Summary of Contents for BAS SOJADIS LEHMDIS
- Page 1 User manual LEHMDIS SECONDARY CONTROL SYSTEM User manual LEHMDIS 04/04/2014 BAS (NW) Ltd Mobility Controls School Lane - Hollins Green Warrington - WA3 6LJ Tel: 0161 776 1594 www.basnw.co.uk office@basnw.co.uk...
- Page 2 User manual LEHMDIS...
-
Page 3: Table Of Contents
User manual LEHMDIS Table of contents USE OF LEHMDIS Presentation Power supply Battery reference Replacement of batteries Average replacement period Use and functions Functions not covered Important Activation LEHMDIS functions Cancelling LEHMDIS commands Troubleshooting... -
Page 4: Use Of Lehmdis
User manual LEHMDIS Use of LEHMDIS Presentation There are 7 function push buttons on the emitter: Horn Active while pressed down. Front windshield wipers Front windshield wipers Impulse => slow fast. Impulse: fast slow Impulse : slow Deactivation Front windshield washers* Long pressure Rear windshield washers*... -
Page 5: Power Supply
User manual LEHMDIS Power supply Battery reference 1 battery Lithium type CR 123 A Replacement of batteries Remove the screws with slotted/phillips screwdriver Pull the bottom of the transmitter Change the battery respecting the way Average replacement period ... -
Page 6: Use And Functions
User manual LEHMDIS Use and functions Function Action Button Impulse Right indicator Impulse Impulse Left indicator Impulse Impulse Low beam lights Sustained pressure Impulse Headlights Impulse Headlights flashing Sustained pressure Horn Activation Sustained pressure Slow or automatic front windshield Impulse wiper (depending on vehicle) Fast front windshield wipers Impulse... -
Page 7: Important
User manual LEHMDIS Important Activation LEHMDIS functions If a function was activated with LEHMDIS it is imperative to deactivate with LEHMDIS as well. Cancelling LEHMDIS commands To cancel LEHMDIS commands switch off the engine. Troubleshooting If a button gets stuck, the transmitter stops its transmission after 25 seconds. The other buttons are no longer usable. - Page 8 Date of the last batteries replacement...
- Page 10 Warranty BAS Ltd guarantees this product and installation for three years providing that it is in no way tampered with. All warranty work is done by us at our premises. Warranty is null and void if the product is not serviced annually.
- Page 11 Service Schedule The first three services are necessary to the validity of your warranty. First service at 12 months Date..........Second service at 24 months Date..........Third service at 36 months Date..........Fourth service at 48 months Date..........Fifth service at 60 months Date..........
- Page 12 BAS (NW) Ltd Mobility Controls School Lane - Hollins Green Warrington - WA3 6LJ Tel: 0161 776 1594 www.basnw.co.uk office@basnw.co.uk...
