Thank you for purchasing this learnable universal
remote control. Your new remote control has a stylish
design and attractive surface. It contains one of the
largest infrared code library.
For preprogrammed code, all you have to do is to
choose the device which you wish to control (for example
TV) and it's 3-digit code number from the brand code list
(for example 001 under Philips TV). After you set up it
will remember all your set up data permanently even you
remove the batteries later.
The 6 in 1 universal remote control is suitable for
practically almost all common brands of television set
(TV), DVD player (DVD), digital and analogue satellite
receiver and cable box (SAT), video recorder (VCR),
tuner (AUX), cassette recorder (AUX), amplifiers and
other audio device (AU D). It can operate all main
functions of your device.
You can use "Auto Search" to scan the code library in
case of you can't find a suitable code under the brand or
you can not find your device brand in the list.
Besides, this remote control also can "learn" a new
code from a original remote control to supplement the
codes in case of it's shortage.
"Device shift" makes you flexible to change one
device buttons to work as another device. E.g. you can set
up a TV code to AUX and then you will have 2 TV
device keys.
"Volume lock" can fix VOL+/VOL- button to only
control amplifier for your home theater.
"Write-protection of Device Codes" can protect the
device codes from being inadvertently overwritten or
deleted
Please read this manual book carefully before you start
operate your new remote control.
Realize the Buttons
Control Remoto Inteligente Universal
Operation Instruction
1
Advertisement
Summary of Contents for Selectron RC-001
- Page 1 Control Remoto Inteligente Universal Operation Instruction Thank you for purchasing this learnable universal remote control. Your new remote control has a stylish design and attractive surface. It contains one of the largest infrared code library. For preprogrammed code, all you have to do is to choose the device which you wish to control (for example TV) and it’s 3-digit code number from the brand code list (for example 001 under Philips TV).
- Page 2 Control Remoto Inteligente Universal DESCRIPTION OF THE KEYBOARD Press this key… To… For you start to set up the remote control or show you the status in LCD screen. 、 Let you select the device you want to control. 、 VCR/DVD 、...
- Page 3 Control Remoto Inteligente Universal when set up. Works like the enter on your original remote. Works like the Menu or OSD (on-screen MENU display) or Memory key on your original remote control. CH± Works like the Channel Up and Down keys on your original remote control.
-
Page 4: Battery Installation
Control Remoto Inteligente Universal Battery Installation This remote control needs 2 AAA batteries to work with. Fresh Alkaline batteries are recommended. To install the batteries: 1. Turn the remote back, and lift the battery cover off. 2. Insert the batteries, matching the batteries to the (+) and (-) marks inside the battery compartment. - Page 5 Control Remoto Inteligente Universal 6.Check the function of the keys on remote control. If most keys on your new remote control do not function correctly, try another 3-digit device code (e.g. 004…) from the list under the same brand. Repeat steps 3 to 6 until all the basic functions operate correctly.
- Page 6 Control Remoto Inteligente Universal control. If all the keys do not function (that means you may not stop the search in time), or most keys’ operation is not good enough, you can start the search again (see steps 2–4) to find a suitable code. If most key’s function properly, that means your set up is successful, press the device key (e.g.
- Page 7 Control Remoto Inteligente Universal about every 1.5 seconds again to search the next reactive code (continues the Manual Search, see step 4-5). If you feel most of keys on the remote control work good enough, you can save the code by pressing the device key (e.g.
- Page 8 Control Remoto Inteligente Universal 4. Press and hold the source button on your original remote control (e.g.POWER) until the LED on your new remote control blinks 3 times and lights up 1 seconds, then blinks again. (That means you have learnt POWER singnal from the original remote,and you new remote control is in learning again for next learning.) If there is a learning problem, the light blinks 4 times and...
- Page 9 Control Remoto Inteligente Universal 7. About 14 commands can be stored in this remote control. Other Functions A. Display the Device Code: The device code, which has been set up in your new remote control, can be called up as follows: 1.Press the SET key and hold it down, now actuate number key “1”...
