Summary of Contents for Ambiano MD 37260

Page 1 User Manual TABLE TOP FRIDGE...
Page 2: Table Of Contents
Contents Contents About this user manual ................... 5 Explanation of symbols ..................5 Proper use ....................... 7 Safety information ..................8 General safety instructions ................9 Transport ......................10 Installation and electrical connection ............. 11 Cleaning and maintenance ................14 Faults ........................15 Disposal ....................... 16 Information on the appliance ................16 Information regarding refrigerant R-600a ............17 Package contents ...................
Page 3 Contents Disposal ......................31 Technical speciﬁ cations ..................32 Product data sheet .................... 32 EU declaration of conformity ................ 34 Spare parts ....................34 Service information ..................34 Legal Notice ....................35 Privacy statement ..................36...
Page 4: About This User Manual
About this user manual About this user manual Thank you for choosing our product. We hope you enjoy using this appliance. Read the safety instructions carefully before using the appliance for the ﬁ rst time. Note the warnings on the appliance and in the user manual. Always keep the user manual close to hand.
Page 5 About this user manual Follow the instructions in the user manual! Warning: risk of electric shock! Warning: danger due to combustible and/or highly ﬂ ammable substances! Warning: danger due to the highly ﬂ ammable R-600a refrigerant. R600a Warning: risk of explosive materials! •...
Page 6: Proper Use
Proper use Proper use This appliance is intended to be used for cooling food. This appliance is designed for use in private households and similar household applications, such as: − Staff kitchens in shops, ofﬁ ces and other workplaces − In agriculture and by guests in hotels, motels and other types of accommodation −...
Page 7: Safety Information
Safety information Safety information IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND KEEP FOR FUTURE REFERENCE! − This appliance can be used by children over the age of 8 and by persons with reduced physical, sensory or mental abilities or by those with limited experience and/or knowledge, provided that they are supervised or have been instructed in how to use the appliance safely, and have understood the associated risks.
Page 8: General Safety Instructions
Safety information General safety instructions WARNING! Risk of injury! The appliance’s refrigeration system contains R-600a refrigerant. If the refrigerant escapes, there is a risk of injuries. − WARNING! Do not damage the refrigerant circuit. − If the refrigeration system has nevertheless become damaged, ventilate the room.
Page 9: Transport
Safety information Transport CAUTION! Risk of injury! The appliance is heavy. There is a risk of injury from the strain of lifting the appliance. − Seek the assistance of at least one other person in order to move the appliance. NOTICE! Risk of damage! Risk of damage to the appliance if transported incorrectly.
Page 10: Installation And Electrical Connection
Safety information Installation and electrical connection Location NOTICE! Risk of damage! Risk of damage to the appliance due to improper handling. − Install the refrigerating appliance in a dry and ventilated room. The room should be approx. 4 m² to ensure that sufﬁ cient air volume is available if the refrigeration system becomes damaged.
Page 11 Safety information Always load the cooling chamber ﬁ rst and then the door compartment. WARNING! Risk of ﬁ re! Insufﬁ cient air circulation can lead to heat accumulation. − Make sure that the ventilation openings in the housing, around the appliance and in the installation niche are not blocked. −...
Page 12 Safety information Mains connection WARNING! Risk of electric shock! There is a risk of electric shock due to live parts. − Connect the appliance to a properly installed, earthed safety socket which is easily accessible and close to the place of installation.
Page 13: Cleaning And Maintenance
Safety information WARNING! Risk of injury/risk to health! Improper handling of the appliance can lead to injuries. − Do not misuse the plinth, drawer compartments, doors etc. as a step or for support. The appliance may not work properly (temperature increase) if the appliance is exposed to temperatures that fall below the speciﬁ...
Page 14: Faults
Safety information WARNING! Risk of explosion and ﬁ re! An accumulation of gas can lead to explosions. − Do not use any ﬂ ammable liquids to clean the appliance or any part of the appliance. NOTICE! Risk of damage! Damage to the appliance caused by improper handling. −...
Page 15: Disposal
Information on the appliance − If there is damage to the mains connection cable on this appliance, it must be replaced by the manufacturer, their customer service department, or another suitably qualiﬁ ed person. This is necessary to avoid hazards. −...
Page 16: Information Regarding Refrigerant R-600A
Package contents Information regarding refrigerant R-600a R-600a and cyclopentane are used as 100% HCFC-free refrigerant and insulating materials in this appliance. This helps to protect the ozone layer and reduces the so- called greenhouse effect. These appliances can be identiﬁ ed by the “Refrigerant R-600a” notice on the type plate.
Page 17: Appliance Overview
Appliance overview Appliance overview Storage tray Container shelf Bottle rack Refrigerator door Lower hinge with adjustable foot Adjustable foot Mains cable with plug (on the back, not shown) Cooling chamber Temperature control, can be set to level 0–5 (at rear, not shown) Wire shelf Ice cube compartment Upper hinge...
Page 18: Before Operation
Before operation The type plate is located on the back of the appliance. Store the food in appropriate containers as follows: The ice cube compartment is suitable: • for making ice cubes • for storing fresh pork, beef, ﬁ sh, chicken, some ready-made products etc.
Page 19: Changing The Door Hinge Over To The Opposite Side
Before operation ca. 5 cm ca. 30 cm 5 cm ca. 51 cm ca. 98 cm ca. 88 cm Changing the door hinge over to the opposite side The refrigerator is supplied with a door hinged on the right-hand side. If you would like to change the door hinge over to the opposite side, proceed as follows.
