- Page 1 KRM-V3 PRO with support Assembly instructions Page 1 | 5...
- Page 2 Karma V3 PRO Screen Printing Machine – KLP Screw parts using the bolts and washers TC. 2. Place part on top of module 5, using the 2 short screws and washers. Adjust the screws with the key (red). Part must be in the right position, as shown in the picture.
- Page 3 Insert and tighten the screws in module 6, as shown in the picture. 7. Place module on module and tighten the bolts with the key. 8. Connect modules with the long bolt and its nut TE. Hold the head of the screw and tighten the nut.
- Page 4 Fasten the screws simultaneously using the Allen key, but don’t tighten them completely. Start with one first and then the other until they are fully adjusted. 11. We recommend screwing the machine to the table with a clamp, as shown in the picture.
