Instruction manual
VWR A-1000/A-1100/A-1200
Sipper/Temperature Control System
European Catalogue Number
EU/UK/CH Plug: 634-1152
EU/UK/CH Plug: 634-1153
EU/UK/CH Plug: 634-1154
Version:
1.0.1
Issued:
16, June, 2020
A-1100 CONTROLLER, SIPPER FOR
UV1600PC, UV-3100PC, V3000PC, UV6300PC
A-1000 CONTROLLER, SIPPER WITH
CONSTANT-TEMPERATURE FOR
UV1600PC, UV-3100PC, V3000PC, UV6300PC
A-1200 CONTROLLER,
CONSTANT-TEMPERATURE FOR
UV1600PC, UV-3100PC, V3000PC, UV6300PC
Advertisement
Table of Contents
Summary of Contents for VWR VWR A-1000
- Page 1 Instruction manual VWR A-1000/A-1100/A-1200 Sipper/Temperature Control System European Catalogue Number EU/UK/CH Plug: 634-1152 A-1100 CONTROLLER, SIPPER FOR UV1600PC, UV-3100PC, V3000PC, UV6300PC EU/UK/CH Plug: 634-1153 A-1000 CONTROLLER, SIPPER WITH CONSTANT-TEMPERATURE FOR UV1600PC, UV-3100PC, V3000PC, UV6300PC EU/UK/CH Plug: 634-1154 A-1200 CONTROLLER, CONSTANT-TEMPERATURE FOR...
- Page 2 Legal Address of Manufacturer Europe VWR International bv Researchpark Haasrode 2020 Geldenaaksebaan 464 B-3001 Leuven + 32 16 385011 www.vwr.com Made in China...
-
Page 3: Table Of Contents
Operation ..................................16 Temperature Control ............................16 Sipper ................................17 System settings ................................19 Technical service ................................21 Warranty ..................................21 Compliance with local laws and regulations ........................21 Equipment disposal ..............................22 Local VWR offices in Europe and Asia Pacific........................ 23... -
Page 4: Safety Information
Safety Information Please follow the guidelines below and read this manual in its entirety to ensure safe operation of the unit. We recommend against the use of A-1000 Constant Temperature/Automatic Injection System. Do not open the device. Disconnect the device from the mains supply before carrying out ... -
Page 5: Package Contents
Package Contents Configuration list of A-1000 Description Quantity Constant Temperature/Automatic Injection Controller 10mm Single Cell Holder with Constant Temperature 10mm Flowing Quartz Cuvette Silicone Pipe with Limit Ring（1m，Inner hole diameter：φ2，Outer diameter：φ4） Silicone pipe（700mm，Inner hole diameter：φ2，Outer diameter：φ4） Constant Temperature Control Cable Power Cords ( EU/UK/CH Plug ) Instruction Manual... - Page 6 Configuration list of A-1100 Description Quantity Automatic Injection Controller 10mm Single Cell Holder 10mm Flowing Quartz Cuvette Sample Chamber Baffle (including injection hole) Silicone Pipe with Limit Ring（1m，Inner hole diameter：φ2，Outer diameter：φ4） Silicone pipe（700mm，Inner hole diameter：φ2，Outer diameter：φ4） Power Cords ( EU/UK/CH Plug ) Instruction Manual Configuration list of A-1200 Description...
-
Page 7: Unpacking
Unpacking Open the package, according to carefully check the packaging packing list items, if found inside the packaging are missing or damaged items please contact your authorized contractual partners. Description The A-1000 series Constant Temperature/Automatic Injection Controller is specially developed to meet the needs of some applications of our UV/Vis spectrophotometer. It is divided into 3 models according to different functions. -
Page 8: Installation
1 – Touch Screen 2 – Injection Pipe 3 – Peristaltic Pump 4 – USB Port 5 – Constant Temperature Control Port 6 – Serial Port 7 – Power Inlet 8 – Fuse Seat 9 – Power Switch 10 – Constant Temperature Control Interface 11 –... - Page 9 Connect the power cord Check to confirm instrument power switch is turned off. Plug the female of the power cord into the power inlet of the instrument and plug the male into the power outlet. 1 – Power inlet 2 – Power cord 3 –...
- Page 10 Connect the injection pipe As shown in the figure, insert the output end of the injection pipe (label 1) through the in hole of the cover and insert the injection end of the flow cuvette (label 2). One end of the sample discharge pipe (label 5) is connected to the sample end of the flow cuvette (label 2), and the other end is passed through the sample hole of the cover plate 1 –...
