Summary of Contents for TeddyPardo Bluesound Node2i
- Page 1 Teddy Pardo Bluesound Node2i Conversion Kit Quick Startup Guide...
- Page 2 Step 1: grab the rear panel cover from the marked point and remove it. It is magnetic, therefore no tools are necessary.
- Page 3 Step 2: remove the 4 screws that hold the rear panel.
- Page 4 Step 3: carefully lift the upper cover.
- Page 5 Step 4: slowly and very carefully, lift open the case cover. Make sure not to apply too much force. Make sure not to touch or remove any of the internal flat cables.
- Page 6 Step 5: Carefully unplug the two marked connectors. Do not pull the wires.
- Page 7 Step 6: this is the result of step 5.
- Page 8 Step 7: remove 4 marked screws.
- Page 9 Step 8: Remove the two marked screws from the rear panel.
- Page 10 Step 9: Remove the rear panel.
- Page 11 Step 10: Remove the rear power socket holder.
- Page 12 Step 11: Grab hold the conversion board filler panel and attach it to the rear panel, use the original screws.
- Page 13 Step 12: place the conversion board into the case.
- Page 14 Step 13: connect the plugs into the main board.
- Page 15 Step 14: use the original screws for the conversion board.
- Page 16 Step 15: replace the original power socket holder.
- Page 17 Step 16: place the rear panel back. Carefully place the upper cover, note the marked holders.
- Page 18 Step 17: replace all rear panel screws.
- Page 19 Step 18: insert the panel cover to its place, plug the barrel plug. Unit is now ready !
