SERVICE MANUAL
Disc Mower-Conditioner
Part number 48049004
2
edition English
nd
November 2016
Replaces part number 47544204
Discbine
®
Discbine
®
313
316

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Discbine 313 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for New Holland Discbine 313

  • Page 1 SERVICE MANUAL Discbine ® Discbine ® Disc Mower-Conditioner Part number 48049004 edition English November 2016 Replaces part number 47544204...
  • Page 2 SERVICE MANUAL Discbine® 313 Discbine® 316 48049004 14/11/2016 Find manuals at https://best-manuals.com...
  • Page 3 Contents INTRODUCTION Power Take-Off (PTO) ..............31 [31.201] Power Take-Off (PTO) drive shaft ..........31.1 [31.214] Secondary Power Take-Off (PTO) .
  • Page 4 INTRODUCTION 48049004 14/11/2016 Find manuals at https://best-manuals.com...
  • Page 5: Table Of Contents

    Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Safety rules .
  • Page 6: Foreword - Important Notice Regarding Equipment Servicing

    Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your NEW HOLLAND Sales and Service Networks. 48049004 14/11/2016...
  • Page 7: Safety Rules

    INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual you will find the signal words DANGER, WARNING, and CAUTION followed by special in- structions.
  • Page 8: Safety Rules - Personal Safety

    INTRODUCTION Safety rules - Personal safety General safety rules Use caution when you operate the machine on slopes. Raised equipment, full tanks and other loads will change the center of gravity of the machine. The machine can tip or roll over when near ditches and embankments or uneven surfaces.
  • Page 9 INTRODUCTION Before you leave the machine: 1. Park the machine on a firm, level surface. 2. Put all controls in neutral or park lock position. 3. Engage the parking brake. Use wheel chocks if required. 4. Lower all hydraulic equipment — Implements, header, etc. 5.
  • Page 10 INTRODUCTION Wheels and tires Make sure that tires are correctly inflated. Do not exceed any recommended load or pressure. Follow the instructions in the manual for proper tire inflation. Tires are heavy. Handling tires without proper equipment could cause death or serious injury. Never weld on a wheel with a tire installed.
  • Page 11 INTRODUCTION Power Take-Off (PTO) Power Take-Off (PTO) driven machinery can cause death or serious injury. Before you work on or near the PTO shaft or service or clear the driven machine, put the PTO lever in the disengage position, stop the engine, and remove the key.
  • Page 12 INTRODUCTION Material Safety Data Sheets (MSDS) provide information about the chemical substances within a product, safe han- dling and storage procedures, first aid measures, and procedures to take in the event of a spill or accidental release. MSDS are available from your dealer. Before you service your machine check the MSDS for each lubricant, fluid, etc.
  • Page 13: Safety Rules - Ecology And The Environment

    Improper disposal of batteries can contaminate the soil, groundwater, and waterways. NEW HOLLAND strongly recommends that you return all used batteries to a NEW HOLLAND dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement.
  • Page 14: Torque - Nominal Tightening Torques For Normal Assembly

    INTRODUCTION Torque - Nominal tightening torques for normal assembly NOTE: In the metric tables, nominal sizes M4 through M8 hardware torque specifications are shown as a Newton meters (pound-inches) numerical value. Nominal sizes M10 through M24 hardware torque specifications are shown as a Newton meters (pound-feet) numer- ical value.
  • Page 15 INTRODUCTION Identification markings Metric hex head, flange hex head and carriage bolts, Classes (CL) 5.6 and upward NHIL14RB00662AA Metric bolt identification markings 1. Manufacturer's identification 2. Property class Metric hex nuts and locknuts, Classes (CL) 05 and upward NHIL14RB00663AA Metric hex nut identification markings •...
  • Page 16 INTRODUCTION NOTE: In the Imperial units tables, the nominal sizes, 1/4 (0.25) in (inch) and 5/16 (0.3125) in (inch) hardware torque specifications are shown as a Newton meters (pound-inches) numerical value. Nominal sizes 3/8 (0.375) in (inch) through 1 (1.0) in (inch) hardware torque specifications are shown as a Newton meters (pound-feet) numerical value.
  • Page 17 INTRODUCTION Identification marking Grades of inch bolts and free-spinning nuts SAE (J995) bolt head and nut grade identification Grade Grade identification marking Marking description Grade 2 No line marks Grade 5 Three line marks Grade 8 Six line marks Grade 2 No circumferential line marks Grade 5 Two circumferential line marks located 120°...
  • Page 18 INTRODUCTION Grades of inch prevailing torque locknuts, all metal (three common marking methods) On prevailing torque locknuts, the grade of nut is identified by one of three different sets of markings that denote the strength level and manufacturer. Common prevailing torque locknut grade identification markings Grade Grade identification marking Marking description...
  • Page 19: Basic Instructions - Shop And Assembly

    Only use CNH Original Parts or NEW HOLLAND Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or NEW HOLLAND Original Parts can offer this guarantee.
  • Page 20 W0111A Special tools The special tools that NEW HOLLAND suggests and illustrate in this manual have been specifically researched and designed for use with NEW HOLLAND machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting operation.
  • Page 21: General Specifications

    INTRODUCTION General specifications Model Discbine® 313 Discbine® 316 Overall Width Transport position 4.04 m (13 ft 4 in) 5.05 m (16 ft 7 in) Field position – Two-point hitch 6.5 m (21 ft 3 in) 7.8 m (25 ft 7 in) Field position –...
  • Page 22 Standard 750 RPM ( 640 RPM optional by swapping sheaves) Standard 1042 RPM, Optional 752 RPM with the low-speed rotor kit Speed – Flail conditioner (available from your authorized NEW HOLLAND dealer) Conditioning roll tension adjustment – Single crank Roll conditioner Conditioner gap adjustment –...
  • Page 23: Capacities

    Consumable product Material specification Capacity Grease lubricant As specified per the All grease fittings operator’s manual CNH Industrial: MAT3550 NEW HOLLAND AMBRA maintenance section. Performance: NLGI 2, HI TEMP EP GREASE GC-LB Not specified; amount as Wheel bearings – Repack...
  • Page 24 INTRODUCTION 48049004 14/11/2016...
  • Page 25: Product Identification

    INTRODUCTION Product identification Product Identification Number (PIN) The location of the disc mower-conditioner Product Iden- tification Number (PIN) plate (1) is on the right-hand side of the trail frame. NHIL13HT00487AA (1) – Model (2) – PIN number (3) – Weight (4) –...
  • Page 26: Product Identification - Machine Orientation

    INTRODUCTION Product identification - Machine orientation NOTE: On this equipment, left-hand and right-hand are determined by standing behind the unit, looking in the direction of travel. NHIL13HT00287AA Left-hand side view NHIL13HT00289AA Right-hand side view NHIL13HT00288AA Rear view 48049004 14/11/2016...
  • Page 27 INTRODUCTION 48049004 14/11/2016...
  • Page 28 SERVICE MANUAL Power Take-Off (PTO) Discbine® 313 Discbine® 316 48049004 14/11/2016...
  • Page 29 Contents Power Take-Off (PTO) - 31 [31.201] Power Take-Off (PTO) drive shaft ........... . 31.1 [31.214] Secondary Power Take-Off (PTO) .
  • Page 30 Power Take-Off (PTO) - 31 Power Take-Off (PTO) drive shaft - 201 Discbine® 313 Discbine® 316 48049004 14/11/2016 31.1 [31.201] / 1...
  • Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
