  • Page 1 CSS Laboratories Single Board Computer SBP-205 User Guide...
  • Page 2 Copyright © 2002 CSS Laboratories, Inc. All rights reserved. ProRack™, MaxPro™ and SBP-205™ are trademarks of CSS Laboratories, Inc. All other trademarks are owned by their respective companies. Published by CSS Laboratories, Inc. 1641 McGaw Avenue Irvine, California 92614 http://www.csslabs.com/...

  • Page 3: Table Of Contents

    Processor Overview....................11 Installing and Removing a Processor ................ 11 SBP-205 Installation........................ 12 Overview ........................12 Installing the SBP-205 to a Passive Backplane ............12 Jumper Switches ........................14 Jumper Switches Overview ..................14 Setting Jumper Switches.................... 16 BIOS Configuration......................... 17 BIOS Configuration Overview..................
  • Page 4 Troubleshooting by Direct Inspection ............... 24 Troubleshooting Using System Utilities..............24 Troubleshooting Tables ..................... 25 Section 4 – Technical References SBP-205 General Specifications....................32 Memory Configuration ......................34 System Interrupt Chart......................34 Notices and FCC Information FCC Standards ......................... 36 Notice............................

  • Page 5: Section 1 - Sbp-205 Features

    On-board 64-bit path memory supports up to 512MB of total memory in two 168-pin DIMM sockets. Bus Architecture The SBP-205 is fully ISA and PCI Local Bus compatible. The PCI Local Bus is fully compliant with the PCI Local Bus 2.1 specifications. Peripheral Support...

  • Page 6: Board Features

    256KB running at full CPU speed. The cache modules are inside the CPUs, and provide 32KB of first level (L1) cache. Voltage Regulators The nine voltage regulators mounted on the SBP-205 provide compatibility with a full line of processors. •...

  • Page 7: Microprocessor

    • Microprocessor ® The SBP-205 supports a single Pentium III processor operating at speeds up to 1GHz. The processor features include: Dynamic Execution performance with Multiple Branch Prediction, Data Flow Analysis and Speculative Execution. Multi-transaction system bus. Dual Independent Bus Architecture, which allows data access from either bus simultaneously or in parallel.

  • Page 8: Section 2 - Using The Sbp-205

    • Section 2 – Using the SBP-205 Connectors Connector designations are stamped in white on the SBP-205 board. SBP-205 Board Connector Descriptions Connector Description IDE1 Primary IDE connector IDE2 Secondary IDE connector USB1 USB0 (Universal Serial Bus 1) USB2 USB1 (Universal Serial Bus 2)

  • Page 9: Keyboard And Mouse

    Assignment Assignment Keyboard Data +5 Vdc Not Used Clock Ground Not Used PS/2 Mouse Connector Pin Assignments Assignment Assignment Mouse Data +5 Vdc Not Used Clock Ground Not Used • Section 2 – Using the SBP-205 • 5 CSS Laboratories...

  • Page 10: Ide, Primary And Secondary

    IOCHRD 470 Ω (ohm) pull down DDACK0 (DDACK1) # Ground IRQ14 (IRQ15) Reserved Addr1 Reserved Addr0 Addr2 Chip Select 1P (1S) # Chip select (3P 3S) Activity # Ground • Section 2 – Using the SBP-205 • 6 CSS Laboratories...

  • Page 11: Parallel Port

    Ground Ground SLCT Not Used Serial Ports (COM1, COM2) The SBP-205 features two 9-pin serial ports and connectors. They are designated COM1 (serial port 1) and COM2 (serial port 2). Serial Port Connectors (COM1, COM2) Pin Assignments Assignment Assignment Ground •...

  • Page 12: Diskette Drive (Fdd)

    FDRDATA # Ground FDRHEAD # Ground DSKCHG # Universal Serial Bus (USB) The SBP-205 provides connectors for two Universal Serial Bus (USB) connectors. They are designated USB1) and USB2). USB Connector (USB1, USB2) Pin Assignments Assignment Assignment Data + Data –...

  • Page 13: Processor Cooling Fan (Cpu Fan)

    • Processor Cooling Fan (CPU Fan) The SBP-205 provides a 3-pin processor cooling fan connector. It is designated CPU Fan. Processor Cooling Fan Connector (CPU Fan) Pin Assignments Assignment Assignment Ground 12 volt Sense Memory The SBP-205 provides two 168-pin DIMM sockets. The board supports up to 512MB of RAM with each socket supporting DIMMs up to 256 MB.

  • Page 14: Installing And Removing Memory

    16M x 64/72 16M x 64/72 Installing and Removing Memory The SBP-205 DIMM sockets are located on the left side of the board. IMPORTANT NOTE: It should not be necessary to remove the single board computer from the passive backplane or the system chassis in order to remove or install memory modules.

