Summary of Contents for kowatec K20W
- Page 1 K20W Sound Writer User Guide K20W Sound Writer USER GUIDE Kowatec Corporation www.kowatec.com Page 1 of 12...
-
Page 2: Table Of Contents
K20W Sound Writer User Guide Table of Content Introduction .......................... 3 Installation ................Error! Bookmark not defined. Running the Software ......................4 Compiler Window ......................... 6 Writer Window ........................9 Inserting Devices onto the Programmer ................11 Technical Support ......................12... -
Page 3: Introduction
K20W Sound Writer User Guide Introduction The K20W Sound Writer Programmer is designed to support the following IC: K161004 (10 sec, 4 I/O OTP chip) K162104 (21 sec, 4 I/O OTP chip) K164208 (42 sec, 8 I/O OTP chip) K208511 (85 sec, 11 I/O OTP chip) -
Page 4: Running The Software
4) The BUSY LED will be turned ON Fig. 1 Running the Software Double click the file K20W.EXE to launch the software. The software will start and check the firmware version on the Writer Programmer board. The following Window will be displayed (Fig. 2). - Page 5 K20W Sound Writer User Guide Update Firmware If the firmware version is correct, the program starts automatically. If the Firmware version is not correct, it will display a firmware update window to automatically update the firmware (Fig. 3). Fig. 3 Press Y to continue.
-
Page 6: Compiler Window
K20W Sound Writer User Guide Compiler Window When the K20W USB Sound Writer is launched, the Compiler Window is displayed. The Compiler Window consists of the following areas: Device Selection: to select which voice chip to be used Trigger Selection: to determine how the chip to be triggered... - Page 7 K20W Sound Writer User Guide Step 1 – Select Device Click the pulldown list to show a list of devices and select the device you want to work on. Step 2 – Select Trigger Mode Select the type of Trigger Mode you want. For more information, see Trigger Options or Triggering examples.
- Page 8 K20W Sound Writer User Guide Step 5 – Add Sound files and Silence Click the “Add” button to add sound files or mute sections or silence in ms. The mute sections or silence will not occupy any memory The sound file must be a “wav” file with 8-bit Mono format. It is recommended to use GOLDWAVE, COOLEDIT or SOUND FORGE for sound editing.
-
Page 9: Writer Window
K20W Sound Writer User Guide Writer Window After finishing the DAT file is created, you can program the DAT file onto the voice chip you have selected. Click the “Writer” tab to display the Writer Window. The following functions are available: 1. - Page 10 K20W Sound Writer User Guide Note: 1. Once the voice chip is programmed, it cannot be re-programmed. 2. The Green status bar will move from left to right to indicate the operation is in progress. 3. If the operation is completed and passed, the result is displayed in Blue on the Status bar.
-
Page 11: Inserting Devices Onto The Programmer
K20W Sound Writer User Guide Inserting Devices onto the Writer DIP package devices Device should be inserted align to the bottom of the 24-pin textool socket. K161004 - 16DIP K162104 - 16DIP K164208 - 16DIP K208511 - 20DIP K2N341N - 20DIP... -
Page 12: Technical Support
K20W Sound Writer User Guide Adapter 20S-D for K208511 SOP K208511 20SOP Technical Support Email: support@kowatec.com sales@kowatec.com Forum. www.kowatec.com/forum Tel: 408-451-9779 Kowatec Corporation 1580 Oakland Rd C102 San Jose, CA 95131 U.S.A. Page 12 of 12...