- Page 10 Control Remoto Inteligente Universal C. Volume lock This function makes you very convenient when you only use one device to adjust volume. For example, you may use your amplifier as your main volume control, then you can use this function to fix the volume and mute key to AUX, no matter which device you use (even you use TV, DVD, VCR etc), the volume and mute key on remote control still control the volume and mute of your...
-
Page 11: Instrucciones De Operación
Control Remoto Inteligente Universal Instrucciones de Operación Gracias por comprar este Control Remoto Inteligente Universal. Su nuevo control remoto tiene un elegante diseño y superficie atractiva. Contiene uno de los directorios de código infrarojos más extenso disponible para 6 aparatos diferentes. Para código preprogramado, todo lo que usted tiene que hacer es seleccionar el aparato que desea controlar (por ejemplo TV) y seleccionar su número de código de 3-... - Page 12 Control Remoto Inteligente Universal Por favor lea este manual cuidadosamente antes de que empiece a operar su nuevo control remoto. Conozca los botones Presione Para… el botón… Inicia la configuración del control remote o muestra el status en la pantalla de su television 、...
- Page 13 Control Remoto Inteligente Universal Enciende o apago su aparato Los botones númericos operan igual a los de su control remoto original, además se utilizan para ingresar los códigos momento configuración del control. Funciona igual que el de su control remoto original Funciona como el Menú...
- Page 14 Control Remoto Inteligente Universal video (Antena, caja de cable, DVR, etc.) Cambie las opciones de la imagem (4:3 o 16:9) en su televisión o ASPECT receptor. Acceda a los sub canales de su TV o — on your HD TV or receptor. LEARN Busqueda automatica Instalación de Baterías...
- Page 15 Control Remoto Inteligente Universal 4. Ahora debe ingresar el codigo de 3-dígitos del aparato (Ej. 001 para TV SONY) dentro de 10 segundos. Si no hay entradas dentro de 10 segundos, el modo de programación terminará automáticamente. 5. El LED se apaga si el código ha sido aceptado por el control remoto.
- Page 16 Control Remoto Inteligente Universal 2.Apunte el control remoto hacia su aparato. Presione SET-PROGRAMAR y la tecla del aparato (Ej. TV) simultaneamente y manténgalos presionados por 3 segundos. Luego la tecla del aparato parpadea, significa que ahora está en Búsqueda Automática. 3.la señal OFF-APAGADO...
- Page 17 Control Remoto Inteligente Universal 2.Apunte el control remoto hacia su aparato. Presione abajo mantenga presionada tecla (PROGRAMAR) y presione la tecla del aparato (Ej. TV) por un instante (menos de 3 segundos, de lo contrario irá a Búsqueda Automática), luego deje de presionar ambas teclas.
- Page 18 Control Remoto Inteligente Universal adicionales. O puede agregar un nuevo código de un control remoto original que esta almacenado en la lista de códigos. En el modo de aprender, puede preparer otro control remoto original de donde tomará los códigos Por favor use baterías nuevas para el Control Remoto Aprender y el Control remoto original.
- Page 19 Control Remoto Inteligente Universal Observación: 1. Si usted desea salir del modo de aprender, presione y libere la tecla APRENDER (APRENDER). 2. En el modo de aprender usted no debe estar mas de 30 mm entre dos 2 controles remotos, y los 2 controles 2 debe ser colocados en línea recta.
- Page 20 Control Remoto Inteligente Universal 2.Similarmente, presione la tecla SET (PROGRAMAR) y manténgala presionada, al mismo tiempo active la técla numérica “2” para desplegar la 10ª posición del código de 3-dígitos. 3. Presione la tecla SET (PROGRAMAR) y manténgala presionada, al mismo tiempo active la técla numérica “3” para desplegar la 1ª...