  • Page 15: Processor

    Processor The SBP-205 supports a single Pentium III processor operating at up to 1 GHz. The processor mounting includes a single edge contact (SEC) slot and an attached mounting and retention bracket. The SBP-205 accepts a Pentium II/III processor packaged in an SECC-2 cartridge.

  • Page 16: Sbp-205 Installation

    Swapping out the single board computer(s) is one way the MaxPro and ProRack systems can be customized and upgraded. Overview The SBP-205 connects to any CSS Laboratories passive backplane through one EISA connector with a PCI bus extension. This SBC connector socket combination is located on the passive backplane.
  • Page 17 5. Close the system case. 6. Reconnect the power cord and the external connectors, and power up the system. As the system boots, the BIOS will detect the SBP-205 settings. You may need to manually reconfigure the system. See BIOS Configuration for procedures to configure the BIOS and CMOS.

  • Page 18: Jumper Switches

    Figure 4 – Passive Backplane Figure 5 – SBC Installed to Passive Backplane Jumper Switches The SBP-205 jumper switches are pre-configured at the factory. Jumpers are used to configure the processor bus frequency and to clear CMOS contents. Jumper Switches Overview The Pentium III processor uses a clock multiplier to match the processor core frequency with the speed of the processor bus—the speed at which data travels into...
  • Page 19 “off” or “out” with the jumper cap off. Jumpers with more than two pins are described by numbering the pins. Each of the SBP-205 jumpers has the number “1” stamped on the board next to that jumper’s pin number one.

  • Page 20: Setting Jumper Switches

    • Setting Jumper Switches Setting jumper switches is easiest with the SBP-205 removed from the system. While the jumper switches are accessible with the SBP-205 installed, it might be necessary to remove one or more adapter cards if they restrict access to the jumpers.

  • Page 21: Bios Configuration

    With a Pentium II processor, jumper settings are used to multiply the bus speed to match the processor clock speed. The SBP-205 provides a chart stamped on the board which gives the processor speed ratios at different settings of jumper JP7.

  • Page 22: Setting Up Cmos-Standard Setup

    ↑ ↓ → ←: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optional Defaults Figure 8 – Standard CMOS Setup • Section 2 – Using the SBP-205 • 18 CSS Laboratories...

  • Page 23: Setting Up Cmos-Advanced Setup

    Figure 9 – Advanced CMOS Setup, First Page Advanced Setup displays two screens of options to fine tune a number of system features. Select Advanced CMOS Setup from the main menu. • Section 2 – Using the SBP-205 • 19 CSS Laboratories...

  • Page 24: Setting Up Cmos-Advanced Chipset Setup

    ↑ ↓ → ←: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optional Defaults Figure 11 – CMOS Advanced Chipset Setup Configuring Power Management The power management options include: • Section 2 – Using the SBP-205 • 20 CSS Laboratories...

  • Page 25: Configuring Pci/Plug And Play

    ↑ ↓ → ←: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optional Defaults Figure 12 – CMOS PCI/PNP Setup • Section 2 – Using the SBP-205 • 21 CSS Laboratories...

  • Page 26: Setting Up Peripherals

    PWRON After PWR-Fail [ Off ] ↑ ↓ → ←: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optional Defaults • Section 2 – Using the SBP-205 • 22 CSS Laboratories...

  • Page 27: Section 3 - Maintenance And Troubleshooting

    Section 3 – Maintenance and Troubleshooting Routine Maintenance Follow these basic steps to maintain and safeguard the SBP-205 single board computer: The MaxPro tower server chassis and the ProRack rackmount chassis are designed to provide protection for internal devices and connections. Care must still be taken to ensure that the system case won’t be kicked or struck.

  • Page 28: Troubleshooting By Direct Inspection

    Figure 14—Windows NT Devices Window 3. Select the problem device and click the HW Profiles button. This will display the Device window. 4. Click the Enable button if the device is incorrectly disabled. • Section 3 – Maintenance and Troubleshooting • 24 CSS Laboratories...

