Page 1 ITS-AXX Barrier Gate Control Radar (Collision Avoidance Type) User’s Manual Changsha MicroBrain Intelligent Technology Co., Ltd.
Page 2 Copyright Notice Thank purchasing ITS-AXX Barrier Gate Control Radar with collision avoidance for smart access radar products. To ensure the best performance of the radar product, you are kindly invited to read this user’s manual carefully, then you are strongly suggested to install and...
Page 3 product belongs to Changsha MicroBrain Intelligent Technology Co., Ltd., and is protected by law. No unit or individual shall infringe these lawful rights. In order to further improve the quality and performance, the specifications and designs of this product changed without notifications.
Page 4: Table Of Contents
Content 1.Introduction ........5 2.Technical Specifications ....8 3.Features ..........9 4.Installation Instructions ..... 13 5.Interface Definition ..... 18 6.Configuration Instructions ..22 7.Remarks ......... 26...
Page 5: Introduction
1.Introduction ITS-AXX barrier gate control radar is developed for the entrance and exit management of parking lots or underground garages. It can precisely control the rising and falling of the gate rod by cooperating with the main control board of the gate control system, effectively avoid the "accidental injury"...
Page 6 scheme, which characteristics of small size, low cost, all-weather work, high detection sensitivity, high precision, easy to debug and installation, very good stability and reliability. The working frequency of the radar is among 77GHz-81GHz, with Linear Frequency Modulation Continous Waveform, which makes the available bandwidth 4GHz.The range...
Page 7 multiple receiving configuration, with high angular resolution and angle measuring accuracy; signal processing control unit adopts DSP + ARM dual core architecture. Through the joint optimization design of software and hardware, this product can accurately identify distinguish pedestrian, vehicle and other targets passing through the brake lever area, and avoid the phenomena of "smashing...
Page 8: Technical Specifications
2.Technical Specifications Terms Parameter Value Input 10~16 Voltage(Volts) Temperature -40~85 Range(℃) Power(W) < 2.5 Working Water Condition Rissistance IP67 Level Connection RS485 Interface 107.5*73.2* Size(mm)
Page 9: Features
Default ± 0.5m Along Road (configurabl Width e within ± Detection Zone Default 3 m Cross Road (configurabl Range e within 6 Online Serial Port Upgrade debugging Debug Serial Port Debug Online update Upgrade 3.Features The appearance of ITS-AXX...
Page 10  LED indicators There are two LED indicators on the surface of the front surface of ITS-AXX radar. The red LED is the power state lamp which will stay on when the power supply is turned on;...
Page 11 The default detection Zone of the radar is 3 meters forward times 0.5 meters on the left and right sides. configurable detection area can be set by the host computer software;  Configuration parameters saving and reload Configuration such as detection area could automatically...
Page 12 communication distance;  Firmware upgrade The firmware can be upgraded online through 485 interface with host computer without taking off the cover board and the new firmware can take effect just by restarting the power of radar.  Stable performance Millimeter wave radar sensing capablity stay nearly the same under...
Page 13: Installation Instructions
Figure 1. ITS-AXX Appearance and Size 4.Installation Instructions The radar must be installed on the surface of gate box body and the radar surface with LED indicators must be perpedicular...
Page 14 to the lane (vehicle access) direction. The installation must follow the instructions below:  Step1. Choice radar mounting location. the radar LED indicator must be facing down which refers in figure 2. The installation position of radar must be 200-300mm away from the barrier gate and 550-750mm higher than the ground.
Page 15 Figure Radar Installation Demonstration  Step2. Trepanning A mounting hole of M16 should be drilled on the surface of gate box according to the installation position illustrated in the former part(see figure 2). Recommended diameter...
Page 16 drilling hole must approximately 16mm  Step3. Radar mounting and fixing. M16 nut (a)Radar through a (b)Nut locking and fixing circular hole Plug-in wiring harness (c)Plug in harness fixing (d)Post installation display Figure 3. ITS-A06 mounting and fixing...
Page 17 steps schematic As shown in Figures 3 (a)-(d), the radar is fixed to the brake box through the bottom bolt. Firstly the radar is plugged into the brake box, then cover the washer with M16 screws to fix it, then insert the end of the wire harness into the radar in the correct direction and lock the metal...
Page 18: Interface Definition
Figure 4.ITS-AXX Installation Demonstration 5.Interface Definition There are 10 wires interface among which some of them should be connected to the mainboard of barrier gate. The definition of each interface is shown as followling table.
Page 19 Color Description CABLE ID positive pole Black negative pole Reserved Yellow Ground White Gray Normally Normally Blue open1 open1 Normally Normally Green open1 open1 Normally Normally Brown open2 open2 Normally Normally purple open2 open2 Enter Orange Enter...
Page 20 Here detailed connections of these interface to the gate control board.  Power supply connection: The red wire("VCC") MUST be connected to the positive output terminal of the 12V power supply, The black wire ("GND") MUST be connected negative output terminal of the power supply.
Page 21 to the T / R- terminal of 485;  Manual Range Setting orange line "5V" connected to the yellow line "reserved common ground" through the DIP switch which is made by ‘NO’ and ‘1’ triggerss.  Barrier gate control signal: The green and blue wires are normally open signals 1 of the radar onboard relay1.
Page 22: Configuration Instructions
loop detector interface and the public common signal interface. 6.Configuration Instructions You can configure the radar detection area, the learning and recording environment by using "Barrier Setting" tool software (the interface is shown in Figure 5), the serial port printing tool, and the one-click distance adjustment.
Page 23 Note: The baud rate should be 115200. Host Software Setting:  Step1: Select the serial port number Insert the 485 connector to the host computer, to establish the connection between radar and the host computer, and the customers can find the port number in the device manager list of the computer and select it...
Page 24 (for the serial port connection method, refer to Section 5 of this manual interface cable description).  Step2: Radar Sensing Range Setting The factory default operating range of radar is 3 metres. The user can set it according to the length of the specific gate bar;...
Page 25  Step3: Boundary Setting the factory default boundary of radar detection along the access road is limited to -0.5 m and 0.5m in the center of the gate bar. default setting recommended. Users can also customize the setting within ±1 according actual situation.
Page 26: Remarks
7.Remarks  Please read the following instructions carefully before using ITS-AXX radar:  Ensure power supply stable to prevent influence on the performance of the radar.  Avoid collision and falling to avoid physical damage of the radar.  It should be cleaned in time...
Page 27 electromagnatica waves.  Please reconfigure the radar parameters and power off restart when detection environment changes.  Objects affecting target detection such metal objects etc should not be placed within the detection area radar avoid triggering by mistake;  The installed gate box must be stable, and the shaking of the box will easily lead to abnormal radar operation.
Page 28 detection distance is slightly less than or equal to the length of the pole to prevent people or objects outside the brake lever from being detected by the radar.
Page 29 Federal Communications Commission (FCC) Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 30  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received,...
Page 31 This product may not be collocated or operated in conjunction with any other antenna or transmitter. This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.
Page 32 Packing List Accessory Name Quantity ITS-AXX Radar M16 nut Waterproof rubber ring gasket Plug-in wiring harness Service Hotline： 0731-89909918(extension 802)
