Summary of Contents for Clevertouch SCETA
- Page 1 INSTALLATION GUIDE INSTALLATION GUIDE FOR WALLMOUNTED AND MOBILE ELECTRICAL HEIGHT ADJUSTABLE “LIGHT” SYSTEMS FOR USE WITH UP TO 86" DISPLAYS...
-
Page 2: Table Of Contents
CONTENT Important hazard and safety notes Assembly instructions 5 – 8 Mobile systems Systems with floor panel Wall mounted systems “Light” Frame installation Operating unit for height EC-Declaration of conformity 7–10 Certificate of compliance... - Page 3 Total load: 150 kg/ 330 lbs Max. additional load: 120 kg/ 264 lbs Thank you for purchasing our electrical height components (I.e. trolley, frame unit for interactive adjustable units. Please carefully read all components, etc.) but those, which are certified by us. We cannot take over any warranty for safety and proper provided informations before assembling and usage.
-
Page 4: Important Hazard And Safety Notes
Important hazard & safety notes Please carefully read the below hazard and safety notes before using the height adjustment unit. This adds to make the unit work failure-free and avoids accidents. Electrical safety Connect unit to a free accessible 110 – 230 V / 50 Hz grounded power outlet only. Make sure, the unit can be immediately separated from the power outlet. -
Page 5: Assembly Instructions
MOBILE SYSTEMS SYSTEMS WITH FLOOR PANEL FOR V-STAND FOR FLOOR PANEL Connect the trolley to the column. Connect the floor panel to the column. 4 x countersunk Allen head screw 4 x lens head Allen screw with flange M8 x 40 mm M8 x 40 mm WALL MOUNTED SYSTEM Fix 2 x Z-bracket to the wall. -
Page 6: Light" Frame Installation
“LIGHT” FRAME INSTALLATION Secure “lift & lock”-brackets to Attach upper bar using 2 x lens head Allen screw with flange the display, before M8 x 85 (long) and ensure the slotted holes facing upwards attaching to mount. and towards the screen. To attach the display to the Attach lower bar using 2 x M6 x 30 (short) screws and ensure mount use the included... -
Page 7: Ec-Declaration Of Conformity
Manufactors name or of his representative Conen Produkte GmbH, D - 54497 Morbach-Gonzerath Description of the machine Motorized lift system for displays and (interactive) boards Part-No. SCETA (-L) / SCETA-W(L) / SCETTA/ SCETAVLI / CCELW-AF EC-machinery directive (2006/42/EG) EMC directive (2014/3/EU) European directive(s) WEEE-Directive 2012/19/EU... - Page 8 Bei einer mit uns nicht abgestimmten Änderung der Maschine verliert diese Erklärung ihre Gültigkeit. Hersteller Conen Produkte GmbH, 54497 Morbach-Gonzerath Bezeichnung der Maschine Elektrische Hubsäuleneinheit für Tafelsysteme Maschinen-Nr. SCETA (-L) / SCETA-W(L) / SCETTA/ SCETAVLI / CCELW-AF EG-Richtlinie Maschine (2006/42/EG) EG – EMV (2014/3/EU) Zutreffende EG-Richtlinien ROHS Directive 2011/65/EU WEEE-Richtlinie 2012/19/EU...
- Page 9 Producent Conen Produkte GmbH, D - 54497 Morbach-Gonzerath Produktbeschrijving Electrisch kolommensysteem voor monitoren en (interactieve) schoolborden Produktnummer SCETA (-L) / SCETA-W(L) / SCETTA/ SCETAVLI / CCELW-AF EG-machinerichtlijn (2006/42/EG) EMC richtlijn (2014/3/EU) Geldende EG richtlijnen WEEE richtlijn 2012/19/EU WEEE-Register 12204025...
- Page 10 Conen Produkte GmbH, D - 54497 Morbach-Gonzerath Description de la machine Système de levage motorisé pour les moniteurs et les tableaux (interactive) Réference SCETA (-L) / SCETA-W(L) / SCETTA/ SCETAVLI / CCELW-AF Directive CE machines (2006/42/CE) Directive CEM (2014/3/CE) Directive(s) européenne(s) Directive WEEE 2012/19/EU Numéro d’enregistrement WEEE 12204025...
- Page 12 Manufacturer Clevertouch Europe House,Littlebrook DC1,Shield Rd, London DA1 5UR, UK +44 (0)20 8319 7777 info@clevertouch.com www.clevertouch.com...
