Delta 9955-DST Specification Sheet

9955-DST
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
2 1/2 "
(64 mm)
2 1/2"
(64 mm)
4"
(102 mm)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
DSP-K-9955-DST Rev. A
Min. 2 1/2" (64 mm)
Clearance to Back Splash
6 11/16"
(169 mm)
6 1/2"
7 7/16"
(165 mm)
(189 mm)
5"
(127 mm)
2 1/2"
(64 mm)
Max. Deck
Thickness
36 3/4"
(933 mm)
37 3/4"
(959 mm)
bar / prep sink
FaUCeTs
■ Victorian ® Collection
■ Single Handle Widespread
■ 2 Hole Sink Applications
■ DIAMOND™ Seal Technology
■ Integrated Supply Tubes
■ MagnaTite™ Docking System
■ 2-Function Pull-Down
STANDARD SPECIFICATIONS:
• 14" (356 mm) high, 6 11/16" (169 mm) long, spout
swings 360˚.
• Control mechanism shall be the diamond coated
ceramic cartridge.
• Lever handle. Control shall return to neutral position
when faucet is turned off.
• Touch-Clean
• MagnaTite™ docking system secures sprayer to spout.
14"
(356 mm)
• 3/8" O.D. straight, staggered pex supply tubes -
36 3/4" (933 mm) and 37 3/4" (959 mm) long.
• Finished handle button with red/blue graphics to
indicate hot/cold temperature.
• Integral double check valves in sprayer assembly.
• Disposable hose lead to aid installation.
WARRANTy
1 3/8"
• Lifetime Faucet and Finish Limited Warranty to the
(35 mm)
Hole
original consumer purchaser to be free from defects
Size
in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
16 1/2"
(419 mm)
®
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
0 69
6
5
4
3
2
1
0
0 10
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
®
2 function (stream/spray) sprayhead.
U P
C
®
Pressure (kPa)
138 207 276 345 414 483 552 621
22.7
18.9
15.1
11.4
7.6
3.8
0
20 30 40 50 60 70 80 90
Pressure (PSI)
