Summary of Contents for Digital Vision element
- Page 1 Panel guide Nucoda and Phoenix 2018.2 www.digitalvision.tv...
- Page 2 Tools have been mapped, for some of the complex tools not all parameters are mapped, especially where “Basic” Effects are referred to in the Element Mapper as a Mode - you will see that each mode is mapped separately in the mapper and the menus on some panels will change for every mode.
- Page 3 Button Panel (Bt2) Navigation (Mf) These menus are persistent and will always be available These menus are persistent and will always be available Bt2 - Bank 1 of 2 Mf - Bank 1 of 2 - Available in all modes Compare Mem Src Comp Type...
- Page 4 Button Panel (Bt1) Menu example Knob Panel (Kn) Menu example Mode specific menus, they will update depending on the mode Mode specific menus, they will update depending on the mode The encoders must be pressed down to reset the values. Sensitivity can be set in the This example is the Shapes mode - Most modes use only one bank, but there are modes Tangent mapper application.
- Page 5 Trackballs and Rings - Tk The trackballs and rings are automatically active when a relevant tool is selected. Their use is not only limited to colour tools. In the shape tool, with a selected shape, they are mapped Left Ball - Shape position Left Ring - Softness Middle Ball - Scale X and Y Ring - Scale...
- Page 6 Bt2 - Bank 1 of 2 - Available in all modes Mf - Bank 1 of 2 - Available in all modes Compare Mem Src Comp Type Add CC Add FX Add To FX Src Sel - Src Display Src Sel + <-Layer Layer->...
- Page 7 Bt1 - Bank 1 of 2 - mode specific - Shapes Bt1 - Bank 1 of 2 - mode specific -Shapes Ellipse Rectangle Auto-Bezr Outer Sft Inner Sft Blur Size Shape Invert Delete Shp Opty Shp Oper Soft Fall Vari Soft Invert All ShowK Comb Opty...
- Page 8 Button Panel (Bt1) - Keyer Mode The keyer the largest menu with 5 banks - each keyer type has it's own bank and you have to switch to the required bank manually. Bt1 - Bank 1 of 2 Enable ShowK Graphs On Lightness Green...
- Page 9 Knob Panel (Kn) - Keyer Knob Panel (Kn) - Keyer Kn - Bank 1 of 6 - Keyer main page Kn - Bank 4 of 6 - Press B - HSV Values Keyer FilterTyp MedianSiz Hue High Sat High Val High KInFilter MedianStr HHighSoft...
- Page 10 Digital Vision (US) Digital Vision (UK) Digital Vision Development AB 6464 Sunset Blvd. 110 Wapping High Street Sankt Eriksgatan 48 C Suite 830 Wapping 112 34 Hollywood London Stockholm CA 90028 E1W 2NE Sweden United Kingdom Tel:+1 818 769 8111...
