Summary of Contents for BMG WALKER
- Page 2 WALKER STEP-THRU Owner's Manual...
-
Page 3: Table Of Contents
Content About Manual ································································································································································································································································ 1 Product Specification ··························································································································································································· 2 Product Structure································································································································································································· 3 Safety Checklist ···································································································································································································· 4 Assembly Instructions · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6 Recommended Torque Values ·································································································································································································································... -
Page 4: About Manual
WALKER Bike makes every effort to ensure the accuracy of its documentation and assumes no responsibility or liability if any errors or inaccuracies appear within. Assembly and first adjustment of your WALKER Bike require special tools and skills and it is... -
Page 5: Product Specification
Product Specification 48V 16Ah Samsung Lithium Battery Front Suspension Fork Battery Front Fork 500W High Speed Brushless Geared Motor 6061 Aluminum Motor Bike Frame LCD Display Tektro Aries 180mm Brakes Display Brake Shimano 7 Speed US Standard 3.0A Smart Quick Charger Derailleur Charger 20 MPH... -
Page 6: Product Structure
Product Structure LED Head Light Handle Front Fork On/Off Front Brake LCD Display Tire Shimano Shifter Pedal Throttle Brake Lever Controller Derailleur LED Rear Light Motor Rear Rack Rear Brake Saddle Battery... -
Page 7: Safety Checklist
Safety Checklist NOTICE: Before every ride it is important to carry out the following safety checks. Safety Check Basic Steps · Ensure front and rear brakes work properly. · Ensure brake pads are not over worn and are correctly positioned in relation to the rims. ·... - Page 8 Safety Checklist Safety Check Basic Steps · Ensure the chain is oiled, clean and runs smoothly. · Extra care is required in wet or dusty conditions. Chain · Ensure pedals are securely tightened to the cranks. · Ensure the cranks are securely tightened and are not bent. Cranks and Pedals ·...
-
Page 9: Assembly Instructions
Assembly Instructions NOTICE: The following assembly steps are only a general guide to assist in the assembly of your WALKER Bike and is not a complete or comprehensive manual of all aspects of assembly, maintenance and repair. We recommend you consult a certified bicycle mechanic to assist in the assembly, repair and maintenance of your bicycle. - Page 10 Step 9 : Install the taillight. Attach the taillight and the rear rack by the screw. Step 10 : Check if the battery pack is locked into the frame of the WALKER Breeze Step-Thru. When you want to take off the battery, insert the key and turn it to release the battery pack.
-
Page 11: Recommended Torque Values
Recommended Torque Values Hardware Location Torque Required (Nm) Hardware Location Torque Required (Nm) Handlebar 18-20 Disk Mounting Bolts Stem 18-20 Disk Caliper Mount Saddle 18-20 Crank Bolts Front Wheel 16-25 Rear Derailleur Cable Pinch Rear Wheel 35-40 Front Derailleur Clamp Bottom Bracket Parts 35-55 Saddle Post Clamp... -
Page 12: Display Features
Display Features The image shows the various features and information displayed on the display. Battery Indicator Power Indicator Speed Unit Speed Indication Mode / Switch Function List Down Pedal Assist Level Indication Area Wheel Size Error Code Cycle Display Odometer Riding Time Trip Odometer Maximum Speed... - Page 13 Display Features The display pad is equipped with 3 buttons including "M", "+"(UP) and" -" (DOWN). The "M" button is the mode/switch button. Press and hold the "M" button on the handlebar controls to turn on the display. Now, your e-bike is ready to ride. To turn it off, press and hold Press the UP button for 3 seconds to turn on the light.
-
Page 14: Routine Operation
Routine Operation 1. Press the UP and DOWN keys at the same time for 2S to enter the setting interface and then press the M key to switch. General Settings 2. Press the UP and DOWN keys to select the parameter. 3. -
Page 15: Driving Range
Driving Range The range of your WALKER Bike is the distance the bike will travel on a single full charge of the onboard battery pack. The range values in this manual are estimates based on expected usage characteristics. Some of the factors which affect the range include changes in e levation, speed, payload, and acceleration, number of starts and stops and ambient air temperatures. -
Page 16: Parking Storage And Transport
In public places, your WALKER Bike must be parked in accordance with local rules and regulations. If you must park outdoors in rain, or wet conditions you should only leave your WALKER Bike outside for a few hours and proceed to park the bike in a dry location afterwards to allow all the systems to dry out. -
Page 17: Basic Battery Charging Tips
Basic Battery Charging Tips The battery should be recharged after each use. There is no memory effect, so you can charge the battery after short rides without damage. The battery can be recharged on or off the bike. Remove the battery by turning the key and then pulling the battery forward and up until the battery detaches from the mating receptacle. The charger will automatically stop charging when the battery pack is full. -
Page 18: Bicycle Care
Bicycle Care To ensure safe riding conditions you must ensure your bike is properly maintained. You should follow these basic guidelines a nd see your certified bicycle mechanic at regular intervals to ensure your bike is safe for use. 1. Properly maintain batteries by keeping them fully charged when not in use. 2. -
Page 19: Basic Troubleshooting
Basic Troubleshooting Safety Check Basic Steps Most Common Solutions 1. Insufficient battery power 1. Charge the battery pack 2. Faulty connections 2. Clean and repair connectors 3. Battery not fully seated in tray 3. Install battery correctly 4. Improper turn on sequence 4. - Page 20 Ensure handle bar grips are not damaged and properly installed. Loose or damaged grips can cause you to lose control and fall. Do not use this product with standard bicycle trailers, stands or bicycle racks. Contact WALKER Bike to check if your equipment will work with the bicycle.
-
Page 21: Warranty Info
Wear and tear is not covered under warranty. WALKER Bike lithium ion batteries are warranted to be free from manufacturing defects in materials and/or workmanship for a 2-year period from the date of original purchase. The battery warranty does not include damage from power surges, use of improper charger, improper maintenance or other such misuse, normal wear or water damage. -
Page 22: Additional Warranty Terms
Components of the WALKER Breeze Step-Thru are subject to higher wear when compared to bicycles without power assistance. This is because the WALKER Breeze Step-Thru can travel at higher average speeds than regular cycles and has a greater weight. Higher wear is not a defect in the product and is not subject to warranty.
