SLP1210-P Solar panel Instruction manual
1. Features:
1.1 High module conversion efficiency(up to 16%),
through
superior
cell
manufacturing capability
1.2 Excellent weak light performance
Excellent performance under low light environments
(mornings, evenings, and cloudy days)
1.3 Withstand high wind and snow loads
Entire module certified to withstand high wind loads
2. Electrical Characteristics
Maximum Power at STC (Pmax)
Optimum Operating Voltage (Vmp)
Optimum Operating Current (Imp)
Open - Circuit Voltage (Voc)
Short - Circuit Current (Isc)
Maximum Series Fuse Rating
Maximum System Voltage
Operating Module Temperature
STC: irradiance 1000 W/m2, module temperature 25 ° C, AM=1.5;
Home alarm:
www.GsmAlarmSystem.com
technology
and
Model
Solar Cell
Dimensions
Frame
Junction Box
Power Tolerance
leading
SLP1210-P
Monocrystalline
10W
18 V
0.833A
21.6V
0.883A
291*305*25mm
Anodized aluminum alloy
IP67 rated
20 A
± 3 %
1000 V DC (IEC) / 600 V DC (UL)
-40 ° C to +85 ° C
Industrial controller:
www.GSM-M2M.com
Advertisement
Table of Contents
Summary of Contents for King Pigeon SLP1210-P
- Page 1 SLP1210-P Solar panel Instruction manual 1. Features: 1.1 High module conversion efficiency(up to 16%), through superior cell technology leading manufacturing capability 1.2 Excellent weak light performance Excellent performance under low light environments (mornings, evenings, and cloudy days) 1.3 Withstand high wind and snow loads Entire module certified to withstand high wind loads 2.
- Page 2 3. Application: To charging all the electronic products voltage 12-18V, Usually used for 12v Storage Battery, and 12v solar electronics products . When charging 12V Battery you need to observe the following connection sequence during commissioning: 1. Connect the battery to the charge regulator - plus and minus Connect the photovoltaic module to the charge regulator - plus and minus...