  • Page 29: Troubleshooting Tables

    The following tables list common problems and the basic handlings to resolve those problems. The handlings are only the most likely steps to take, suggested guidelines. Use them in conjunction with the direct inspection and system utilities tools discussed earlier. • Section 3 – Maintenance and Troubleshooting • 25 CSS Laboratories...
  • Page 30 Make sure that the connector is properly seated at both ends. 2. If the problem persists, inspect the battery located on the SBP-205. Make sure that it is properly seated or replace the battery. 3. If the problem persists, inspect the BAT connector on the passive backplane for damaged pins.
  • Page 31 If so, turn off the monitor and either move it or the other device a minimum of a foot apart. Turn the monitor back on. If the problem still persists, have the monitor serviced or replaced. • Section 3 – Maintenance and Troubleshooting • 27 CSS Laboratories...
  • Page 32 PORT OR PERIPHERAL DEVICE PROBLEMS HANDLING The parallel port doesn’t work or isn’t recognized by the 1. The parallel port is mounted on the SBP-205. Check system. the BIOS setting to see if it has been disabled. 2. Open the system case and make sure that the parallel port data cable and power connector are properly seated in their slots on the SBP-205.
  • Page 33 (in the case of a software installation or program diskette). If the problem persists, have the system serviced. The drive itself might be improperly connected or malfunctioning. • Section 3 – Maintenance and Troubleshooting • 29 CSS Laboratories...
  • Page 34 Other hard drive data access problems. Consult the SCSI documentation for termination information and procedures. All SCSI devices must be properly terminated. CSS Laboratories terminates the last SCSI cable end with an active terminator. If none of the above solutions resolve data access or other...
  • Page 35 Apply the troubleshooting steps outlined in these tables and earlier in this topic to ensure that those devices are properly connected and working. • Section 3 – Maintenance and Troubleshooting • 31 CSS Laboratories...

  • Page 36: Section 4 - Technical References

    • Section 4 – Technical References SBP-205 General Specifications 13.28” x 7.25” Form factor Single Intel Pentium II/III: Host bus frequencies of 66/100/133 MHz Up to 1 GHz Cache An external 64-bit wide non-blocking second level (L2) cache, supporting 256K or 512K running at full CPU speed is inside the CPU.
  • Page 37 PCI Interrupt steering O/S Compatibility MS-DOS, Windows, Windows 98/Millenium, OS/2, SCO UNIX, Interactive UNIX, Interactive UNIX, QNX, Linux, Windows NT/2000 Environmental Temperature: 0° to 55° C Specifications Humidity: 20% to 80% non-condensing • Section 4 – Technical References • 33 CSS Laboratories...

  • Page 38: Memory Configuration

    • Memory Configuration The following chart shows all possible memory configurations for the SBP-205. SBP-205 Memory Configuration Bank 0 Bank 1 Bank 0 Bank 1 64 MB 8M x 64/72 256 MB 32M x 64/72 128 MB 8M x 64/72...
  • Page 39 The PCI standard has a 4-IRQ limitation. Some PCI add-in boards do not require IRQs. Some can share an IRQ with another board of the same model and manufacture. Check the add-in board documentation for IRQ information. • Section 4 – Technical References • 35 CSS Laboratories...

  • Page 40: Notices And Fcc Information

    Notice The information within this manual is subject to change without notice. CSS Laboratories, Inc., shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

  • Page 41: Glossary Of Terms

    A type of computer memory that is very fast in which the computer temporarily stores information. Compact Disc. A nonmagnetic, polished metal disc with a protective plastic coating that can hold large quantities of digital data. • Glossary of Terms • 37 CSS Laboratories...
  • Page 42 A removable magnetic storage device encased in plastic. Also called a “floppy disk.” Direct Memory Access. Memory access that does not involve the microprocessor and is frequently used for data transfer directly between memory and an "intelligent" peripheral device, such as a disk drive. • Glossary of Terms • 38 CSS Laboratories...
  • Page 43 Integrated Drive Electronics or Intelligent Device Electronics. A type of interface for controlling hard disk drives. Interrupt ReQuest. Used to let the computer know that a device is ready to do something or that it has done something. • Glossary of Terms • 39 CSS Laboratories...
  • Page 44 The transmission of data eight or more at a time; a type of device, such as a “parallel port” that sends or receives data in this fashion. See also: Serial. Passive Backplane See Backplane. • Glossary of Terms • 40 CSS Laboratories...
  • Page 45 Small Computer System Interface, often pronounced “skuzzy.” An industry standard for connecting hard disks, tape drives and scanners to computers. SDRAM Synchronous Dynamic Random-Access Memory (DRAM). SDRAM can run at higher clock speeds than conventional DRAM. • Glossary of Terms • 41 CSS Laboratories...
  • Page 46 Universal Serial Bus. A type of serial device connector. Video Graphics Adapter. A video adapter that duplicates all the video modes of the EGA (Enhanced Graphics Adapter) and adds several more. • Glossary of Terms • 42 CSS Laboratories...

  • Page 47: Index

    Troubleshooting 23, 24, 25, 26 Jumper switches 2, 13, 14, 15, 16, 17 Universal Serial Bus See USB Jumper Switches 14, 15, 16 USB 1, 8, 33, 42 Keyboard 1, 4, 5, 17, 19, 27, 33, 34 • Index • 43 CSS Laboratories...
