equipped with mechanical protection. To protect the motor, the plastic gear has
been designed to break if bones or utensils are fed into the appliance. When this happens,
simply remove the broken gear and replace with the extra gear (Fig. 6).
In case the appliance is overloaded, it automatically activates the overload protection and
switches off. If this occurs, set the switch knob to , unplug the appliance and let it cool
down for 15 minutes. Remove the residue inside the hopper and then press the overload
reset button on the bottom of the motor unit (Fig. 7).
handled properly and according to the instructions in this user manual, the appliance is safe
Recycling
Your product is designed and manufactured with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means the
product is covered by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform yourself about
the local rules on the separate collection of electrical and electronic products. The correct
disposal of your old product helps prevent potentially negative consequences on the
environment and human health.
All manuals and user guides at all-guides.com
1
c
a
b
e
d
A
B
C
k i
j
h g f
A
o
A
B B
p
l m n
A
q
B
r
HR2732 HR2734
(HR2732, HR2734)
(HR2732, HR2734)
(HR2730)
(HR2730_MEA,
HR2732, HR2734)
(HR2732
2 Introduction
that Philips offers, register your product at www.philips.com.
With this meat mincer, you can
mince meat
make sausages
make kebbe (HR2730 Middle East Asia, HR2732 and HR2734 only)
Tip
For more recipes, go to www.kitchen.philips.com.
3 What's in the box (Fig. 1)
Hopper release button
a
Press and hold it when you remove the hopper.
b
Switch knob for power and reverse modes / /
c
Switch off ( ) or on ( ) the meat mincer.
Switch to to reverse the motor.
Power cord
d
Pusher for the metal hopper
e
f
Extra gear for the worm shaft (HR2730 only)
g
Worm shaft
h
Cutter/Knife
i
Hygienic stainless steel grinding discs
j
A: Coarse grinding disc (diameter of 8 mm)
B: Medium grinding disc (diameter of 5 mm)
C: Fine grinding disc (diameter of 3 mm) (HR2732 and HR2734 only)
Screw ring
k
Sausage horns
l
A: Large sausage horn (diameter of 22 mm)
B: Small sausage horn (diameter of 12 mm)
Sausage separator
m
n
A: Kebbe separator
B: Kebbe shaper
o
p
q
Innovative cleaning tool
r
A: HR2730 only
B: HR2732 and HR2734 only
Before you start, make sure you assemble according to Fig. 2-1.
For disassembly, refer to Fig. 3-1.
Note
Never grind bones, nuts, or other hard items.
Do not overload the appliance by pushing too much meat into the hopper.
Depending on the granularity of minced meat, select the proper grinding disc. You can also
grind for more than one time.
2
2-1
2-2
2-3
5
HR2730
Tip
Remove bones, gristle, and sinews out of the meat as much as possible.
If the hopper is blocked, switch to to reverse the motor and clear the leftover meat.
Recipe
Pozharskie Kotleti (Chicken cutlets)
Yield: 4 servings
Ingredients:
450 g chicken breast or readily ground chicken
200 g plain wheat bread
120 ml warm milk
6 Tbsp. unsalted butter
1/2 tsp. salt
1/8 tsp. black pepper
1/2 cup of bread crumbs, use more if needed
1 clove of minced garlic (optional)
15 ml vegetable oil (optional)
100 g mozzarella or Muenster cheese, cut into 5 cm long, 1.3 cm wide strips (optional)
Directions:
1
Soak the bread in warm milk for several minutes.
2
3
Mince the mixture of minced bread and chicken.
5
Add salt and pepper (as well as the minced garlic if you like) into the mixture, and then
thoroughly mix the ingredients.
6
Soak your hands in water, and then grab a portion of the mixture equal to the size of a
tennis ball. Cover a piece of cheese in the mixture, and shape it into a patty. Make sure
that the cheese is not exposed.
7
Coat the patty with bread crumbs.
8
Over medium-low heat, melt the butter, and then fry the patty on each side for three
minutes, or until it turns golden brown in the melt butter.
9
Bake the fried patties in the oven (preheated at 177°C) for 15 minutes.
10
Serve the patties with your favorite side course.
Before you start, make sure you assemble according to Fig. 2-2.
For disassembly, refer to Fig. 3-2.
Note
Do not block the air outlet grooves of the sausage horn.
Do not make the sausages too thick in case the sausage skin is overstretched.
Keep the sausage skin wet to prevent it from sticking on the sausage horn.
Recipe
Sausages
Ingredients:
4,500 g ground pork
5 Tbsp. of salt
1 Tbsp. of ground white pepper
2 Tbsp. of rubbed sage
1 tsp. of ginger
1 Tbsp. of nutmeg
1 Tbsp. of thyme
470 ml ice water
1 Tbsp. of ground hot red pepper
Directions:
1
Mince the meat with the coarse grinding disc.
2
Thoroughly mix the minced meat and other ingredients.
3
Follow the instructions in the section " " to make your own sausages.
3
3-1
3-2
3-3
6
HR2730
7
Before you start, make sure you assemble according to Fig. 2-3.
For disassembly, refer to Fig. 3-3.
Recipe
Kebbe
Yield: 5-8 servings
Ingredients:
Outer casing
500 g lamb or fat-free mutton, cut into strips
500 g bulgur wheat, washed and drained
1 small onion
Filling
400 g lamb, cut into strips
15 ml oil
5-10 ml ground allspice
salt and pepper
Directions:
Outer casing
1)
2) Thoroughly mix the minced ingredients, and then mince the mixture twice again.
3) Use the kebbe maker to shape the mixture into kebbe casing.
Filling
1) Mince the meat with the medium grinding disc.
2) Fry the onion chops until they turn golden brown.
3) Add the minced meat and other ingredients in, and then cook for 1-2 minutes.
Cooking
1)
2) Heat the oil for deep frying (190°C).
3) Deep fry the kebbe for 3-4 minutes, or until it turns golden brown.
into contact with food.
Before you remove accessories or clean the motor unit, switch off and unplug the
appliance.
Do not immerse the motor unit in water nor rinse it under the tap.
Do not clean the metal parts in a dishwasher.
Clean the main unit with a moist cloth.
Pass pieces of bread through the cutter housing to remove any meat left.
Wash removable parts with a soft brush in soapy water, rinse them with clear water,
and then dry them with soft cloth or tissues immediately.
Lightly brush the metal parts with fat or oil to prevent rusting.
Tip
Use the innovative cleaning tool to remove the remains stuck in the grinding discs. rinse them
with clear water, and then dry them with soft cloth or tissues immediately.
8 Replace the gear (HR2730 only) (Fig. 6)
One extra gear is bundled with the product. If the original gear is broken, replace it with the
extra one.