-
Page 11: Symbols And Conventions
Symbols and conventions The following chart is an illustrated glossary of the symbols that are used in this manual. CAUTION This symbol indicates a potential risk and alerts you to proceed with caution. CAUTION This symbol indicates the presence of high voltage and warns the user to proceed with caution. - Page 12 1~8ml/min（0.5ml/min 1~8ml/min（0.5ml/min Injection Speed —— interval adjustable） interval adjustable） 1~300s（1s interval 1~300s（1s interval Continuous Injection adjustable）or Manual adjustable）or manual —— Time stop stop 1~300s（1s interval 1~300s（1s interval Sample Recycling adjustable）or Manual adjustable）or manual —— Time stop stop 1~300s（1s interval 1~300s（1s interval Cleaning Time adjustable）or Manual adjustable）or manual...
-
Page 13: Getting Started
Getting Started The following chart describes the basic operation of the instrument. Turn the instrument power on Switch on the power on the back of the instrument to start. Note: Do not turn the instrument on and off continuously and quickly. Wait at least 30 seconds before turning the instrument back on, otherwise the electrical and mechanical systems may be damaged. -
Page 14: Using The Instrument
Slide When modifying certain setting parameters, press and slide the icon to a position to change the setting value. Using the instrument Main Interface The main interface is divided into two parts, the left part is the temperature control area, and the right part is the injection control area. A-1000... - Page 15 A-1100 A-1200 Constant temperature control state Current temperature Set temperature Appointment time process Sipper control state Sipper speed Temperature control start Stop temperature control Recycle the sample in the flow cuvette after the end of the measurement Cleaning the flow cuvette...
-
Page 16: Operation
Inhale the sample into the flow cuvette Stop sipper/recycling/cleaning System parameter setting Operation Temperature Control Start temperature control Main interface, Press the button Start on the left to pop up the temperature control < > parameter interface, press the button to set the temperature control parameters according to the requirements. -
Page 17: Sipper
Temperature Set temperature, range: 10 ° C ~ 90 ° C, 0.1 ° C interval adjustment Mode The way to control the temperature, Slow: Rise/Lower temperature slowly, no overshoot (for biometrics) Medium: Rise/Lower temperature in medium speed, small overshoot Fast: Rise/Lower temperature quickly, larger overshoot. Reservation Waiting for a period of time to start rising/lowering temperature, range: 0.5~10h, 0.5h interval adjustment or set to "-"... - Page 18 Time Single injection time, range: 1 ~ 300s, interval 1s adjustment or set to "-" continuous injection until manual stop. Speed Sample inhalation speed, range: 1 ~ 8ml / min, interval 0.5 ml / min adjustment. Recycling samples Place the discharge end of the silicone tube in the waste collection container; Main interface, press the button Recycling on the right, pop-up recycling control <...
-
Page 19: System Settings
time (or press the button Stop ) end. Press the button Cancel to return to the main interface. Time Single cleaning time, range: 1 ~ 300s, interval 1s adjustment or set to "-" continuous injection until manual stop. Stop injection/recycling/cleaning Main interface, if the injection/recycling/cleaning is in progress, press the button Stop button on the right to end. - Page 20 Set display brightness Press the icon ， on the Brightness tab to decrease/increase the display brightness. Turn automatic standby on/off Standby mode means that the instrument automatically reduces the brightness of the display when there is no operation for a period of time to save energy and extend the life of the display.
-
Page 21: Technical Service
(2) years from date of delivery. If a defect is present, VWR will, at its option and cost, repair, replace, or refund the purchase price of this product to the customer, provided it is returned during the warranty period. -
Page 22: Equipment Disposal
a defect of the product. Equipment disposal This equipment is marked with the crossed out wheeled bin symbol to indicate that this equipment must not be disposed of with unsorted waste. Instead it's your responsibility to correctly dispose of your equipment at lifecycle -end by handling it over to an authorized facility for separate collection and recycling. -
Page 23: Local Vwr Offices In Europe And Asia Pacific
Local VWR offices in Europe and Asia Pacific Austria Hungary Poland VWR International GmbH VWR International Kft. VWR International Sp. z o.o. Graumanngasse 7 Simon László u. 4. Limbowa 5 1150 Vienna 4034 Debrecen 80-175 Gdansk Tel.: +43 1 97 002 0 Tel.: +36 (52) 521-130...
