Summary of Contents for MicroTouch MP-000-AA2
- Page 1 User Manual Version 3.0 2022/3 MP-000-AA2 Android™ Media Player...
- Page 2 MicroTouch a TES Company. The information in this document is subject to change without notice. MicroTouch a TES Company makes no representations or warranties with respect to the contents herein, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and fund to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. There limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Renseignements relatifs à la conformité Pour la FCC (États-Unis). Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe A selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
- Page 5 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Warning - Power cord shall be connected to a socket-outlet with earthing connection.
- Page 6 Avis d’utilisation Mise en garde — Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde — Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde – Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 ........................7 1.1 Overview ........................8 1.2 Feature ........................8 1.3 Specifications ......................8 1.4 Block Diagram......................9 1.5 User Controls and Indicators ..................9 1.6 Interface Connectors ....................13 1.7 Package Overview ....................13 Chapter 2 ........................ -
Page 8: Chapter 1
Chapter 1 Product Introduction... -
Page 9: Overview
1.1 Overview The versatility, reliability, and performance of MP-000-AA2 makes it an exceptional choice for applications in all business sectors. 1.2 Feature Support Rockchip RK3399 processor. USB Type C with DP ALT Mode Support. Ideal for Signage and Interactive Media Solutions. -
Page 10: Block Diagram
1.4 Block Diagram 1.5 User Controls and Indicators Function Description Power on Press the power button 3~5 sec Press the power button to enter sleep mode, and press again to Sleep resume from sleep Power off Press the power button 2 sec and click power off. -
Page 11: Interface Connectors
1.6 Interface Connectors 12V DC in Pin # Signal Name Pin # Signal Name RJ45 for LAN Pin # Signal Name Pin # Signal Name TP1+ TP1- TP2+ TP3- TP3+ TP2- TP4+ TP4- Function Color Left Active Yellow (Blink) Right 10M/100M/1000M Green USB2.0 Dual x 2... - Page 12 USB3.0 Pin # Signal Name Pin # Signal Name USB5V SSRX- SSRX+ GND_DRAIN SSTX- SSTX+ USB-C Pin # Signal Name Pin # Signal Name SSTXp1 SSRXp1 SSTXn1 SSRXn1 VBUS VBUS SBU2 SBU1 VBUS VBUS SSRXn2 SSTXn2 SSRXp2 SSTXp2...
- Page 13 HDMI Pin # Signal Name Pin # Signal Name TMDS Data2 TMDS Data2+ Shield TMDS Data2- TMDS Data1+ TMDS Data1 TMDS Data1- Shield TMDS Data0 TMDS Data0+ Shield TMDS Data0- TMDS Clock+ TMDS Clock TMDS Clock- Shield CEC(N.C on Reserved(N.C. device) on device) DDC/CEC...
-
Page 14: Package Overview
12Vdc, 2A maximum. (complied with LPS or PS2) Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. If it needs further assistance with purchasing the power source, please contact to MicroTouch for further information. Mise en garde! Cet appareil est conçu avec une alimentation de courant CA, d’une tension... -
Page 15: Chapter 2
Chapter 2 Product Installation... -
Page 16: Dimension
2.1 Dimension Front View Side View Rear View... -
Page 17: Battery Installation
2.2 Battery installation for Remote key 1. Lift and remove the back cover in the direction shown by the arrow. 2. Insert the two batteries after removing the battery cover. -
Page 18: Side Mount For Your Monitor
*Ensure the bracket is fastened to a secured and supported structure. Wall mount is included in MP-000-AA2 packaging | MP-BRKT-A1 Step1: Secure the bracket on the wooden or concrete wall. Step2: Assembly MP-000-AA2 into the wall hole and insert the screw(M4*6mm). -
Page 19: Installation
2.4 Installation | DS-320P-A1, DS-430P-A1(A2), DS-550P-A1 MP-000-AA2 signage bracket, MP-BRKT-B1* “B1” Bracket Sold Separately DS-550P-A1 Step 1. Fix the Media Player bracket to the rear cover with 4pcs M4*8 screws. Step 2. Lock the Media Player into the bracket and fix it with M4*6 star... - Page 20 Step 3. Complete the assembly of MP-000-AA2 and fix it on the DS-550P-A1. DS-430P-A1(A2) Step 1. Fix the Media Player bracket to the rear cover with 4pcs M4*8 screws. Step 2. Lock the Media Player into the bracket and fix it with M4*6 star...
- Page 21 Step 3. Complete the assembly of MP-000-AA2 and fix it on the DS-430P-A1(A2). PC box Bracket will be sold separated.
- Page 22 Fix the Media Player bracket to the rear cover with 4pcs M4*8 screws. Step 2. Lock the Media Player into the bracket and fix it with M4*6 star socket screw on the side. Step 3. Complete the assembly of MP-000-AA2 and fix it on the OF-320P-A1.
- Page 23 Fix the Media Player bracket to the rear cover with 2pcs M4*8 screws. Step 2. Lock the Media Player into the bracket and fix it with M4*6 star socket screw on the side Step 3. Complete the assembly of MP-000-AA2 and fix it on the DS-320P-A1.
