Page 1
Hunting Trail Camera USER MANUAL CAUTION: 1.FORMAT your TF ( microSD ) card before use ; 2.TF ( microSD ) card must under 32G (32G included). English ..............- 01 06 ..............- Francais 07 12 ..............Deutsch 13 18 ..............
Page 2
Camera View ( L SERIES ) MENU SHOT REPLAY ON TEST OFF 1. Strap hole 10. PIR & sensor 19. REPLAY button 2. Lock hole 11. Fixed button Down button 3. Fixing nut 12. PIR & sensor OK button 4. DC input 3.
Page 3
Camera View ( N SERIES ) MENU SHOT REPLAY ON TEST OFF 1. Strap hole . PIR & sensor 17. REPLAY button 2. Fixing nut 10. PIR & sensor 8 Down button 3. DC input 1. LCD 9 OK button 4.
Preparation before use 1.Power selection (choose one) 1.1 Insert 8×1.5V AA battery into the battery compartment. 1.2 Select 12V, 2A DC input external power supply. 2.Storage. 2.1 Installation of the Class 10 TF( microSD ) card with FAT/FAT32. Support up to 32 G Max. Please format the memory card from your computer before use.
4.When selecting a photo: Press Key ▲ to zoom in the picture, then press Key ◄, ►, ▲ , ▼ to adjust the position of the picture.Press the “MENU” key to exit the zoom mode. 5.When playing a vedio,press “OK” Key to play or pause,press ◄ to fast backward video,Press ►...
Page 6
● Press ▲, ▼ to scroll through the setting options, and the “OK” button to confirm the setting; ● Press “MENU” key to exit. Settings Settings Settings Language English Timer Setting Mode Photo Camera Name PIR Interval 15 sec Set Clock 00:00 Stamp...
Page 7
● Keep the camera facing north or south NOT east or west due to sunrise and sunset could produce false triggers and overexposed images. ● Clear all obstructions in front of camera to avoid obscuring camera lens or PIR sensor.Otherwise,the camera may be triggered by mistake during windy or hot days. ●...
Page 8
Vue d’appareil photo ( SÉRIE L ) MENU SHOT REPLAY ON TEST OFF 1. Trou de bande 10. PIR & capteur 19. Bouton REPLAY 2. Trou de serrure 11. Boucle de fixe Bouton inférieur 3. Ecrou de fixation 12. PIR & capteur Bouton 4.
Page 9
Vue d’appareil photo ( SÉRIE N ) MENU SHOT REPLAY ON TEST OFF 1. Trou de bande 9. PIR & capteur 1 . Bouton REPLAY 2. Ecrou de fixation 10. PIR & capteur Bouton inférieur 3. Entrée CC 1. LCD Bouton 4.
Préparation avant utilisation 1. Sélection d’alimentation (choisissez-en une). 1.1 Installez les piles AA 8×1.5V AA dans le compartiment à piles. 1.2 Choisissez l’alimentation externe d’entrée DC 12V, 2A. 2. Stockage 2.1 Installation de carte TF (FAT/FAT32). Support maximum 32G. 2.2 Veuillez formater la carte TF sur votre ordinateur avant utilisation.
Page 11
4.Une photo est sélectionnée: presser la touche ▲ pour agrandir la photo,après avoir agrandi la photo, presser les touches ◄ , ► , ▲ , ▼ pour ajuster la position dephoto.Appuyez sur le bouton“MENU”pour quitter le mode d’agrandissement. 5.Une vidéo est sélectionnée:presser la touche “OK” pour lire ou mettre en pause, appuyez sur ◄...
Page 12
● Appuyez sur ▲, ▼ pour faire défiler les options de paramètres et appuyez sur "OK" pour confirmer; ● Appuyez sur "MENU" pour quitter le réglage. L a création L a création L a création Langue Français Mode Photo Minuteur Intervalle 15 sec Temps...
Page 13
Hauteur d'installation de la caméra: 0,5-2 mètres. Position d'installation de la caméra: installez au nord ou au sud, ne faites pas face à l'est ou à l'ouest. (du fait que le soleil se lève et se couche, il produira de faux déclencheurs et des images surexposées) Supprimez toutes les obstructions sur le côté...
Page 14
Kameraansicht ( L-SERIE ) MENU SHOT REPLAY ON TEST OFF REPLAY Taste 1. Binde Vias 10. PIR &Sensoren 2. Schlüsselloch 11. Feste Taste Abwärtstaste 3. Befestigungsmutter 12. PIR &Sensoren OK Taste 4. DC Eingang 3. LCD TF-Kartenslot 5 Objektivlinsen SHOT Taste 23.
Page 15
Kameraansicht ( N-SERIE ) MENU SHOT REPLAY ON TEST OFF REPLAY Taste 1. Binde Vias . PIR &Sensoren . Befestigungsmutter . PIR &Sensoren Abwärtstaste . DC Eingang . LCD OK Taste . Die Infrarotlampe SHOT Taste TF-Kartenslot 5 Feste Taste Rechte Taste 21.
