crescendo EVOLUTION THREE 3A6 Instruction Manual

Hide thumbs

Advertisement

Available languages

Available languages

Quick Links

Download this manual
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVOLUTION THREE 3A6 and is the answer not in the manual?

Questions and answers

Summary of Contents for crescendo EVOLUTION THREE 3A6

  • Page 2 INDONESIA POWER BERKUALITAS TINGGI Penguat suara CRESCENDO tipe EVOLUTION THREE 3A6 hanya menyediakan POWER BERKUALITAS TINGGI. Tidak ada fitur pembatas frekuensi aktif, penguat nada rendah, ataupun penyetelan fase. Apabila pengguna menghendaki fitur seperti itu, pengguna bisa mendapatkannya dalam versi digital yang jauh lebih fleksibel dan sempurna.
  • Page 3 UKURAN SEKRING Penguat suara CRESCENDO tipe EVOLUTION THREE 3A6 dilengkapi dengan sekring berukuran 30 Ampere sebanyak 2 buah. Pengguna tidak diperkenankan mengganti nilai sekring ini dengan tujuan apapun. KONEKSI KABEL RCA Penguat suara CRESCENDO tipe EVOLUTION THREE 3A6 hanya menerima signal tingkat rendah dari pemutar CD atau pemroses signal.
  • Page 4 KONEKSI KABEL POWER Gambar 2...
  • Page 5 KONEKSI KABEL POWER Gambar 3...
  • Page 6 KONEKSI KABEL POWER Gambar 4...
  • Page 7 AWG untuk performa yang terbaik. Ukuran kabel pengeras suara maksimum yang dapat AWG untuk performa yang terbaik. Ukuran kabel pengeras suara maksimum yang dapat diterima oleh CRESCENDO tipe EVOLUTION THREE 3A6 adalah 8 AWG. KONEKSI KABEL PENGENDALI Kabel pengendali tidak sepenting kabel lain. Tetapi, pilihlah kabel dengan pembungkus yang enting kabel lain.
  • Page 8 1 input dan 2 buah pengeras suara nada rendah dalam konfigurasi mono. Lihat Gambar 7. 3. CRESCENDO tipe EVOLUTION THREE 3A6 disambung ke 2 set pengeras suara 2 jalur yang diletakan di depan dan belakang mobil serta 2 buah pengeras suara nada rendah dalam konfigurasi stereo.
  • Page 9 ILUSTRASI PERKABELAN Gambar 6...
  • Page 10 ILUSTRASI PERKABELAN Gambar 7...
  • Page 11 ILUSTRASI PERKABELAN Gambar 8...
  • Page 12 ILUSTRASI PERKABELAN Gambar 9...
  • Page 13 ILUSTRASI PERKABELAN Gambar 10...
  • Page 14 ILUSTRASI KONEKSI KABEL PENGERAS SUARA...
  • Page 15 SPESIFIKASI INFORMASI DETAIL Daya Tercatat (RMS) 6 x 100 Watt pada beban stereo 4 Ohm 6 x 100 Watt pada beban stereo 2 Ohm 3 x 300 Watt pada beban mono 4 Ohm Daya Terukur Pada 12,0 Volt : dengan Beban Dinamik a.
  • Page 16 Penguat suara sangat panas a. Pastikan impedansi pengeras suara tidak dibawah beban minimum penguat suara, yakni 4 ohm mono untuk CRESCENDO tipe EVOLUTION THREE 3A6. b. Pastikan penguat suara mendapatkan sirkulasi udara yang baik. Tambahkan kipas pendingin jika diperlukan.

  • Page 17: Amplifier Mounting

    ENGLISH HIGH QUALITY POWER CRESCENDO EVOLUTION THREE 3A6 amplifier only provides HIGH QUALITY POWER. There are no features such as active crossover, bass boost, or phase adjustment. If user ever needs such feature, they are now available in a more sophisticated digital version.

  • Page 18: Power Connections

    FUSE SIZE CRESCENDO EVOLUTION THREE 3A6 is equipped with 2 pieces of 30 Ampere fuse. User is not permitted to change the fuse size for any purpose. RCA INPUT CONNECTIONS CRESCENDO EVOLUTION THREE 3A6 amplifier only accepts low level output from Head Unit or preamplifier or other signal processor.
  • Page 19 POWER CONNECTIONS Figure 2...
  • Page 20 POWER CONNECTIONS Figure 3...
  • Page 21 POWER CONNECTIONS Figure 4...

  • Page 22: Speaker Cable Connections

    We recommend 18 AWG to 12 AWG speaker cable size for best performance. speaker cable size for best performance. Maximum speaker cable size for CRESCENDO EVOLUTION THREE 3A6 is 8 AWG. REMOTE CABLE CONNECTIONS Remote cable is not as important as other cable. But, choose a cable with good isolation to Remote cable is not as important as other cable.

  • Page 23: Wiring Illustration

    2. CRESCENDO EVOLUTION THREE 3A6 is connected to 2 ways speaker system and 2 subwoofers in mono mode. Look at Figure 7. 3. CRESCENDO EVOLUTION THREE 3A6 is connected to 2 sets of 2 ways speaker system and 2 subwoofer in stereo mode. Look at Figure 8.
  • Page 24 WIRING ILLUSTRATION Figure 6...
  • Page 25 WIRING ILLUSTRATION Figure 7...
  • Page 26 WIRING ILLUSTRATION Figure 8...
  • Page 27 WIRING ILLUSTRATION Figure 9...
  • Page 28 WIRING ILLUSTRATION Figure 10...
  • Page 29 SPEAKER WIRING CONNECTION ILLUSTRATION...

  • Page 30: Specification

    SPECIFICATION INFORMATIONS DETAILS Power Rating (RMS) 6 x 100 Watts at stereo 4 Ohm load 6 x 100 Watts at stereo 2 Ohm load 3 x 300 Watts at bridged 4 Ohm load Measured Power At 12,0 Volts : with dynamic load speaker a.

  • Page 31: Troubleshooting

    Check for short circuit on speaker leads. flashing b. Make sure that speaker load is not below amplifier minimum load, 4 Ohm bridged for CRESCENDO EVOLUTION THREE 3A6. PROTECT indicator LED Amplifier needs to be repaired. lights up No sound output a.
