General Information:

®
The Lifestyle
SA-2 or SA-3 stereo amplifier provides you with a simple solution when you want to add Bose
non-powered environmental speakers or Bose non-powered accessory speakers to your Lifestyle
Bose proprietary Integrated Signal Processing technology, featured in the amplifier, provides full, rich stereo
sound, even when the speakers are playing at low volumes. By using the Lifestyle
your system, you can enjoy Bose quality sound and Lifestyle
swimming deck, garage, or utility room.
®
®
The Bose
Lifestyle
SA-2 and SA-3 amplifiers are a zone 2 accessory to the Bose Lifestyle
repair package for installation instructions) and Bose
require an additional RF remote control in order to operate the second zone. This is because the dip switches
located in the remote control must be set differently to control zone 2 (see repair package for settings).
®
Lifestyle
systems that use a PMC/MRI (such as the Lifestyle
control.
Note: The circuit operation described below is for the left channel. The right channel operation is identical. The
designators inside the brackets are schematic sheet grid locations.
Refer to schematic for the following information.
The rear panel of the Lifestyle
DIN. These jacks, along with an audio input cable, part number 272902-220 supplied with the
amplifier, allow the use of the different Lifestyle
installation, see the repair package for the installation to the system you are working with.
®
Bose
link is the proprietary networking technology that allows a Lifestyle
products to provide sound in secondary rooms.

Introduction:

®
The Lifestyle
Stereo Amplifier 2 and the higher power Lifestyle
printed circuit board. The LSA-2 is a depopulated version of the SA-3. The differences between the two
products can be summarized as follows:
Feature
Power output
Amplifier topology
Auxiliary RCA input
Mono/Stereo switch

General Theory of Operation:

Refer to the system block diagram (Figure 1).

Audio Chain:

Audio Input is received at the DIN connector in the form of two separate analog stereo (left and right) channels
(channel 1 and channel 2) from the music center. The LSA-3 has a third audio input, via the left and right RCA
jacks. Channel selection, volume level, and dynamic equalization occur at the volume control IC U3 (the ST
TDA7309). Output from this IC is fed to a differential pre-amplifier stage, and then to the power amplifier IC.
11/22/2005
SA-2 and SA-3 Theory of Operation
®
®
amplifier utilizes two different types of audio input jacks, RCA and
®
music centers. Different Lifestyle
LSA-2
40W/ch
Class AB
No
No
®
system convenience in your yard, patio,
®
speakers. Lifestyle
Systems that use a music center
®
40 and 50) do not require an additional remote
®
system to integrate with other Bose
®
Stereo Amplifier 3 product use the same
LSA-3
100 W/ch
Class G
Yes
Yes
Page 1 of 4
®
system.
®
stereo amplifier to expand
®
systems (see
®
systems require different
27172X-00
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIFESTYLE SA-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bose LIFESTYLE SA-2

  • Page 1 General Information: ® ® The Lifestyle SA-2 or SA-3 stereo amplifier provides you with a simple solution when you want to add Bose ® non-powered environmental speakers or Bose non-powered accessory speakers to your Lifestyle system. Bose proprietary Integrated Signal Processing technology, featured in the amplifier, provides full, rich stereo ®...
  • Page 2 SA-2 and SA-3 Theory of Operation At full volume the frequency response of the system is basically “flat”, over the frequency range from 10 Hz to 15 kHz. At lower volume levels, the dynamic equalizer provides up to 16 dB of bass boost at 50 Hz. A graph of frequency response vs.
  • Page 3 Currently the volume control adjustment is not available to end consumers. Contact your Bose® dealer or call Bose Customer Service for information on installing this feature. See the contact list inside the back cover of the Owners Guide. The output of U1 is AC coupled to the volume control chip U3. This is an analog resistor “ladder”...
  • Page 4 SA-2 and SA-3 Theory of Operation The enclosure temperature is monitored by thermistor RT3, located close to the screw hole between the power amplifiers. When the temperature exceeds 60 degrees C, transistor Q7 begins to conduct and this slowly reduces the voltage at pin 12 of comparator U6. This has the effect of making the compressor circuit activate more frequently, at a lower threshold voltage, and the maximum output power is reduced.