Vorbereitung vor dem Gebrauch 1.Auswahl der Stromversorgung(wählen Sie eine aus) 1.1 Legen Sie eine 8×1,5V A A -Batterie in das Batteriefach ein. 1.2 Wählen Sie eine externe Stromversorgung mit 12V, 2A DC-Eingang. 2 .Speicherung 2.1 Installation der TF-Karte (FAT/FAT32).Maximale Unterstützung 32G. 2.2 Bitte formatieren Sie die T F -Karte vor der Verwendung in Ihrem Computer.
Page 17
3.Drücken Sie die Taste ◄ und ► , um das Foto oder Video, das Sie durchsuchen möchten, auszuwählen. 4.Une photo est sélectionnée: presser la touche ▲ pour agrandir la photo,après avoir agrandi la photo, presser les touches ◄ , ► , ▲ , ▼ pour ajuster la position dephoto.Appuyez sur le bouton“MENU”pour quitter le mode d’agrandissement.
● Drücken Sie "Menu", um die Einstellungsoberfläche aufzurufen; ● Drücken Sie ▲, ▼, um durch die Einstellmöglichkeiten zu blättern, und die Taste "OK", um die Einstellung zu bestätigen; ● Drücken Sie "MENU", um die Einstellungsoberfläche zu verlassen. Einstellungen Einstellungen Einstellungen Timer Setting Modus Foto...
Page 19
Kamera-Installationshöhe: 0,5 bis 2 Meter. Installation der Kamera: Installieren Sie die Kamera nach Norden oder Süden, und richten Sie sie nicht nach Osten oder Westen (da die Sonne auf- und abfällt, werden falsche Auslöser und überbelichtete Bilder erzeugt). Entfernen Sie alle Hindernisse auf der Vorderseite der Kamera, um das ...
Page 20
Vista de cámara ( SERIE L ) MENU SHOT REPLAY ON TEST OFF Botón de arriba PIR Sensor 9 Botón REPLAY Agujero de bloqueo Hebilla fija 20 Botón abajo Tuerca fijación PIR Sensor 21 Botón OK DC Entrada Ranura TF Lente 14.
Page 21
Vista de cámara ( SERIE N ) MENU SHOT REPLAY ON TEST OFF Botón de arriba PIR Sensor 7 Botón REPLAY 2 Tuerca fijación PIR Sensor 18 Botón abajo 3 DC Entrada 11 LCD 19 Botón OK 4 Radiacóin infrarroja 12.
Preparación antes del uso 1. Selección de potencia (Elija una) 1.1 Inserte una batería AA de 8×1.5V en el compartimiento de la batería. 1.2 Seleccione una fuente de alimentación externa de entrada de 12V, 2A DC. 2 Almacenamiento 2.1 Instalación de tarjetas TF(Sistema de archivos:FAT / FAT32).Máximo soporte 32G.
Page 23
3.Presione la tecla ◄ y la tecla ► para seleccionar una foto o video para previsualizar . 4.Después de seleccionar una foto : Presione la tecla ▲ o la tecla ▼ para acercar / alejar la imagen, luego presione la tecla ◄,►,▲,▼ para ajustar la posición de la imagen.Presione la tecla“MENU”para salir de la interfaz de ampliada y la interfaz de descripción general de la imagen.
Page 24
● Presione “MENU” para ingresar a la interfaz de configuración; ● Presione ▲, ▼ para desplazarse por las opciones de configuración y confirme la configuración con "OK". ● Presione "MENU" para salir de la interfaz de configuración. Configuraciones Configuraciones Configuraciones Modo Foto Idioma...
Page 25
Altura de instalación de la cámara: 0.5-2 metros.. La cámara está montada al norte o al sur, sin mirar al este o al oeste (porque el sol sube y baja, produce falsos disparadores e imágenes sobreexpuestas). Retire todas las obstrucciones en la parte frontal de la cámara para evitar que se ...
Page 26
カメラ概略図 ( Lシリーズ ) MENU SHOT REPLAY ON TEST OFF 1.ストラップ穴 10.PIR&センサー 19.REPLAYボタン 2.ロック穴 11.固定留め金 20.下ボタン 3.締付ナット 12.PIR&センサー 21 OK ボタン 4.DC入力 13.LCD 22.TFカードスロット 5.レンズ 14.SHOTボタン 23.USBインターフェース 6.赤外線 15.右ボタン 24.スイッチ 7.感光センサー 16.上ボタン (TEST/OFF/ON) 8.表示ライト 17.MENUボタン 25.バッテリーボックス 9.マイク 18.左ボタン - 25 -...
Page 27
カメラ概略図 ( Nシリーズ ) MENU SHOT REPLAY ON TEST OFF ストラップ穴 PIR&センサー 17. REPLAYボタン 締付ナット 10 PIR&センサー 18. 下ボタン 3 DC入力 11. LCD 19 OK ボタン 赤外線 12. SHOTボタン TFカードスロット 5. 固定留め金 13. 右ボタン 21 USBインターフェース レンズ 14. 上ボタン スイッチ 7.
Page 32
Compliance The WEEE logo on this product or its documentation indicates that the product must not be disposed of as household waste. To help prevent possible harm to human health and/or the environment, the product must be disposed of in an approved and environmentally safe recycling process.