Page 20 Before operation − Remove the screw hole cover on the left-hand side, for example using a ﬂ at- head screwdriver. − Remove the blind plug for the hinge pin from the left-hand side of the refrigerator door and insert it in the hole on the right-hand side. Place the refrigerator on its back.
Page 21 Before operation − Remove the screws from the side housing on the left-hand side and place them on the opposite side. − Place the two white washers and the locking washer from the lower hinge safely to one side. They will be required when reinstalling the refrigerator door −...
Page 22 Before operation − Stand the appliance upright again. While doing so, hold the refrigerator door quite ﬁ rmly in place. − Before screwing the upper hinge back on, ensure that the refrigerator door closes ﬂ ush with the appliance housing horizontally and vertically so that all seals close.
Page 23: Removing And Reinserting The Wire Shelf
Operating the appliance Please note: The door seal adapts to the new door hinge after a few hours. If tilted to an angle of more than 40° during transport or when changing the door ﬁ ttings, wait 30 minutes before connecting it to the mains and switching it on to enable the refrigerant circuit to settle.
Page 24: Temperature Control
Operating the appliance Temperature control − Connect the appliance to an earthed mains socket. The local mains voltage must match the voltage stated in the technical speciﬁ cations for the appliance. The temperature control setting automatically adjusts the temperature setting in the cooling chamber and ice cube compartment The refrigeration temperature can be set as follows:...
Page 25: Switching Off The Appliance
Operating the appliance Switching off the appliance to 0 and unplug − To de-energise the appliance, set the temperature control the mains plug from the socket. − Wait approx. 10 minutes before switching on the appliance again. Tips on saving energy −...
Page 26: Storing Food In The Cooling Chamber
Using the ice cube compartment Storing food in the cooling chamber NOTICE! Possible material damage! Possible risk of damage to the door seal − Sensitive surfaces: Do not allow oil and grease to come into contact with the plastic parts and the door seal as the surface can become porous and brittle.
Page 27: Making Ice Cubes
Defrosting the ice cube compartment The ice cube compartment is not suitable for freezing foods or storing highly perishable foods. Food that has already been frozen can, if necessary, be stored in suitable packaging for 1–3 days. Making ice cubes −...
Page 28: Cleaning The Appliance
Cleaning the appliance − Do not operate any electrical appliances inside the refrigerator. Both appliances may be damaged irreparably. − Take the frozen product out of the ice cube compartment , wrap in a few layers of newspaper and possibly a blanket and store it in a cool location. to 0 and pull out the mains plug.
Page 29: Transport
Transport − Wash the cooling chamber and ice cube compartment with a mild cleaning agent (e.g. washing-up liquid or a sodium carbonate solution of 3 teaspoons of soda to 1 litre of water) and leave to dry completely. − Carefully clean and dry all ﬁ ttings. −...
Page 30: Disposal
Disposal Fault Cause Solution The temperature The refrigerator door − Arrange chilled goods so is not low does not seal properly that the door can be closed enough. or is opened too often. without any obstruction. − Open the refrigerator door for less time.
Page 31: Technical Specifi Cations
Approx. 14 kg Protection class Product data sheet Supplier’s name or AMBIANO® trademark: Supplier’s address: MEDION AG Am Zehnthof 77 45307 Essen Germany Model identiﬁ er: MD 37260 Type of refrigerating appliance: Low-noise Design type: Free-standing appliance: Wine cooler: Other refrigerating appliance:...
Page 32 Technical speciﬁ cations General product parameters: Parameter Value Parameter Value Overall Height Total volume (in dm dimensions or l) Width (in mm) Depth Energy efﬁ ciency class Airborne noise emissions Airborne noise (in dB(A) re 1 pW) emission class Annual energy 79.0 Climate class: N, ST...
Page 33: Eu Declaration Of Conformity
EU declaration of conformity EU declaration of conformity MEDION AG hereby declares that this appliance complies with the fundamental requirements and the other relevant provisions of: • EMC Directive 2014/30/EU • Low Voltage Directive 2014/35/EU • Ecodesign Directive 2009/125/EC • RoHS Directive 2011/65/EU. Spare parts Please visit our MEDION Service Shop at https://www.medion.com/medionserviceshop to order any spare parts you need.
Page 34: Legal Notice
Legal Notice You can download this and many other sets of operating instructions from our service portal at www.medionservice.com. You will also ﬁ nd drivers and other software for a wide range of devices there. You can also scan the QR code on the side of the screen, to download the operating instructions onto your mobile device from the service portal.
Page 35: Privacy Statement
Privacy statement Privacy statement Dear customer, We wish to inform you that we, MEDION AG, Am Zehnthof 77, 45307 Essen, Germany process your personal data as a data controller. For matters regarding data protection, we are supported by our company data protection ofﬁ...
Page 36 WARWICKSHIRE, CV9 2SH. ALDI STORES (IRELAND) LTD. PO BOX 726, NAAS, CO. KILDARE. Visit us at www.aldi.com AFTER SALES SUPPORT 714277 0333 3213106 1 800 992508 Standard local land- Free hotline line call rate www.medion.co.uk YEAR MODEL: WARRANTY 09/2021 MD 37260...
