The list of bulk parts
4
×
1
×
注意

Note

本品适用于ZT310-T 19寸辐条轮系列整车,安装前请确认
This product is used in ZT310-T 19" spoke front wheel models,
please confirm before installation.
安装前请核对散件数目
Check the number of bulk pieces before installation.
安装指南仅作参考,请以实际为准
The installation guide is for reference only,please take the actual
information as a guide.
Guide to the installation of the
2
×
1
×
exhibition rack
1
×
1
×

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZT310-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zontes ZT310-T

  • Page 1 × × 注意 Note 本品适用于ZT310-T 19寸辐条轮系列整车,安装前请确认 This product is used in ZT310-T 19" spoke front wheel models, please confirm before installation. 安装前请核对散件数目 Check the number of bulk pieces before installation. 安装指南仅作参考,请以实际为准 The installation guide is for reference only,please take the actual...
  • Page 2 Installation sign 安装提示 Installation tips 安装①胶套时确保胶套套到底 ① 部避免脱落 When installing① sleeve,make sure that the sleeve is covered to the bottom to avoid falling off. 整车摆正后,先将展架长管上的两件 ① × 胶套着地后再将展架对好前轮空心轴 ⑥ (如图3所示),从右侧穿入螺栓⑤, ⑥ × 确保胶垫④在展架圆垫片与前减震器 之间,避免穿螺栓⑤以及装配后划伤 减震器。用12#套筒固定好螺栓⑤后 用14#套筒顺时针锁紧,直到展架圆 垫片刚开始往里变形时停止。顶住展 架胶套外侧面将车辆往前推让展架4件 胶套着地,将螺母③锁紧后将两件橡 胶盖②装好。 ⑤...
