Summary of Contents for UCOM PRO-MIC
- Page 1 PRO-MIC Strip Profiling Workstation Assembly and Connection Hydraulic Clamp Bar Pressure Points Hydraulic Pressure Gauge Pressure Release Valve Hydraulic Pump Material PRO-MIC Digital Flexible Handle Sample Electronics Measurement to be Probes measured Top/Bottom...
- Page 2 The workstation should be set on a solid level table. The workstation feet can be used to level the system. Step 1: Attach the PRO-MIC electronics to its adjustable mount. Loosen the locking screw and complete the assembly with the two pivot balls inside the clamp.
- Page 3 Step 6: Connect the W1-G cable (female) to the PRO-MIC electronics. The PRO-MIC may start automatically, if not press Start/Stop to start the PRO-MIC. Basic Setup is complete. Your PRO-MIC is Ready! If PRO-MICs Visual Quantum PC software is to be used, please follow the...
