REVEAL® SLIDE-IN SELF-SERVICE HEATED MERCHANDISERS
> REAR SLIDING DOOR UNITS WITH PERFORATED PLENUMS THAT SLIDE IN TANDEM WITH DOORS
> SOLID BACK UNITS WITH FIXED METAL PERFORATED PLENUMS
> CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Model NE4835HSSV Slide-In Unit Shown With
Solid Perforated Metal Back and 3 Shelves
(Illustration Shown May Not Reflect Every
Feature Or Option of Your Particular Case)
Important! See Structural Concepts
Reveal® Self-Service Counter Guide
P/N 21-26260 (That Accompanies This
Manual) For Cabinetry Construction/
Design Requirements.
User Manuals\Reveal_NE(L)(H)HSSV_Slide-In Htd Self-Svc Case_User Manual_21-26059.pub
READ AND SAVE THESE INSTRUCTIONS
®
MANUAL
Structural Concepts Corporation ∙ 888 E. Porter Road ∙ Muskegon, MI 49441
Phone: 231.798.8888 ∙ Fax: 231.798.4960 ∙ www.structuralconcepts.com
USER
Model NE4835HSSV Slide-In Unit Shown With
Rear Sliding Doors and 3 Shelves
(Illustration Shown May Not Reflect Every
Feature Or Option of Your Particular Case)
SCC P/N
21-26059
Rev A Date: 02/24/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NE3613HSSV and is the answer not in the manual?

Questions and answers

Summary of Contents for Reveal NE3613HSSV

  • Page 1 SCC P/N MANUAL 21-26059 REVEAL® SLIDE-IN SELF-SERVICE HEATED MERCHANDISERS > REAR SLIDING DOOR UNITS WITH PERFORATED PLENUMS THAT SLIDE IN TANDEM WITH DOORS > SOLID BACK UNITS WITH FIXED METAL PERFORATED PLENUMS > CAUTION! DO NOT PUSH OR PULL ON UPPER GLASS ENCLOSURE! >...
