1032
INSTRUCTIONS
INSTALLATION AND OPERATING INSTRUCTIONS
FOR THE AMC-1032 TWO CHANNEL MONITOR
WITH INTEGRAL CARBON MONOXIDE/REMOTE
AMC-3700 PROPANE SENSORS
IMPORTANT:
PLEASE READ THESE INSTRUCTIONS CAREFULLY
BEFORE BEGINNING INSTALLATION AND/OR
OPERATION OF THIS EQUIPMENT.
Filename: Manual AMC 1032 CO_Propane
Copyright, 12/05/1999
The Armstrong Monitoring Corporation
)
(613) 225-9531 —
(613) 225-6965 — Fax
)
(800) 465-5777 —
U.S. Toll Free
www.armstrongmonitoring.com
